🔧 Explorer - Water Pump Replacement

On your Explorer’s 3.5L V6, the water pump is mounted behind the front (timing) cover and is driven by the timing chain. That means replacing it is a major tear-down: coolant must be drained, the front cover and timing components must be removed, then the pump and seals are replaced.

Difficulty Level: Advanced | Estimated Time: 8-12 hours

Assumption: Stock 3.5L NA (non-turbo) timing-chain-driven internal water pump.

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool fully before opening the cooling system; hot coolant can burn.
• ⚠️ Disconnect the negative battery cable to prevent accidental starts and short circuits.
• ⚠️ Support the vehicle with jack stands on solid ground; never rely on a jack alone.
• ⚠️ You must keep cam/crank timing correct; wrong timing can cause severe engine damage.
• ⚠️ Many front-cover/crank fasteners are “torque-to-yield” (TTY), meaning they stretch and should be replaced after removal.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 1/4" drive ratchet
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (10-100 Nm range)
• Torque angle gauge (specialty)
• Socket set (8mm-21mm)
• Deep socket set (10mm-19mm)
• Torx bit set (T20-T55)
• External Torx socket set (E8-E14)
• Serpentine belt tool (3/8" drive)
• Harmonic balancer puller (specialty)
• Ford 3.5L Ti-VCT timing tool kit (specialty)
• Engine support bar (specialty)
• Trim clip removal tool
• Pry bar (12-18")
• Gasket scraper (plastic)
• Brake cleaner spray
• Shop rags
• Funnel
• Cooling system vacuum fill tool (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Water pump - Qty: 1
• Water pump O-ring / seal - Qty: 1
• Front cover gasket set - Qty: 1
• Front crankshaft seal - Qty: 1
• Engine coolant (Motorcraft Yellow or equivalent, pre-mixed 50/50) - Qty: 3-4 gallons
• RTV silicone sealant (OEM-approved) - Qty: 1
• Serpentine belt - Qty: 1
• Crankshaft pulley bolt (TTY) - Qty: 1
• Front cover bolts (TTY where applicable) - Qty: 1 set
• Engine oil - Qty: 6 quarts
• Oil filter - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Disconnect the battery using a 10mm socket (negative terminal first).
• Raise the front and support it on jack stands; remove the right-front wheel with a 19mm socket.
• Plan to keep bolts organized by location; a cardboard “bolt map” works great.
• Have the Ford 3.5L Ti-VCT timing tool kit (specialty) ready; it locks the cams/crank so timing stays correct.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Drain coolant

• Place a drain pan (10-quart minimum) under the radiator drain.
• Open the drain and remove the coolant cap to speed draining.
• Dispose of old coolant properly; it’s toxic to people and pets.

Step 2: Remove the intake ducting and upper covers

• Loosen hose clamps with a 8mm socket and remove the air inlet duct.
• Remove any engine appearance covers using a 10mm socket.

Step 3: Remove the splash shields to access the crank pulley area

• Remove the right-front inner fender liner fasteners with a trim clip removal tool and 7mm socket.
• Remove the lower splash shield fasteners with a 8mm socket.

Step 4: Remove the serpentine belt

• Rotate the belt tensioner using a serpentine belt tool (3/8" drive) and slide the belt off.
• Take a quick photo of belt routing.

Step 5: Support the engine and remove the right engine mount

• Install an engine support bar (specialty) across the strut towers and tension it lightly.
• Remove the right engine mount fasteners using a socket set (15mm-18mm) and 3/8" drive ratchet.
• This creates room to remove the front cover area components.

Step 6: Remove accessory brackets/pulleys blocking the front cover

• Remove any front accessory brackets and pulleys that block the timing cover using a socket set (10mm-15mm) and Torx bit set (T30-T50).
• Set parts aside in order so they go back the same way.

Step 7: Remove the crankshaft pulley (harmonic balancer)

• Remove the crank bolt using a 1/2" drive breaker bar and appropriate socket (typically 18mm or 21mm).
• Use a harmonic balancer puller (specialty) to pull the crank pulley off straight.
• Do not pry against the timing cover sealing surface.

Step 8: Set the engine to timing position and lock it

• Rotate the engine by hand at the crank using a socket and 1/2" drive breaker bar until it’s at the correct timing/index position.
• Install the Ford 3.5L Ti-VCT timing tool kit (specialty) to lock the camshafts and crankshaft.
• A “timing tool” is a set of fixtures that hold the engine in the correct position so the chain can be removed and reinstalled safely.

Step 9: Remove the front (timing) cover

• Remove timing cover fasteners using an external Torx socket set (E8-E14) and socket set (10mm-13mm).
• Gently separate the cover using a pry bar (12-18") only at approved pry points.
• Clean old RTV from the cover and block using a plastic gasket scraper and brake cleaner spray.

Step 10: Remove timing components as needed to access the water pump

• Relieve chain tensioners and remove the chain guides as required using a socket set and Torx bit set.
• Keep parts in order (left/right/upper/lower) so they go back exactly.

Step 11: Remove and replace the water pump

• Remove the water pump bolts using a 10mm socket.
• Pull the pump straight out; expect residual coolant to spill into the drain pan.
• Clean the sealing surface with a plastic gasket scraper and brake cleaner spray (no gouges).
• Install the new pump with a new seal/O-ring.
• Tighten water pump bolts evenly in a crisscross pattern: Torque to 10 Nm (89 in-lb).

Step 12: Reinstall timing components and verify timing

• Reinstall chain guides and tensioners using the socket set and Torx bit set.
• Confirm all timing marks align and the Ford 3.5L Ti-VCT timing tool kit (specialty) fits properly before proceeding.
• Remove the locking tools only after timing is confirmed correct.

Step 13: Reinstall the front cover with fresh RTV where required

• Install new front cover gaskets (and any included seals) per the gasket set.
• Apply RTV silicone sealant (OEM-approved) at the specified joints (common spots are cover-to-block “step” seams).
• Install the cover and hand-start all bolts, then tighten evenly using external Torx sockets and a torque wrench to OEM spec.

Step 14: Reinstall crank pulley with a new TTY crank bolt

• Reinstall the crank pulley (make sure it seats fully and straight).
• Install a new crankshaft pulley bolt (TTY).
• Tighten using a torque wrench and torque angle gauge (specialty) to OEM spec (TTY bolts require an initial torque plus angle turns).
• A “torque angle gauge” measures how many degrees you turn the bolt after initial torque.

Step 15: Reinstall mounts, belt, shields, and intake

• Reinstall the right engine mount using a socket set and torque wrench to OEM spec, then remove the engine support bar (specialty).
• Reinstall accessory brackets/pulleys using a socket set and Torx bit set to OEM spec.
• Install the new serpentine belt using the serpentine belt tool (3/8" drive).
• Reinstall splash shields and liner using a trim clip removal tool and 7mm/8mm sockets.

Step 16: Refill and bleed the cooling system

• Close the radiator drain.
• Refill with Motorcraft Yellow or equivalent, pre-mixed 50/50 using a funnel.
• Best method: use a cooling system vacuum fill tool (specialty) to reduce air pockets (air trapped can cause overheating).
• Reconnect the battery using a 10mm socket.

Step 17: Optional but strongly recommended oil change

• If there was any coolant contamination risk during disassembly, change the oil and filter.
• Use a drain pan, correct socket set for the drain plug, and install a new oil filter.

---

✅ After Repair

• Start the engine and let it idle; watch the temperature gauge and check for leaks at the front cover and pump area.
• Top off coolant after the thermostat opens and the level stabilizes.
• Test drive 10-15 minutes, then recheck coolant level after a full cool-down.
• If you hear chain rattle, shut down immediately and recheck timing-related work.

---

💰 DIY vs Shop Cost

Shop Cost: $1,800-$3,200 (parts + labor)

DIY Cost: $250-$650 (parts only)

You Save: $1,150-$2,950 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 8-12 hours.

---
