🔧 Odyssey - Water Pump Replacement

On your Odyssey, the water pump is driven by the timing belt, so replacing the pump requires removing the timing belt and front timing covers. Because a mistake here can cause serious engine damage, this is a careful, step-by-step job with strict timing-mark alignment.

Difficulty Level: Advanced | Estimated Time: 5-8 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the engine before removing the right-side engine mount.
• ⚠️ Work only on a cold engine; hot coolant can burn you.
• ⚠️ Do not rotate the crankshaft/camshafts with the timing belt removed unless instructed.
• ⚠️ Keep fingers/tools clear when releasing the timing belt tensioner.
• ⚠️ Battery disconnect is recommended to prevent accidental starts.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (10-liter minimum)
• Funnel
• Trim clip remover
• 8mm socket
• 10mm socket
• 12mm socket
• 14mm socket
• 17mm socket
• 19mm socket
• 22mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (10-250 Nm range)
• Serpentine belt tool 14mm
• Honda crank pulley holding tool (specialty)
• Small flat plastic scraper
• Shop rags
• Paint marker
• Needle-nose pliers

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Water pump - Qty: 1
• Water pump gasket/O-ring - Qty: 1
• Timing belt - Qty: 1
• Timing belt tensioner - Qty: 1
• Timing belt idler pulley set - Qty: 1
• Serpentine/accessory drive belt - Qty: 1
• Engine coolant (Honda Type 2 / 50-50 premix) - Qty: 2-3 gallons
• Crankshaft pulley bolt - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool completely.
• Disconnect the battery negative terminal using a 10mm socket.
• Raise the front and support it securely on jack stands (rated 3-ton minimum).
• Remove the right-front wheel using a 19mm socket.
• Remove the right-front inner fender/splash shield using a trim clip remover and 10mm socket.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Drain the coolant

• Place a drain pan (10-liter minimum) under the radiator drain.
• Open the radiator cap slowly (only when cool).
• Open the drain cock and drain coolant. Use needle-nose pliers if needed for the drain hose clamp.

Step 2: Remove the serpentine belt

• Rotate the belt tensioner with a serpentine belt tool 14mm and slip the belt off.
• Take a quick belt-routing photo.

Step 3: Support the engine and remove the right engine mount

• Position a floor jack (rated 3-ton minimum) under the oil pan with a block of wood (wood spreads the load).
• Apply light upward pressure to support the engine.
• Remove the right engine mount fasteners using a 14mm socket and 17mm socket.
• Remove the mount and bracket as needed for access.

Step 4: Remove the crankshaft pulley

• Install the Honda crank pulley holding tool (specialty) to hold the pulley.
• Remove the crank pulley bolt using a 22mm socket and 1/2" drive breaker bar.
• Remove the crank pulley.
• Torque to 245 Nm (181 ft-lbs) during reassembly (use a new bolt).

Step 5: Remove the timing covers

• Remove the upper and lower timing belt covers using an 8mm socket and 10mm socket.
• Keep bolts organized by cover location.

Step 6: Set engine to TDC on cylinder #1

• Rotate the crankshaft clockwise using a 22mm socket and 1/2" drive ratchet until timing marks align.
• Use a paint marker to mark the belt and sprockets for reference.
• Only rotate clockwise.

Step 7: Release tension and remove the timing belt

• Remove the timing belt tensioner bolts using a 12mm socket.
• Remove the tensioner and then remove the timing belt.
• Torque to 44 Nm (33 ft-lbs) for the tensioner mounting bolts during reassembly.

Step 8: Remove the water pump

• Place shop rags under the pump area to catch remaining coolant.
• Remove the water pump bolts using a 10mm socket.
• Remove the water pump and gasket/O-ring.

Step 9: Clean the sealing surface

• Clean the engine mating surface using a small flat plastic scraper and shop rags.
• Do not gouge the aluminum surface.

Step 10: Install the new water pump

• Install the new gasket/O-ring on the new pump.
• Install the pump and hand-start all bolts.
• Tighten evenly using a 10mm socket and finish with a torque wrench (10-250 Nm range).
• Torque to 12 Nm (9 ft-lbs) for water pump bolts.

Step 11: Replace idlers and re-install the timing belt

• Replace the idler pulleys using a 14mm socket and torque wrench (10-250 Nm range).
• Torque to 54 Nm (40 ft-lbs) for idler pulley bolt(s).
• Route the new timing belt, keeping timing marks perfectly aligned.
• Install the new tensioner using a 12mm socket.
• Pull the tensioner pin (if equipped) only after the belt is fully seated.

Step 12: Verify timing

• Rotate the crankshaft clockwise two full revolutions using a 22mm socket.
• Re-check that all timing marks line up exactly.
• If marks are off, remove the belt and correct it before proceeding.

Step 13: Reassemble covers, mount, and belts

• Reinstall timing covers using an 8mm socket and 10mm socket.
• Reinstall the crank pulley and install a new crank bolt.
• Hold the pulley with the Honda crank pulley holding tool (specialty) and torque the crank bolt to 245 Nm (181 ft-lbs) using a torque wrench (10-250 Nm range).
• Reinstall the right engine mount using a 14mm socket and 17mm socket.
• Reinstall the serpentine belt using a serpentine belt tool 14mm.
• Reinstall splash shield using a trim clip remover and 10mm socket.
• Reinstall wheel using a 19mm socket and torque lug nuts to 127 Nm (94 ft-lbs).

Step 14: Refill and bleed the cooling system

• Close the drain cock.
• Refill with Engine coolant (Honda Type 2 / 50-50 premix) using a funnel.
• Reconnect the battery negative terminal using a 10mm socket.
• Start the engine and set heat to HOT; let it reach operating temp while watching the temperature gauge.
• Top off coolant as air purges, then install the cap.
• Check for leaks around the water pump area.

---

✅ After Repair

• Recheck coolant level after the first full heat cycle and again the next morning (cold).
• Inspect for coolant drips under the right-front area after a short drive.
• Listen for abnormal belt noises; shut down if squealing/grinding starts.

---

💰 DIY vs Shop Cost

Shop Cost: $900-$1,500 (parts + labor)

DIY Cost: $180-$450 (parts only)

You Save: $720-$1,050 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 5-8 hours.

---
