🔧 Grand Cherokee - Water Pump Replacement

The water pump circulates coolant through your engine and radiator. On your Grand Cherokee, replacing it involves draining coolant, removing the drive belt and front-access components, swapping the pump and gasket, then refilling and bleeding the cooling system.

Difficulty Level: Intermediate | Estimated Time: 3-5 hours

Assumption: Torque specs below are typical for the 5.7L HEMI—verify with OEM service info if available.

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap hot; let the engine cool fully.
• ⚠️ Electric cooling fan can turn on unexpectedly—disconnect the battery negative cable before working near the fan.
• ⚠️ Support the vehicle with jack stands if you raise it; never rely on a jack.
• ⚠️ Coolant is toxic—catch it in a drain pan and clean spills immediately.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 3-gallon)
• Funnel
• 3/8" drive ratchet
• 3/8" drive extension set
• Torque wrench (3/8" drive, 10-100 ft-lbs range)
• 8mm socket
• 10mm socket
• 13mm socket
• 15mm socket
• Flat-blade screwdriver
• Trim clip removal tool
• Hose clamp pliers
• Gasket scraper
• Shop rags
• Coolant vacuum fill tool (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Water pump - Qty: 1
• Water pump gasket / seal - Qty: 1
• Engine coolant (Mopar OAT, MS.90032 compatible) - Qty: 2-3 gallons premix
• Serpentine belt - Qty: 1 (optional, if cracked or glazed)
• Hose clamps - Qty: 2 (optional, if original clamps are weak)

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear tires.
• Let the engine cool completely (cold radiator hose to the touch).
• Disconnect the battery using a 10mm socket and remove the negative (-) cable.
• Place a drain pan under the radiator area.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Drain the coolant

• Place the drain pan (at least 3-gallon) under the radiator drain area.
• Slowly loosen the coolant reservoir cap by hand to relieve any leftover pressure.
• Open the radiator drain (petcock) if accessible; use a flat-blade screwdriver if needed.
• If you can’t access the petcock, remove the lower radiator hose using hose clamp pliers and aim it into the drain pan.

Step 2: Remove the upper covers and intake ducting (as needed for access)

• Remove the engine cover (pull upward by hand if equipped).
• Loosen intake duct clamps using a flat-blade screwdriver (or 8mm socket if worm-gear clamps).
• Remove any plastic push pins with a trim clip removal tool and move ducting out of the way.

Step 3: Remove the cooling fan assembly (for working room)

• Unplug the fan electrical connector(s) by hand (press the lock tab first).
• Remove the fan shroud/assembly fasteners using a 10mm socket.
• Lift the fan assembly straight up and out carefully.
• Tip: Protect the radiator fins from bumps.
• If any fasteners are removed: Torque to 10 Nm (89 in-lbs)

Step 4: Release tension and remove the serpentine belt

• Rotate the belt tensioner using a 15mm socket on the tensioner bolt.
• Slide the belt off one pulley and slowly release the tensioner.
• Remove the belt and set it aside; take a photo of belt routing first.

Step 5: Remove hoses from the water pump

• Use hose clamp pliers to move the clamps back on the hose.
• Twist the hose gently to break it free, then pull it off the pump.
• Catch remaining coolant with the drain pan.
• Tip: A stuck hose twists easier than it pulls.

Step 6: Remove the water pump mounting bolts

• Remove the water pump bolts using a 10mm socket and/or 13mm socket (bolt heads can vary by pump design).
• Keep bolts organized by length and location on a piece of cardboard.
• Remove the pump from the front cover; if stuck, tap gently by hand—do not pry into sealing surfaces.

Step 7: Clean the sealing surface

• Use a gasket scraper to remove old gasket material from the engine sealing surface.
• Wipe clean with shop rags until dry and smooth.
• Do not gouge the aluminum surface—light pressure only.

Step 8: Install the new water pump and gasket

• Install the new gasket/seal onto the new pump (match orientation exactly).
• Position the pump and hand-start all bolts to avoid cross-threading.
• Tighten bolts evenly in a crisscross pattern using a 10mm socket/13mm socket.
• Final tighten with a torque wrench: Torque to 40 Nm (30 ft-lbs)

Step 9: Reinstall hoses, belt, and fan assembly

• Reinstall coolant hoses and position clamps with hose clamp pliers.
• Route the serpentine belt and apply tension with a 15mm socket on the tensioner.
• Reinstall the fan assembly and fasteners using a 10mm socket.
• Reconnect the fan electrical connector(s) by hand until they click.
• Fan fasteners: Torque to 10 Nm (89 in-lbs)

Step 10: Reconnect battery and refill coolant

• Reconnect the negative battery cable using a 10mm socket.
• Refill with Engine coolant (Mopar OAT, MS.90032 compatible) using a funnel.
• If using a coolant vacuum fill tool (specialty), follow tool instructions to reduce air pockets.

Step 11: Bleed air and verify operation

• Start the engine and set the heater to HOT with the fan on medium.
• Let it reach operating temperature while watching for leaks.
• Shut off, let cool, and top off the reservoir as needed.
• Tip: Don’t overfill; coolant expands hot.

---

✅ After Repair

• Check for leaks around the pump and hose connections with the engine running and after shutdown.
• Verify the heater blows hot (good sign coolant is circulating).
• Monitor the temperature gauge on your first test drive; stop if it overheats.
• Recheck coolant level the next morning (engine cold) and top off if needed.

---

💰 DIY vs Shop Cost

Shop Cost: $700-$1,200 (parts + labor)

DIY Cost: $160-$350 (parts only)

You Save: $540-$850 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
