🔧 Corolla - CVT Transmission Fluid Change

This repair replaces the CVT fluid in your Corolla’s automatic CVT transmission. Toyota CVTs are sensitive to fluid type and fluid level, so use the correct Toyota CVT FE fluid and follow the temperature-based level check carefully.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface. The fluid level check must be done with your Corolla sitting level.
• ⚠️ Use jack stands. Never work under a vehicle supported only by a jack.
• ⚠️ CVT fluid gets hot. Wear gloves and safety glasses to protect from burns and splashes.
• ⚠️ Use only Toyota CVT FE fluid or approved equivalent. Regular automatic transmission fluid can damage the CVT.
• ⚠️ Do not overfill or underfill. The final level is checked by fluid temperature, not by a dipstick.
• ⚠️ Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 24mm socket
• 6mm hex bit socket
• 3/8-inch ratchet
• Torque wrench 5-50 Nm
• Fluid transfer pump
• Drain pan 8-quart minimum
• OBD2 scan tool with live data
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Toyota CVT FE transmission fluid - Qty: 4-5 quarts
• Transmission drain plug gasket - Qty: 1
• Transmission fill plug gasket - Qty: 1
• Transmission overflow plug gasket - Qty: 1

---

📋 Before You Begin

• Park your Corolla on a flat, level surface.
• Set the parking brake and place wheel chocks behind the rear wheels.
• Let the transmission cool if the vehicle was recently driven.
• Raise the front of the vehicle with a floor jack and support it with jack stands. Keep the vehicle as level as possible.
• An OBD2 scan tool with live data means a scanner that can show the transmission fluid temperature while the engine is running.
• The final fluid level must be checked at about 35-45°C / 95-113°F CVT fluid temperature.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Lower Engine Cover

• Put on safety glasses and nitrile gloves.
• Use a 10mm socket and 3/8-inch ratchet to remove the lower splash shield fasteners.
• Set the cover and fasteners aside in order. Take a phone picture first.

Step 2: Locate the CVT Fill and Drain Plugs

• Use a light and look at the transmission case on the driver side area of the engine bay/underside.
• The fill plug is on the side of the CVT case. The drain plug is at the bottom of the CVT pan area.
• Before draining, always remove the fill plug first. This makes sure you can refill the transmission.

Step 3: Remove the Fill Plug First

• Place the drain pan 8-quart minimum under the transmission area.
• Use a 24mm socket and 3/8-inch ratchet to loosen and remove the CVT fill plug.
• Remove the old fill plug gasket and discard it.
• If the fill plug will not come loose, stop here and do not drain the fluid.

Step 4: Drain the Old CVT Fluid

• Move the drain pan 8-quart minimum directly under the drain plug.
• Use a 6mm hex bit socket and 3/8-inch ratchet to remove the drain plug.
• Let the fluid drain until it slows to a drip.
• Measure the drained fluid amount if possible. This gives you a starting refill amount.

Step 5: Reinstall the Drain Plug

• Install a new transmission drain plug gasket on the drain plug.
• Thread the drain plug in by hand first to avoid cross-threading.
• Use a 6mm hex bit socket and torque wrench 5-50 Nm to tighten the drain plug to Torque to 40 Nm (30 ft-lbs).

Step 6: Add New CVT Fluid

• Use a fluid transfer pump to pump Toyota CVT FE transmission fluid into the fill opening.
• Add about the same amount that drained out, then add a small extra amount to prepare for the overflow level check.
• Do not install the fill plug yet if you are doing the level check immediately.

Step 7: Warm the Fluid to Check Level

• Connect the OBD2 scan tool with live data to the diagnostic port under the driver side dash.
• Start the engine while the vehicle remains safely supported and level.
• With your foot on the brake, slowly move the shifter through P-R-N-D, pausing 2-3 seconds in each position, then return to P.
• Watch CVT fluid temperature on the scan tool.
• The level check range is about 35-45°C / 95-113°F.

Step 8: Set the Correct Fluid Level

• Keep the engine idling.
• Use the 6mm hex bit socket and 3/8-inch ratchet to remove the overflow/check plug if equipped separately from the drain plug assembly.
• If fluid flows out in a steady stream, let it drain until it becomes a thin trickle.
• If no fluid comes out, use the fluid transfer pump to add Toyota CVT FE transmission fluid through the fill hole until fluid starts to trickle from the overflow/check port.
• When the fluid is a thin trickle at 35-45°C / 95-113°F, the level is correct.

Step 9: Reinstall the Overflow and Fill Plugs

• Install a new transmission overflow plug gasket if your Corolla uses a separate overflow plug gasket.
• Use the 6mm hex bit socket and torque wrench 5-50 Nm to tighten the overflow/check plug to Torque to 20 Nm (15 ft-lbs).
• Install a new transmission fill plug gasket on the fill plug.
• Use the 24mm socket and torque wrench 5-50 Nm to tighten the fill plug to Torque to 49 Nm (36 ft-lbs).

Step 10: Reinstall the Lower Engine Cover

• Wipe spilled fluid with shop towels.
• Use a 10mm socket and 3/8-inch ratchet to reinstall the lower splash shield.
• Lower your Corolla carefully using the floor jack rated 2-ton minimum after removing the jack stands rated 2-ton minimum.

---

✅ After Repair

• Start the engine and let it idle. Check underneath for leaks.
• Test drive gently for 10-15 minutes. Avoid hard acceleration at first.
• Recheck for leaks around the drain, overflow, and fill plugs.
• No battery registration, programming, or infotainment reset is required.
• If the transmission slips, shudders, or has a warning light after service, stop driving and recheck the fluid level with scan-tool temperature.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$380 parts + labor

DIY Cost: $70-$130 parts only

You Save: $150-$250 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
