🔧 TITAN XD - Radiator Hose Replacement

Replacing a radiator hose stops coolant leaks and prevents overheating. You’ll remove the old hose, clean the fittings, install the new hose with fresh clamps, then refill and bleed the cooling system.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.5 hours

Assumption: covering both upper and lower radiator hoses.

---

⚠️ Safety & Precautions

• ⚠️ Never open the radiator cap on a hot engine; coolant can spray and burn.
• ⚠️ Support the truck with jack stands before working underneath; never rely on a jack.
• ⚠️ Coolant is toxic to people and pets—catch every drop and dispose properly.
• ⚠️ Keep hands clear of the fan and belts if the engine is running.
• 🔋 Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 3-gallon)
• Spill-free funnel kit
• Pliers
• Hose clamp pliers (specialty)
• Pick tool
• Flathead screwdriver
• 10mm socket
• 12mm socket
• 3/8" drive ratchet
• 3/8" drive extension (6")
• Torque wrench (3/8" drive)
• Trim clip removal tool
• Shop towels
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Radiator hose clamps - Qty: 4
• Nissan Long Life Antifreeze/Coolant (blue) 50/50 premix - Qty: 3-4 gallons
• Distilled water - Qty: 1 gallon

---

📋 Before You Begin

• Park on level ground, set the parking brake, and let the engine cool fully.
• Put wheel chocks behind the rear tires.
• Set your drain pan under the radiator area before loosening anything.
• If you need access to the lower hose from underneath, raise the front with a floor jack and support with jack stands.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove any lower splash shield (if equipped)

• Use a trim clip removal tool to pop out plastic clips.
• Use a 10mm socket and 3/8" drive ratchet to remove small bolts.
• Reinstall later and Torque to 7 Nm (62 in-lbs).

Step 2: Relieve cooling system pressure

• With the engine cold, place a shop towel over the radiator cap.
• Slowly loosen the cap to the first stop to release any leftover pressure, then remove it.

Step 3: Drain enough coolant to drop the level below the hose

• Place the drain pan under the radiator drain area.
• Open the drain slowly (use a flathead screwdriver only if your drain design requires it).
• Drain until the coolant level is below the hose you’re replacing, then close the drain.

Step 4: Remove the upper radiator hose (radiator to engine)

• Use hose clamp pliers (specialty) to compress the spring clamp, then slide it back on the hose.
• If you have a screw-type clamp, loosen it with a flathead screwdriver.
• Twist the hose to break it free, then pull it off. Use a pick tool to gently lift the hose edge if it’s stuck (don’t gouge the radiator neck).

Step 5: Remove the lower radiator hose (radiator to water pump/engine)

• Use a flashlight to locate both ends of the lower hose.
• Use hose clamp pliers (specialty) or a flathead screwdriver (depending on clamp type) to release both clamps.
• Expect more coolant to drain when the lower hose comes off—keep the drain pan positioned under the connection.

Step 6: Clean and inspect the hose fittings

• Wipe the radiator neck and engine fittings with shop towels until clean and dry.
• Make sure old rubber isn’t stuck to the metal/plastic neck.
• Clean sealing surfaces prevent slow leaks.

Step 7: Install the new hose(s) and clamps

• Slide new clamps onto the new hose before installing the hose.
• Push the hose on until it bottoms out against the stop/bead on the fitting.
• Position the clamp behind the bead, then release/tighten it:
  • Spring clamp: release using hose clamp pliers (specialty).
  • Screw clamp: tighten with a flathead screwdriver (snug, do not crush the neck).

Step 8: Refill coolant

• Install a spill-free funnel kit at the radiator fill neck.
• Pour in Nissan Long Life Antifreeze/Coolant (blue) 50/50 premix slowly.
• Fill the overflow reservoir to the “MAX” line.

Step 9: Bleed air from the cooling system

• Set the cabin heat to hottest and fan to medium (this opens the heater core to help purge air).
• Start the engine and let it idle while watching the funnel level.
• As the engine warms up, add coolant as the level drops. Squeeze the upper hose gently (with gloves) to help push trapped air out.
• When you see steady heat from the vents and fewer bubbles, shut the engine off and let it cool completely.

Step 10: Final top-off and recheck for leaks

• After a full cool-down, remove the funnel and install the radiator cap.
• Top off the reservoir if needed.
• Clean any spilled coolant with shop towels and recheck both hose ends for seepage.

---

✅ After Repair

• Let the engine reach normal temperature and confirm the heater blows hot.
• Check for leaks with the engine running, then again after a test drive.
• Recheck the reservoir level the next morning (cold engine) and top off if needed.
• If the temperature gauge rises higher than normal, stop driving and recheck for air in the system.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $190-$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
