🔧 HR-V - CVT Transmission Fluid Change

This service drains and refills the CVT fluid in your HR-V. Honda CVTs are very fluid-sensitive, so use only Honda HCF-2 CVT fluid or an approved equivalent clearly labeled for Honda HCF-2.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface so the fluid level is accurate.
• ⚠️ Support your HR-V with jack stands. Never rely on a floor jack alone.
• ⚠️ CVT fluid can be hot. Let the vehicle cool until the transmission pan is warm, not burning hot.
• ⚠️ Do not use regular automatic transmission fluid. The HR-V CVT requires Honda HCF-2 CVT fluid.
• ⚠️ Do not start the engine with the transmission low on fluid.
• ⚠️ Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 3/8-inch drive ratchet
• 3/8-inch drive torque wrench
• 10mm socket
• 17mm socket
• Drain pan (8-quart minimum)
• Long-neck transmission funnel
• Measuring jug with quart markings
• Plastic trim clip remover
• Clean shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Honda HCF-2 CVT fluid - Qty: 4 quarts
• CVT drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park your HR-V on level ground and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Drive the vehicle for 5-10 minutes, then let it sit briefly so the CVT fluid is warm but safe to touch.
• A crush washer is a soft sealing washer that compresses when tightened. Replace it every time to prevent leaks.
• A torque wrench tightens bolts to the correct tightness. This helps prevent stripped threads and leaks.
• Record how much old fluid drains out. Refill with the same amount first, then verify level.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and Support the Vehicle

• Use the floor jack to lift the front of your HR-V at the front center jacking point.
• Place jack stands under the proper front support points.
• Keep the vehicle as level as possible. If needed, raise the rear with the floor jack and support it with jack stands.
• Put on safety glasses and nitrile gloves.

Step 2: Remove the Lower Splash Shield

• Use a 10mm socket to remove the splash shield bolts.
• Use a plastic trim clip remover to release the plastic clips.
• Set the splash shield aside.
• Keep clips organized.

Step 3: Locate the CVT Drain Plug

• Slide the drain pan under the transmission case.
• The CVT drain plug is at the bottom of the transmission housing.
• Wipe around the drain plug with clean shop towels so dirt does not enter the area.

Step 4: Drain the Old CVT Fluid

• Use a 3/8-inch drive ratchet to loosen and remove the CVT drain plug.
• Let the fluid drain completely into the drain pan.
• Measure the drained fluid using the measuring jug with quart markings.
• Expect roughly 3.5-4 quarts during a normal drain and refill.
• Measuring prevents overfilling.

Step 5: Clean and Reinstall the Drain Plug

• Remove the old crush washer from the drain plug by hand.
• Clean the drain plug with clean shop towels.
• Install the new CVT drain plug crush washer.
• Thread the drain plug in by hand first to avoid cross-threading.
• Use a 3/8-inch drive torque wrench to tighten the drain plug to 49 Nm (36 ft-lbs).

Step 6: Access the CVT Fill Point

• Open the hood.
• Locate the CVT fluid fill plug/dipstick area on top of the transmission.
• Wipe the area clean with clean shop towels before opening it.
• Remove the fill plug or dipstick by hand.

Step 7: Refill with Honda HCF-2 CVT Fluid

• Place the long-neck transmission funnel into the CVT fill opening.
• Pour in the same amount of Honda HCF-2 CVT fluid that drained out.
• Add slowly to prevent spills.
• Do not overfill. Start with the measured amount only.
• Use HCF-2 only.

Step 8: Cycle the Transmission

• Start the engine with the vehicle still safely supported and level.
• Keep your foot firmly on the brake pedal.
• Move the shifter slowly through P-R-N-D-S-L, pausing 3 seconds in each position.
• Return the shifter to Park.
• Let the engine idle for about 1 minute.

Step 9: Check the Fluid Level

• With the vehicle level, engine warm, and transmission in Park, check the CVT fluid level using the factory fill/dipstick check method on your HR-V.
• Use clean shop towels to wipe the dipstick, reinstall it fully, then remove it again to read the level.
• If low, add Honda HCF-2 CVT fluid in small amounts through the long-neck transmission funnel.
• If overfilled, drain a small amount using the 3/8-inch drive ratchet at the drain plug, then retorque to 49 Nm (36 ft-lbs).

Step 10: Reinstall the Splash Shield

• Use the plastic trim clip remover by hand to align the splash shield clips.
• Push the clips back into place.
• Use a 10mm socket to reinstall the splash shield bolts.
• Tighten the small splash shield bolts snugly. Do not overtighten plastic shield hardware.

Step 11: Lower the Vehicle

• Use the floor jack to lift your HR-V slightly off the jack stands.
• Remove the jack stands.
• Lower the vehicle slowly to the ground.
• Remove the wheel chocks.

---

✅ After Repair

• Start the engine and let it idle for 1-2 minutes.
• Check underneath for leaks around the CVT drain plug.
• Take a gentle 10-minute test drive. Avoid hard acceleration at first.
• Recheck for leaks after the test drive.
• Reset the maintenance minder if the CVT fluid service was due: use the steering wheel controls to go to Vehicle Settings > Maintenance Info > Reset.
• Dispose of the old CVT fluid properly at a recycling center or parts store that accepts used oil and transmission fluid.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $55-$95 (parts only)

You Save: $125-$225 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
