🔧 CR-V - Engine Oil & Oil Filter Replacement

This job replaces the used engine oil and oil filter in your CR-V. Fresh oil protects the turbocharged 1.5L engine from wear, heat, and sludge buildup.

Difficulty Level: Beginner | Estimated Time: 45-75 minutes

---

⚠️ Safety & Precautions

• ⚠️ Engine oil can be hot enough to burn you. Let the engine cool until it is warm, not hot.
• ⚠️ Support the CR-V with jack stands before going underneath. Never rely on a floor jack alone.
• ⚠️ Wear safety glasses and nitrile gloves to protect your eyes and skin from used oil.
• ⚠️ Used engine oil is hazardous waste. Drain it into a sealed container and recycle it properly.
• ⚠️ Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 17mm socket
• 3/8-inch drive ratchet
• 3/8-inch drive torque wrench
• 65mm 14-flute oil filter wrench
• Flat-blade screwdriver
• Trim clip removal tool
• Oil drain pan 8-quart minimum
• Long-neck funnel
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil 0W-20 full synthetic - Qty: 4 quarts
• Engine oil filter - Qty: 1
• Oil drain plug crush washer - Qty: 1

---

📋 Before You Begin

• 🅿️ Park your CR-V on level ground and set the parking brake.
• 🧱 Place wheel chocks behind the rear wheels so the vehicle cannot roll.
• 🌡️ Run the engine for 2-3 minutes if it is cold, then shut it off. Warm oil drains faster.
• 🛢️ Open the hood and remove the oil fill cap. This helps oil drain more smoothly.
• 📘 A crush washer is a soft metal sealing washer that should be replaced every oil change.
• 🔧 A torque wrench is a tool that tightens bolts to an exact tightness, preventing leaks or stripped threads.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and Secure the Front

• Use the floor jack rated 2-ton minimum at the front center jacking point to lift the front of the CR-V.
• Place jack stands rated 2-ton minimum under the approved front support points.
• Gently lower the vehicle onto the jack stands and give the vehicle a light push to confirm it is stable.
• Keep the wheel chocks behind the rear wheels.
• Stability matters more than speed.

Step 2: Remove the Lower Engine Cover Access

• Use a flat-blade screwdriver or trim clip removal tool to remove the plastic clips from the lower splash shield access area.
• Move the cover enough to reach the oil drain plug and oil filter.
• Set the clips aside in a safe place so they do not roll away.

Step 3: Position the Drain Pan

• Put on safety glasses and nitrile gloves.
• Place the oil drain pan 8-quart minimum directly under the oil drain plug.
• Move the pan slightly rearward because oil may shoot outward at first.

Step 4: Drain the Engine Oil

• Use a 17mm socket and 3/8-inch drive ratchet to loosen the oil drain plug.
• Finish removing the plug by hand while pushing inward slightly, then pull it away quickly.
• Let the oil drain until it slows to a drip.
• Use shop towels to wipe oil from the drain plug area.
• Do not drop the plug into the pan.

Step 5: Replace the Drain Plug Washer

• Remove the old crush washer from the drain plug by hand.
• Install the new oil drain plug crush washer onto the drain plug.
• Thread the drain plug into the oil pan by hand first. This prevents cross-threading, which means damaging the threads by starting the bolt crooked.
• Use a 17mm socket and 3/8-inch drive torque wrench to tighten the drain plug to Torque to 40 Nm (30 ft-lbs).

Step 6: Remove the Old Oil Filter

• Move the oil drain pan 8-quart minimum under the oil filter.
• Use the 65mm 14-flute oil filter wrench with the 3/8-inch drive ratchet to loosen the oil filter.
• Spin the filter off by hand. Keep it upright as much as possible to reduce spills.
• Check that the old rubber gasket came off with the filter. The gasket is the rubber sealing ring on the top of the filter.
• Use shop towels to clean the oil filter mounting surface.

Step 7: Install the New Oil Filter

• Dip a gloved finger into fresh 0W-20 full synthetic engine oil and lightly coat the new oil filter gasket.
• Thread the new engine oil filter on by hand until the gasket touches the engine.
• Tighten the filter by hand another 3/4 turn after the gasket contacts the engine.
• If using the 65mm 14-flute oil filter wrench and 3/8-inch drive torque wrench, tighten the filter to Torque to 12 Nm (9 ft-lbs).
• Hand-tight is usually enough.

Step 8: Reinstall the Lower Cover

• Use the trim clip removal tool or your hands to align the lower splash shield access cover.
• Reinstall the plastic clips by hand.
• Use a flat-blade screwdriver only if needed to guide the clip centers into place.

Step 9: Lower the Vehicle

• Use the floor jack rated 2-ton minimum to lift the front slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower the CR-V slowly back onto level ground.

Step 10: Add Fresh Engine Oil

• Place the long-neck funnel into the oil fill opening on top of the engine.
• Add about 3.4 quarts of 0W-20 full synthetic engine oil first.
• Reinstall the oil fill cap by hand.
• Start the engine and let it idle for 30 seconds while watching for leaks under the vehicle.
• Shut the engine off and wait 3-5 minutes for the oil to settle.

Step 11: Check and Adjust Oil Level

• Pull out the engine oil dipstick and wipe it clean with shop towels.
• Reinsert the dipstick fully, then pull it out again to read the level.
• Add oil in small amounts through the long-neck funnel until the level is near the upper mark on the dipstick.
• Total refill with filter change is about 3.7 quarts, but always use the dipstick as the final guide.
• Reinstall the dipstick and oil fill cap securely by hand.

Step 12: Reset the Maintenance Minder

• Turn the ignition ON without starting the engine, or start the engine with the vehicle in Park.
• Use the steering wheel controls to select Home > Settings > Vehicle > Maintenance Info.
• Select Oil Life, then press and hold the selector/Enter button until reset options appear.
• Select All Due Items or Engine Oil, then confirm the reset to 100%.
• If your display layout differs, use the instrument cluster menu path: Home > Maintenance Minder > Oil Life > Reset.

---

✅ After Repair

• ✅ Let the engine idle for 1 minute and check under the CR-V for oil leaks at the drain plug and filter.
• ✅ Shut the engine off, wait 3-5 minutes, and recheck the dipstick level.
• ✅ Wipe away any spilled oil with shop towels.
• ✅ Pour the used oil from the drain pan into a sealed container and recycle it with the old filter.
• ✅ Recheck for leaks after your first short drive.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$140 USD equivalent, depending on oil brand and labor rate

DIY Cost: $35-$65 USD equivalent for oil, filter, and washer

You Save: $45-$75 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.4-0.7 hours.

---
