🔧 Terrain - Radiator Hose Replacement

Replacing a radiator hose stops coolant leaks and prevents overheating. On your Terrain, you’ll typically replace the upper hose (top of radiator) and/or lower hose (bottom of radiator) and then refill/bleed the cooling system through the surge tank.

Difficulty Level: Intermediate | Estimated Time: 1.5–3 hours

Assumption: replacing both upper and lower radiator hoses.

---

⚠️ Safety & Precautions

• Never open the surge tank cap on a hot engine—hot coolant can spray and burn you.
• Support the vehicle with jack stands if you lift it—never rely on a floor jack alone.
• Keep coolant off paint and away from kids/pets; it’s toxic and slippery.
• Let the engine cool fully (radiator hoses should feel cool to the touch).
• Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 3-gallon)
• Funnel
• Pliers
• Hose clamp pliers (specialty)
• Pick tool or hose removal hook (specialty)
• Flathead screwdriver
• 7mm socket
• 8mm socket
• 10mm socket
• 1/4" ratchet
• 3/8" ratchet
• 6" extension
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Hose clamps - Qty: 2-4
• DEX-COOL coolant (50/50 premix) - Qty: 2-3 gallons
• Distilled water - Qty: 1 gallon

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool completely.
• Set the HVAC to full heat later during bleeding (this helps move coolant through the heater core).
• If you lift the front end for access, use a floor jack and support with jack stands at the proper lift points.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve cooling system pressure safely

• Put on safety glasses and nitrile gloves.
• Slowly loosen the surge tank cap (coolant reservoir cap) by hand to release any leftover pressure, then remove it.

Step 2: Raise the front (optional but helpful)

• Place wheel chocks behind the rear tires.
• Lift the front with a floor jack (rated 3-ton minimum) and support with jack stands (rated 3-ton minimum).

Step 3: Drain enough coolant to get below hose level

• Position a drain pan (at least 3-gallon) under the lower right (passenger-side) area of the radiator.
• Use a flathead screwdriver to open the radiator drain (petcock) if equipped; otherwise, you’ll drain from the lower hose connection in a later step.
• Drain until the level is below the lower hose area, then close the drain by hand (snug only).

Step 4: Remove the air intake ducting for access (if needed)

• Use a 7mm socket or 8mm socket with a 1/4" ratchet to loosen the hose clamps on the intake duct.
• Disconnect the duct and move it aside to improve access to the upper hose connections.

Step 5: Remove the upper radiator hose

• Place shop towels under the hose connections to catch drips.
• If your Terrain uses spring clamps, compress them with hose clamp pliers (specialty) and slide the clamp back on the hose.
• If it has screw clamps, loosen them with a 7mm socket or 8mm socket.
• Twist the hose to break it free, then pull it off the radiator neck and the engine-side outlet.
• If it’s stuck, use a pick tool or hose removal hook (specialty) carefully to lift the hose edge. A hose hook is a small curved tool used to separate a stuck hose from a fitting without tearing the fitting.

Step 6: Remove the lower radiator hose

• Reposition the drain pan (at least 3-gallon) directly under the lower hose because more coolant will spill.
• Move the clamp back using hose clamp pliers (specialty) (spring clamp) or loosen with a 7mm socket/8mm socket (screw clamp).
• Twist and pull the hose off the radiator and off the engine-side connection.
• Tip: twist first, then pull.

Step 7: Prep the fittings and compare parts

• Wipe the radiator necks and engine outlets clean with shop towels.
• Compare the new hoses to the old hoses (shape, length, bend angles, and quick-connector ends if equipped).
• Install new clamps onto the hoses if your replacements do not reuse the originals.

Step 8: Install the new lower radiator hose

• Push the hose fully onto both fittings until it seats against the stop/bead.
• Position the clamp in the same area as factory (usually just behind the raised bead on the fitting), then release/tighten it using hose clamp pliers (specialty) or a 7mm socket/8mm socket.
• Make sure the hose is not rubbing the fan shroud, belt area, or sharp edges.

Step 9: Install the new upper radiator hose

• Route the hose exactly like the original to avoid kinks.
• Push it fully onto the radiator and engine outlet, then secure clamps using hose clamp pliers (specialty) or a 7mm socket/8mm socket.

Step 10: Reinstall the intake ducting

• Reinstall the intake duct and tighten clamps using a 7mm socket or 8mm socket with a 1/4" ratchet.
• If any brackets/fasteners were removed, reinstall using a 10mm socket with a 3/8" ratchet and 6" extension.

Step 11: Refill coolant through the surge tank

• Make sure the drain is closed and both hoses are clamped.
• Use a funnel and fill the surge tank with DEX-COOL coolant (50/50 premix) to the cold fill line.
• If you used concentrate coolant, mix with distilled water to a 50/50 blend before filling.

Step 12: Bleed air and verify heat

• Start the engine and let it idle with the surge tank cap off.
• Set the HVAC to maximum heat and medium fan.
• Watch the coolant level; add DEX-COOL coolant (50/50 premix) as the level drops.
• When the upper hose gets hot, the thermostat has opened and coolant is flowing.
• Once bubbles reduce and the level stabilizes, install the surge tank cap hand-tight.

Step 13: Lower the vehicle and final leak check

• Turn the engine off and inspect both hose connections with a flashlight (use shop towels to feel for wetness).
• If raised, lift slightly with the floor jack (rated 3-ton minimum), remove jack stands (rated 3-ton minimum), and lower the vehicle.

---

✅ After Repair

• Road test 10–15 minutes while watching the temperature gauge.
• Verify the heater blows hot at idle and while driving.
• After the engine cools completely, recheck the surge tank level and top off to the cold line.
• Inspect again for seepage around the clamps the next day.

---

💰 DIY vs Shop Cost

Shop Cost: $250–$550 (parts + labor)

DIY Cost: $60–$180 (parts only)

You Save: $190–$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5–2.5 hours.

---
