🔧 RAV4 - Engine Oil & Oil Filter Replacement

This service replaces the old engine oil and oil filter so your RAV4’s 2.5L hybrid engine stays properly lubricated and protected. You’ll drain the oil, replace the cartridge-style oil filter, refill with the correct oil, then check the level after running the engine.

Difficulty Level: Beginner | Estimated Time: 45-75 minutes

---

⚠️ Safety & Precautions

• ⚠️ Hybrid warning: do not touch orange high-voltage cables or hybrid components. This oil service does not require hybrid battery service.
• 🧤 Wear gloves and safety glasses. Used engine oil can irritate skin and eyes.
• 🔥 Let the engine cool until it is warm, not hot. Hot oil can burn you.
• 🚗 Support the RAV4 with jack stands if you lift it. Never work under a vehicle supported only by a jack.
• 🔋 Battery disconnect is not required for this oil change.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 14mm socket
• 3/8-inch ratchet
• 3/8-inch torque wrench
• 64mm 14-flute oil filter wrench (specialty)
• 3/8-inch extension
• Flat-blade screwdriver
• Oil drain pan 8-quart minimum
• Funnel
• Shop towels
• Nitrile gloves
• Safety glasses
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil 0W-16 full synthetic - Qty: 4.8 quarts
• Engine oil filter cartridge kit with O-ring - Qty: 1
• Engine oil drain plug gasket - Qty: 1

---

📋 Before You Begin

• Park your RAV4 on level ground.
• Set the parking brake and place the transmission in Park.
• Place wheel chocks behind the rear wheels.
• If lifting the front, use a floor jack and support the RAV4 securely with jack stands.
• Warm the engine for 2-3 minutes, then shut it off. Warm oil drains faster.
• Open the hood and remove the oil filler cap. This helps the oil drain smoothly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the Lower Engine Area

• Put on safety glasses and nitrile gloves.
• If more room is needed, lift the front of the RAV4 with the floor jack rated 3-ton minimum.
• Place jack stands rated 3-ton minimum under the proper front support points.
• Gently lower the RAV4 onto the jack stands before going underneath.
• Use the flat-blade screwdriver to remove any small plastic under-cover retainers needed to access the drain plug and oil filter housing.
• Take a photo before removing clips.

Step 2: Position the Drain Pan

• Place the oil drain pan 8-quart minimum under the engine oil drain plug.
• The drain plug is on the bottom of the engine oil pan.
• Slide the pan slightly toward the rear, because oil may shoot outward at first.

Step 3: Drain the Engine Oil

• Use the 14mm socket and 3/8-inch ratchet to loosen the engine oil drain plug.
• Remove the drain plug by hand once loose.
• Let the oil drain until it slows to an occasional drip.
• Remove the old drain plug gasket from the drain plug.
• Wipe the drain plug clean with shop towels.

Step 4: Reinstall the Drain Plug

• Install the new engine oil drain plug gasket onto the drain plug.
• Thread the drain plug in by hand first. This helps prevent cross-threading, which means damaging the threads by starting the bolt crooked.
• Use the 14mm socket and 3/8-inch torque wrench to tighten the drain plug.
• Torque to 40 Nm (30 ft-lbs).
• Wipe the area clean with shop towels.

Step 5: Remove the Oil Filter Housing

• Move the oil drain pan 8-quart minimum under the oil filter housing.
• The RAV4 uses a cartridge-style oil filter. The paper filter sits inside a reusable filter housing instead of being a metal spin-on can.
• Attach the 64mm 14-flute oil filter wrench (specialty) to the filter housing.
• Use the 3/8-inch ratchet and 3/8-inch extension to turn the housing counterclockwise.
• Unscrew the housing slowly and let oil drain into the pan.
• Remove the housing and old filter cartridge.

Step 6: Replace the Filter Cartridge and O-Ring

• Pull the old paper filter cartridge out of the housing by hand.
• Remove the old O-ring from the filter housing. An O-ring is a round rubber seal that prevents leaks.
• Wipe the housing clean with shop towels.
• Lightly coat the new O-ring with fresh engine oil 0W-16 full synthetic.
• Install the new O-ring into the correct groove on the housing.
• Push the new engine oil filter cartridge kit with O-ring into the housing.
• Do not twist the O-ring.

Step 7: Reinstall the Oil Filter Housing

• Thread the filter housing into the engine by hand first.
• Use the 64mm 14-flute oil filter wrench (specialty), 3/8-inch extension, and 3/8-inch torque wrench to tighten it.
• Torque to 25 Nm (18 ft-lbs).
• Wipe the filter area clean with shop towels.

Step 8: Refill the Engine Oil

• Lower the RAV4 to level ground if it was lifted.
• Place the funnel into the engine oil filler opening.
• Pour in about 4.5 quarts of engine oil 0W-16 full synthetic.
• Reinstall the oil filler cap by hand.
• Wait 2 minutes, then check the dipstick level.
• Add oil slowly until the level is near the full mark.
• Total refill with filter is approximately 4.8 quarts.

Step 9: Start and Leak Check

• Start the RAV4 and let it idle for 30-60 seconds.
• Use safety glasses and look underneath for leaks at the drain plug and oil filter housing.
• Shut the engine off.
• Wait 5 minutes so the oil can drain back into the oil pan.
• Check the dipstick again and top off with the funnel if needed.

Step 10: Reinstall the Lower Cover

• Use the flat-blade screwdriver to reinstall any plastic retainers or access panels removed earlier.
• Make sure the cover sits flat and does not hang loose.
• Wipe any spilled oil with shop towels.

Step 11: Reset the Maintenance Reminder

• Turn the ignition on without starting the engine.
• Use the steering wheel controls to select Settings > Vehicle Settings > Scheduled Maintenance > Reset.
• Confirm the reset when prompted.
• If your display shows an oil maintenance item separately, also select Settings > Vehicle Settings > Oil Maintenance > Reset.

---

✅ After Repair

• Drive your RAV4 for 5-10 minutes, then park on level ground.
• Wait 5 minutes and recheck the dipstick level.
• Look under the engine again for oil drips.
• Dispose of used oil and the old filter at an approved recycling center or auto parts store.
• Do not overfill. Too much oil can cause engine damage.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $55-$90 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.4-0.7 hours.

---
