🔧 Civic - CVT Transmission Fluid Replacement

This procedure replaces the CVT fluid in your Civic to help maintain smooth shifting, proper belt lubrication, and transmission cooling. Your Civic EX uses Honda CVT fluid, not regular automatic transmission fluid.

Difficulty Level: Beginner-Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool or mildly warm vehicle. Hot transmission fluid can burn skin.
• ⚠️ Keep the Civic level while draining and refilling so the fluid amount is accurate.
• ⚠️ Never use regular ATF. Use only Honda HCF-2 CVT fluid or an equivalent fluid specifically approved for Honda CVTs.
• ⚠️ Always support the vehicle with jack stands. Never work under a vehicle held only by a jack.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 3/8-inch drive ratchet
• 3/8-inch drive extension
• 10mm socket
• Phillips screwdriver
• Flat trim clip remover
• Torque wrench 3/8-inch drive
• Fluid drain pan 6-quart minimum
• Long-neck funnel
• Measuring container 5-quart minimum
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Honda HCF-2 CVT fluid - Qty: 4 quarts
• Transmission drain plug crush washer - Qty: 1
• Replacement splash shield clips - Qty: As needed

---

📋 Before You Begin

• Park your Civic on level ground.
• Apply the parking brake and place wheel chocks behind the rear wheels.
• Let the vehicle cool until the transmission case is safe to touch.
• A crush washer is a soft sealing washer that gets squeezed when tightened. Replace it every time to prevent leaks.
• A CVT is a continuously variable transmission. It uses special fluid and must not be filled with standard automatic transmission fluid.
• No infotainment menu, scan tool, battery registration, EPB retraction, ADAS calibration, or HV isolation is required for this service.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and Secure the Front of the Civic

• Use the floor jack rated 2-ton minimum at the front center jacking point.
• Place jack stands rated 2-ton minimum under the proper front support points.
• Lower the Civic gently onto the jack stands.
• Use safety glasses and nitrile gloves before going underneath.
• Shake gently to confirm stability.

Step 2: Remove the Lower Splash Shield

• Use a 10mm socket to remove the splash shield bolts.
• Use a Phillips screwdriver to loosen any screw-style retainers.
• Use a flat trim clip remover to remove plastic clips without breaking them.
• Set the splash shield and fasteners aside in order.

Step 3: Locate the CVT Drain Plug

• Look at the lower side of the transmission case on the driver-side area.
• The CVT drain plug has a square 3/8-inch drive opening.
• Place the fluid drain pan 6-quart minimum directly under the drain plug.
• Wipe the area with shop towels so dirt does not enter the transmission.

Step 4: Remove the Drain Plug

• Insert the 3/8-inch drive ratchet directly into the square drain plug opening.
• Turn counterclockwise slowly to loosen the drain plug.
• Remove the plug by hand once loose and let the fluid drain completely.
• Use nitrile gloves because the fluid can irritate skin.
• Do not rush the draining.

Step 5: Inspect and Clean the Drain Plug

• Use shop towels to clean the drain plug.
• The drain plug has a magnet that collects fine metal dust. A light gray paste is normal.
• Large metal chunks or shiny flakes are not normal and may indicate internal transmission wear.
• Remove the old crush washer from the drain plug by hand.
• Install the new transmission drain plug crush washer.

Step 6: Reinstall the Drain Plug

• Thread the drain plug in by hand first to avoid cross-threading.
• Use the 3/8-inch drive ratchet to snug it gently.
• Use the torque wrench 3/8-inch drive to tighten the drain plug to Torque to 49 Nm (36 ft-lbs).
• Wipe the area clean with shop towels.

Step 7: Measure the Old Fluid

• Carefully pour the used fluid from the fluid drain pan 6-quart minimum into the measuring container 5-quart minimum.
• Measure how much fluid came out.
• Plan to refill with the same amount first, usually about 3.5-4 quarts for a drain-and-fill.
• Measuring prevents overfilling.

Step 8: Lower the Civic to Level Ground

• Use the floor jack rated 2-ton minimum to lift slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower the Civic fully to level ground.
• Keep the wheel chocks in place.

Step 9: Fill the CVT Fluid

• Open the hood and locate the CVT fill tube/dipstick area near the transmission.
• Use the long-neck funnel in the fill tube.
• Pour in Honda HCF-2 CVT fluid slowly.
• Add the same amount you measured from the old fluid first.
• Do not overfill. Add in small amounts if needed.

Step 10: Circulate the New Fluid

• Start the engine with your foot on the brake.
• Move the shifter slowly through P-R-N-D-S-L, pausing about 3 seconds in each position if equipped.
• Return the shifter to P.
• Let the engine idle for a short time.
• Use safety glasses while checking around the vehicle for leaks.

Step 11: Check Fluid Level

• Park on level ground with the engine warm.
• Remove the dipstick, wipe it with shop towels, reinstall it fully, then remove it again.
• The fluid should be within the marked range on the dipstick.
• If low, use the long-neck funnel to add Honda HCF-2 CVT fluid in small amounts.
• If overfilled, drain a small amount using the 3/8-inch drive ratchet at the drain plug, then recheck.

Step 12: Reinstall the Lower Splash Shield

• Raise the front slightly again with the floor jack rated 2-ton minimum if more access is needed.
• Support it again with jack stands rated 2-ton minimum.
• Position the splash shield by hand.
• Use the flat trim clip remover only if you need to align or replace clips.
• Use the Phillips screwdriver to reinstall screw-style retainers.
• Use the 10mm socket to reinstall splash shield bolts snugly.
• Do not overtighten plastic shield fasteners.

---

✅ After Repair

• Start the Civic and check under the transmission for leaks.
• Take a gentle 10-15 minute test drive.
• Confirm smooth takeoff, steady acceleration, and no warning lights.
• Recheck the drain plug area after the test drive.
• Recheck fluid level on level ground after the transmission is warm.
• Dispose of used CVT fluid at a local oil recycling center or service shop.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$300 (parts + labor)

DIY Cost: $45-$90 (parts only)

You Save: $135-$210 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.2 hours.

---
