🔧 Colorado - Engine Oil & Oil Filter Change

This service drains the old engine oil, replaces the oil filter, and refills your Colorado with fresh oil. Clean oil protects the 3.6L V6 from wear, keeps timing components lubricated, and helps prevent sludge buildup.

Difficulty Level: Beginner | Estimated Time: 45-75 minutes

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and let the engine cool until it is warm, not hot.
• ⚠️ Always support your Colorado with jack stands if you lift it. Never rely on a jack alone.
• ⚠️ Used engine oil can burn skin and is harmful to the environment. Wear gloves and recycle the oil properly.
• ⚠️ Keep oil off the exhaust and belts. Wipe spills right away with shop towels.
• ⚠️ Battery disconnect is not required for this oil change.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 15mm socket
• 3/8-inch drive ratchet
• 24mm socket
• 3/8-inch drive torque wrench
• Oil drain pan 10-quart capacity
• Oil filter cap wrench 24mm socket-compatible
• Plastic trim tool
• Funnel
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil 5W-30 full synthetic dexos1 approved - Qty: 6 quarts
• Cartridge-style engine oil filter with O-ring - Qty: 1
• Engine oil drain plug seal - Qty: 1

---

📋 Before You Begin

• 📋 Park your Colorado on level ground, shift to Park, and set the parking brake.
• 📋 Place wheel chocks behind the rear wheels before lifting the front.
• 📋 Run the engine for 2-3 minutes if it is cold, then shut it off. Warm oil drains faster.
• 📋 Open the hood and remove the engine oil fill cap before draining. This helps oil flow out smoothly.
• 📋 A torque wrench tightens bolts to a measured amount so they are not too loose or too tight.
• 📋 A cartridge oil filter is a replaceable paper filter element inside a reusable plastic cap.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and Secure the Front

• Use wheel chocks behind the rear wheels.
• Use a floor jack rated 3-ton minimum at the front frame/crossmember lift point to raise the front of your Colorado enough to work underneath.
• Place jack stands rated 3-ton minimum under the front frame support points.
• Gently lower the truck onto the jack stands and give it a light shake to confirm it is stable.
• Never crawl under a jack-only vehicle.

Step 2: Remove the Lower Access Panel if Equipped

• Put on safety glasses and nitrile gloves.
• If your Colorado has a lower splash shield or access panel, use a plastic trim tool to release any push clips.
• Use the correct socket from your tool set if bolts are fitted, then set the panel and fasteners aside in order.

Step 3: Position the Drain Pan

• Slide the oil drain pan 10-quart capacity under the engine oil drain plug.
• Position the pan slightly behind the plug because the oil may shoot outward at first.
• Use shop towels nearby for spills.

Step 4: Drain the Engine Oil

• Use a 15mm socket and 3/8-inch drive ratchet to loosen the oil drain plug counterclockwise.
• Carefully remove the plug by hand and let the oil drain fully into the pan.
• Wait until the oil slows to an occasional drip.
• Inspect the drain plug threads. Replace the engine oil drain plug seal.
• Keep fingers clear of hot oil.

Step 5: Reinstall the Drain Plug

• Wipe the drain plug area clean with shop towels.
• Thread the drain plug in by hand first. This helps prevent cross-threading, which means the threads start crooked and can damage the oil pan.
• Use a 15mm socket and 3/8-inch drive torque wrench to tighten the drain plug.
• Torque to 25 Nm (18 ft-lbs).

Step 6: Remove the Oil Filter Cap

• From the top of the engine bay, locate the oil filter housing cap on the engine.
• Use a 24mm socket, oil filter cap wrench 24mm socket-compatible, and 3/8-inch drive ratchet to loosen the oil filter cap counterclockwise.
• Lift the cap and old cartridge filter out slowly so oil can drip back into the housing.
• Use shop towels to catch drips.

Step 7: Replace the Cartridge Filter and O-Ring

• Pull the old filter element straight off the cap by hand.
• Remove the old cap O-ring by hand or with a plastic trim tool. Do not scratch the plastic cap.
• Lightly coat the new O-ring with fresh 5W-30 full synthetic dexos1 approved engine oil.
• Install the new O-ring into the same groove where the old one sat.
• Push the new cartridge-style engine oil filter onto the cap until it seats fully.
• Match the old filter orientation.

Step 8: Reinstall the Oil Filter Cap

• Lower the filter and cap assembly into the housing by hand.
• Start the cap threads by hand to avoid cross-threading.
• Use a 24mm socket, oil filter cap wrench 24mm socket-compatible, and 3/8-inch drive torque wrench to tighten the cap.
• Torque to 25 Nm (18 ft-lbs).

Step 9: Add Fresh Engine Oil

• Place a funnel into the engine oil fill opening.
• Add 5.5 quarts of 5W-30 full synthetic dexos1 approved engine oil first.
• Reinstall the oil fill cap by hand.
• Do not add all 6 quarts immediately. Final level is checked after the engine runs.

Step 10: Start the Engine and Check for Leaks

• Start the engine and let it idle for 30-60 seconds.
• Turn the engine off.
• Use safety glasses and look under your Colorado for leaks at the drain plug and around the oil filter cap.
• If a leak is present, shut the engine off and correct it before continuing.

Step 11: Check and Set the Oil Level

• Wait 5 minutes after shutting the engine off so oil can drain back into the oil pan.
• Pull the dipstick, wipe it clean with shop towels, reinstall it fully, then pull it again.
• Add oil through the funnel in small amounts until the level is at the full mark.
• Your Colorado typically takes about 6 quarts with filter, but the dipstick is the final check.
• Reinstall the oil fill cap and dipstick securely.

Step 12: Reinstall the Access Panel and Lower the Truck

• If removed, reinstall the lower splash shield or access panel using the plastic trim tool for push clips.
• Use the appropriate socket if bolts were removed. Tighten small splash shield bolts snug only.
• Use the floor jack rated 3-ton minimum to lift slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower your Colorado slowly to the ground.

Step 13: Reset the Oil Life Monitor

• Turn the ignition to ON without starting the engine, or start the engine if needed for the display.
• Use the steering wheel controls to open the Driver Information Center.
• Select Info > Oil Life.
• Press and hold the checkmark/select button until the oil life resets to 100%.
• If prompted, select Yes to confirm.

---

✅ After Repair

• ✅ Drive your Colorado for 5-10 minutes, then park on level ground and recheck for leaks.
• ✅ Wait 5 minutes after shutdown, then recheck the dipstick and top off if needed.
• ✅ Confirm the oil life display reads 100%.
• ✅ Pour the used oil into a sealed container and recycle it with the old filter at an oil recycling center or parts store.
• ✅ Check the oil level again after the next normal drive.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$160 (parts + labor)

DIY Cost: $45-$75 (parts only)

You Save: $45-$85 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.4-0.7 hours.

---
