🔧 CR-V - CVT Transmission Fluid Change

This repair replaces the Honda HCF-2 CVT fluid in your CR-V. Fresh fluid helps protect the continuously variable transmission from wear, shudder, overheating, and delayed engagement.

Difficulty Level: Beginner-Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool-to-warm vehicle, not a hot one. Transmission fluid can burn skin.
• ⚠️ Keep your CR-V level when draining and refilling so the fluid level is accurate.
• ⚠️ Use only Honda HCF-2 CVT fluid. Do not use regular automatic transmission fluid.
• ⚠️ Support the vehicle with jack stands. Never work under a vehicle held only by a jack.
• ⚠️ No battery disconnect is required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 3/8-inch drive ratchet
• 10mm socket
• Phillips screwdriver
• Flat trim clip removal tool
• Torque wrench 10-80 Nm
• Fluid drain pan 8-quart minimum
• Long-neck transmission funnel
• Clean shop towels
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Honda HCF-2 CVT transmission fluid - Qty: 4 quarts
• Transmission drain plug sealing washer - Qty: 1
• Underbody splash shield clips - Qty: As needed

---

📋 Before You Begin

• Park your CR-V on a flat, level surface.
• Set the parking brake and place wheel chocks behind the rear wheels.
• Drive for 5-10 minutes first if the vehicle is cold. Warm fluid drains more completely.
• A CVT means “continuously variable transmission.” It uses special fluid and does not shift like a normal automatic.
• This procedure is a drain-and-fill service, not a full flush. Honda commonly services this CVT by drain and refill.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and Secure the Front

• Put on safety glasses and nitrile gloves.
• Use a floor jack rated 2-ton minimum to lift the front of your CR-V at the front center jacking point.
• Place jack stands rated 2-ton minimum under the approved front support points.
• Lower the vehicle gently onto the stands and make sure it feels stable before going underneath.
• Shake test before crawling under.

Step 2: Remove the Lower Splash Shield

• Use a 10mm socket to remove the lower splash shield bolts.
• Use a Phillips screwdriver to remove any screw-type retainers.
• Use a flat trim clip removal tool to release plastic clips without breaking them.
• Set the shield and hardware aside in order.

Step 3: Locate the CVT Drain Plug

• Slide the fluid drain pan 8-quart minimum under the transmission drain plug.
• The CVT drain plug is on the lower transmission case.
• Clean around the drain plug with clean shop towels so dirt does not enter the transmission.

Step 4: Drain the Old CVT Fluid

• Use a 3/8-inch drive ratchet in the square recess of the drain plug.
• Turn the plug counterclockwise and remove it carefully by hand once loose.
• Let the fluid drain until it slows to a drip.
• Expect about 3.5-4 quarts to drain during a normal drain-and-fill.
• Keep the pan centered.

Step 5: Clean and Reinstall the Drain Plug

• Remove the old transmission drain plug sealing washer.
• Wipe the drain plug clean with clean shop towels.
• Install a new transmission drain plug sealing washer onto the drain plug.
• Thread the plug in by hand first so it does not cross-thread.
• Use a torque wrench 10-80 Nm with the 3/8-inch drive ratchet setup to tighten the plug.
• Torque to 49 Nm (36 ft-lbs).

Step 6: Access the CVT Fill Point

• Open the hood and support it securely.
• Locate the CVT fill plug or fill port on top of the transmission case.
• Wipe the area clean with clean shop towels before opening it.
• Use the appropriate hand pressure to remove the fill plug if equipped; do not let dirt fall into the opening.

Step 7: Add New Honda HCF-2 CVT Fluid

• Place a long-neck transmission funnel into the CVT fill opening.
• Pour in Honda HCF-2 CVT transmission fluid slowly.
• Add the same amount that drained out, usually about 3.5-4 quarts.
• Do not overfill. Add slowly near the end.
• Measure what came out first.

Step 8: Reinstall the Fill Plug

• Remove the long-neck transmission funnel.
• Wipe away any spilled fluid with clean shop towels.
• Reinstall the CVT fill plug securely.
• If your fill plug uses a threaded fastener, use a torque wrench 10-80 Nm and tighten to Torque to 44 Nm (33 ft-lbs).

Step 9: Cycle the Transmission

• Start your CR-V while keeping your foot firmly on the brake pedal.
• Move the shifter slowly through P > R > N > D > S > L, pausing 3 seconds in each position if equipped.
• Return the shifter to P.
• Let the engine idle for about 1 minute.
• Check underneath for leaks using a flashlight if available.

Step 10: Reinstall the Splash Shield

• Shut the engine off.
• Use a 10mm socket to reinstall the lower splash shield bolts.
• Use a Phillips screwdriver to reinstall screw-type retainers.
• Use a flat trim clip removal tool by hand to seat any plastic clips carefully.
• Tighten splash shield bolts snug only. Do not overtighten plastic shield hardware.

Step 11: Lower the Vehicle

• Use the floor jack rated 2-ton minimum to lift the front slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower your CR-V slowly to the ground.
• Remove the wheel chocks.

---

✅ After Repair

• ✅ Test drive gently for 10-15 minutes.
• ✅ Confirm smooth engagement from Park to Drive and Reverse.
• ✅ Park on level ground and inspect underneath for leaks.
• ✅ Dispose of old CVT fluid at a recycling center or auto parts store. Do not pour it on the ground or into drains.
• ✅ If the maintenance reminder is on, reset it through Home > Settings > Vehicle > Maintenance Info > Reset.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $55-$95 (parts only)

You Save: $125-$225 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
