🔧 Tucson - Engine Oil & Oil Filter Change

This job replaces the old engine oil and oil filter in your Tucson’s 2.4L engine. Fresh oil protects the engine from wear, helps cooling, and keeps internal parts clean.

Difficulty Level: Beginner | Estimated Time: 45-75 minutes

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and let the engine cool enough that the oil will not burn you.
• ⚠️ Never rely on a floor jack alone. A floor jack lifts the vehicle; jack stands safely hold it up.
• ⚠️ Wear gloves and safety glasses because used engine oil can irritate skin and eyes.
• ⚠️ Keep oil off the exhaust and drive belts. Wipe spills right away with shop towels.
• ⚠️ Do not over-tighten the drain plug or oil filter. This can damage threads or cause leaks.
• ⚠️ Battery disconnect is not required for this oil change.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 17mm socket
• 3/8-inch ratchet
• 3/8-inch torque wrench
• Oil filter wrench sized for spin-on filter
• Flat-blade screwdriver
• Trim clip removal tool
• Oil drain pan 8-quart capacity
• Funnel
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil 5W-20 full synthetic - Qty: 5 quarts
• Spin-on engine oil filter - Qty: 1
• Engine oil drain plug crush washer - Qty: 1

---

📋 Before You Begin

• 🚗 Park your Tucson on level ground, shift to Park, and set the parking brake.
• 🧱 Place wheel chocks behind the rear wheels before lifting the front.
• 🌡️ Run the engine for 2-3 minutes, then shut it off. Warm oil drains faster, but it should not be hot enough to burn you.
• 📘 Open the hood and remove the oil filler cap. This helps the oil drain smoothly.
• 🛢️ Have the drain pan ready before removing the drain plug.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and Support the Front

• Use wheel chocks behind the rear wheels so your Tucson cannot roll.
• Use the floor jack rated 3-ton minimum at the front center jacking point to raise the front of the vehicle.
• Place jack stands rated 3-ton minimum under the front side support points, then slowly lower the vehicle onto the stands.
• Gently shake the vehicle by hand to confirm it is stable before getting underneath.
• Stability check first, always.

Step 2: Remove the Lower Engine Cover if Equipped

• Put on safety glasses and nitrile gloves.
• Use a flat-blade screwdriver or trim clip removal tool to remove the plastic push clips from the lower engine cover.
• A trim clip removal tool is a small fork-shaped tool that lifts plastic clips without breaking them.
• Lower the cover and set it aside where you will not step on it.

Step 3: Drain the Old Engine Oil

• Slide the oil drain pan 8-quart capacity under the engine oil pan drain plug.
• Use a 17mm socket and 3/8-inch ratchet to loosen the drain plug counterclockwise.
• Finish removing the drain plug by hand while keeping pressure inward until the threads are free, then pull it away quickly.
• Let the oil drain until it slows to an occasional drip.
• Use shop towels to wipe oil from around the drain hole.
• Keep your hand out of the oil stream.

Step 4: Replace the Drain Plug Washer and Reinstall the Plug

• Remove the old crush washer from the drain plug by hand.
• A crush washer is a soft sealing washer that deforms once to prevent leaks.
• Install the new engine oil drain plug crush washer onto the drain plug.
• Thread the drain plug into the oil pan by hand first. This prevents cross-threading.
• Use the 17mm socket and 3/8-inch torque wrench to tighten the drain plug to Torque to 39 Nm (29 ft-lbs).

Step 5: Remove the Old Oil Filter

• Move the oil drain pan 8-quart capacity under the oil filter area.
• Use the oil filter wrench sized for spin-on filter to loosen the oil filter counterclockwise.
• A spin-on oil filter is the metal can-style filter that screws directly onto the engine.
• Once loose, unscrew the filter by hand and keep the open end facing upward to reduce spilling.
• Check that the old rubber gasket came off with the filter. If it stuck to the engine, remove it by hand.
• Double gaskets cause major leaks.

Step 6: Install the New Oil Filter

• Dip a gloved finger in clean engine oil 5W-20 full synthetic and lightly coat the rubber gasket on the new spin-on engine oil filter.
• Thread the new oil filter on by hand until the gasket touches the mounting surface.
• Tighten the oil filter by hand an additional 3/4 turn after gasket contact.
• If using a 3/8-inch torque wrench with a compatible filter cup, tighten the filter to Torque to 12 Nm (9 ft-lbs).
• Wipe the area with shop towels so new leaks will be easy to spot.

Step 7: Reinstall the Lower Engine Cover

• Raise the lower engine cover into position by hand.
• Use the trim clip removal tool or flat-blade screwdriver to reinstall the plastic clips.
• Make sure the cover is secure and not hanging loose.

Step 8: Lower the Vehicle

• Use the floor jack rated 3-ton minimum to lift the front slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Slowly lower your Tucson to the ground with the floor jack.

Step 9: Add New Engine Oil

• Place the funnel into the oil filler opening on top of the engine.
• Pour in about 4.5 quarts of engine oil 5W-20 full synthetic.
• Reinstall the oil filler cap by hand.
• Start the engine and let it idle for 30 seconds, then shut it off.
• Wait 3-5 minutes for the oil to drain back into the oil pan.
• Use a shop towel to wipe the dipstick, reinsert it fully, then pull it out again to check the level.
• Add oil slowly with the funnel until the level reaches the full mark. Total capacity with filter is approximately 5.1 quarts.
• Add slowly. Overfilled oil can damage parts.

Step 10: Reset the Oil Service Reminder

• Turn the ignition to ON without starting the engine, or press the start button twice without pressing the brake pedal.
• Use the steering wheel buttons to open User Settings > Service Interval on the instrument cluster.
• Select Reset, then confirm the reset if prompted.
• If the menu is not visible, check that User Settings > Service Interval > Enable Service Interval is turned on.

---

✅ After Repair

• ✅ Start the engine and check underneath for leaks at the drain plug and oil filter.
• ✅ Shut the engine off, wait 3-5 minutes, then recheck the dipstick level.
• ✅ Top off only as needed. Keep the oil level near the full mark, not above it.
• ✅ Dispose of used oil and the old filter at a recycling center or parts store oil recycling location.
• ✅ After your first short drive, park on level ground and check one more time for leaks.

---

💰 DIY vs Shop Cost

Shop Cost: $85-$150 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $50-$80 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-0.8 hours.

---
