🔧 QX60 - Radiator Hose Replacement

Replacing a radiator hose means draining some coolant, removing the old hose and clamps, then installing a new hose and refilling/bleeding the cooling system. This fixes leaks, prevents overheating, and avoids a roadside hose burst.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.5 hours

Assumption: I’m covering both upper and lower radiator hoses (your steps match whichever hose you’re replacing).

---

⚠️ Safety & Precautions

• ⚠️ Never open the radiator cap on a hot engine; hot coolant can spray and burn you.
• ⚠️ Support the vehicle with jack stands if you lift it—never rely on a jack alone.
• ⚠️ Keep coolant off belts/alternator; wipe spills immediately.
• ⚠️ Coolant is toxic to people and pets—use a drain pan and sealed containers.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Phillips screwdriver
• Flat-blade screwdriver
• 8mm socket
• 10mm socket
• 1/4" ratchet
• 3" extension
• Hose clamp pliers
• Pick tool (small hook pick)
• Trim clip removal tool
• Funnel
• Spill-free coolant funnel kit (specialty)
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Radiator hose clamps - Qty: 2-4
• Long-life engine coolant (blue, premixed 50/50) - Qty: 1-2 gallons

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool fully (radiator hoses should feel cool to the touch).
• Set the heater inside the cabin to HOT (this helps purge air later).
• If you need access from below for the lower hose, raise the front with a floor jack and support with jack stands.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve pressure safely

• Put on safety glasses and nitrile gloves.
• Place a shop towel over the radiator cap, then slowly loosen it to the first stop to vent any leftover pressure.
• If you hear hissing, pause until it stops, then remove the cap fully.

Step 2: Drain coolant to below hose level

• Position a drain pan (10-quart minimum) under the radiator drain area.
• Use a flat-blade screwdriver (or by hand if it’s a wing-style) to open the radiator drain cock slowly and drain coolant.
• Drain until the level is below the hose you’re replacing (usually a few quarts), then close the drain cock snugly (do not overtighten).

Step 3: Remove covers/ducting for access

• If equipped, remove the top engine cover by pulling upward firmly (it’s held by rubber grommets).
• If the air intake duct blocks access, loosen the clamps with an 8mm socket and remove any clips using a trim clip removal tool, then lift the duct out.

Step 4: Remove the old hose clamps

• For spring clamps: squeeze the clamp ears with hose clamp pliers and slide the clamp back onto the hose.
• For worm-gear clamps: loosen with an 8mm socket or flat-blade screwdriver, then slide the clamp back.
• Tip: Take a quick photo before removal.

Step 5: Break the hose free (don’t damage the radiator neck)

• Twist the hose gently by hand to break the seal.
• If it’s stuck, slide a pick tool (small hook pick) under the hose end to let a little air in, then twist again.
• Pull the hose straight off the fitting.

Step 6: Clean and inspect the fittings

• Use shop towels to wipe the radiator neck and engine-side fitting clean.
• Check for cracks, heavy corrosion, or a damaged “bead” (the raised lip that helps hold the hose). If damaged, fix that before installing a new hose.

Step 7: Install the new hose and clamps

• Pre-position the new clamps on the new hose.
• Push the hose fully onto each fitting until it seats against the stop/bead.
• Reposition clamps:
  • Spring clamp: use hose clamp pliers to place it over the sealing area (near the end of the hose, not hanging off).
  • Worm clamp: tighten with an 8mm socket until snug; do not crush the plastic neck.

Step 8: Reinstall intake ducting/covers

• Reinstall the intake duct and tighten clamps using an 8mm socket.
• Reinstall any 10mm bolts removed using a 10mm socket.
• Press the engine cover back into the grommets.

Step 9: Refill coolant

• Insert a spill-free coolant funnel kit (specialty) into the radiator fill neck (this is a funnel that seals and helps burp air).
• Slowly add long-life engine coolant (blue, premixed 50/50) until full.
• Fill the overflow reservoir to the MAX line using a funnel.

Step 10: Bleed air from the cooling system

• Start the engine and let it idle with the radiator cap still off (funnel installed).
• Set the heater to HOT and fan to medium.
• Watch the funnel: as the thermostat opens, coolant level may drop—add coolant as needed.
• Gently squeeze the upper radiator hose a few times (with gloves) to encourage trapped air out.
• When bubbles stop and heat blows hot from vents, shut the engine off and let it cool, then top off and install the radiator cap.

---

✅ After Repair

• Start the engine and inspect both ends of the new hose for seepage.
• Test drive 10–15 minutes, then recheck for leaks.
• After the engine cools completely, recheck coolant level in the overflow tank and top off to MAX if needed.
• Dispose of old coolant properly (sealed container; take to a recycling center).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $45-$160 (parts only)

You Save: $205-$390 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
