🔧 GLA - Water Pump Replacement

The water pump circulates coolant through your GLA’s engine and radiator. If it leaks, makes bearing noise, or the engine overheats, replacing the pump restores proper cooling and helps prevent engine damage.

Difficulty Level: Advanced | Estimated Time: 3-5 hours

Assumption: This procedure covers the belt-driven engine water pump on your GLA’s 2.0L turbo; exact fastener torque values vary by revision—use Mercedes service data for final torques.

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap on a hot engine; let it cool fully.
• ⚠️ Coolant is toxic—wear gloves and keep it off paint and pets.
• ⚠️ Support the GLA with jack stands; never rely on a floor jack alone.
• ⚠️ Keep fingers/hair/clothing away from the belt drive area.
• 🔋 Battery disconnect is recommended if you’ll be working near the starter/alternator wiring.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Metric socket set (8mm, 10mm, 13mm)
• External Torx socket set (E10, E12)
• Torx bit set (T25, T30)
• Ratchet (3/8" drive)
• Extensions (3" and 6")
• Serpentine belt tool or 17mm wrench
• Hose clamp pliers
• Trim clip removal tool
• Drain pan (at least 10 liters)
• Funnel
• Shop towels
• Plastic scraper
• Torque wrench (5–60 Nm range)
• Cooling system vacuum fill tool (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Water pump assembly - Qty: 1
• Water pump gasket / O-ring (if not included with pump) - Qty: 1
• Coolant (Mercedes-Benz approved, MB 325.0/325.6 spec) - Qty: 2-3 gallons (mixed as required)
• Accessory drive belt (serpentine belt) - Qty: 1
• Replacement hose clamps (if any are weak/damaged) - Qty: As needed

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool completely (radiator hoses should feel cool).
• Open the hood and remove the engine cover (pull up firmly by hand).
• If disconnecting the battery: use a 10mm socket to remove the negative terminal and isolate it so it can’t spring back.
• Place a drain pan under the front of the engine area.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the front and remove the lower splash shield

• Use a floor jack to lift the front and set it securely on jack stands.
• Use a Torx T25/T30 bit and trim clip removal tool to remove the fasteners and take off the lower splash shield.

Step 2: Drain the coolant

• Slowly loosen the coolant expansion tank cap by hand to release any leftover pressure.
• Drain coolant from the radiator drain (if equipped) or by removing the lowest accessible coolant hose.
• Use hose clamp pliers to slide the clamp back, then twist the hose gently to break it free (twisting breaks the seal without tearing the hose).
• Let coolant drain fully into the drain pan.

Step 3: Remove intake ducting for access (as needed)

• Use a 8mm socket (or appropriate driver) to loosen intake hose clamps.
• Use a Torx T25/T30 bit to remove any air duct/airbox screws, then move the ducting aside.
• Tip: Take a quick photo before disassembly.

Step 4: Remove the accessory drive belt

• Locate the belt tensioner.
• Use a serpentine belt tool or 17mm wrench to rotate the tensioner and relieve belt tension.
• Slide the belt off one pulley, then remove it completely.
• If the belt is cracked/glazed, replace it (recommended while you’re here).

Step 5: Disconnect coolant hoses from the water pump

• Place shop towels under the pump area to catch remaining coolant.
• Use hose clamp pliers to move clamps back.
• Gently twist and pull hoses off the pump fittings. Use a plastic scraper to help break the seal if needed (avoid metal picks that can gouge plastic/aluminum).

Step 6: Remove the water pump

• Unplug any nearby connectors that block access (press the lock tab by hand; don’t pull on wires).
• Use an E10/E12 external Torx socket (or 10mm socket, depending on fasteners) with a ratchet and extensions to remove the water pump mounting bolts.
• Remove the pump from the engine. If it’s stuck, tap gently with your hand—do not pry hard on sealing surfaces.

Step 7: Clean the mating surface and prep the new pump

• Use a plastic scraper and shop towels to clean old gasket material and residue from the engine mating surface.
• Make sure the surface is clean and dry—no chunks, no deep scratches.
• Install the new gasket/O-ring onto the new pump (lightly moisten an O-ring with fresh coolant so it seats without pinching).

Step 8: Install the new water pump

• Position the pump squarely and start all bolts by hand to avoid cross-threading.
• Tighten bolts evenly in a crisscross pattern using an E10/E12 socket and ratchet.
• Torque to manufacturer specification using a torque wrench.

Step 9: Reconnect hoses and reinstall the belt

• Reinstall coolant hoses fully onto their fittings, then position clamps back in their original spots using hose clamp pliers.
• Route the belt correctly around pulleys (use your photo or the belt routing diagram if present).
• Use the serpentine belt tool or 17mm wrench to rotate the tensioner, slip the belt on, then release tension slowly.
• Tip: Double-check belt sits in every pulley groove.

Step 10: Reinstall intake parts and splash shield

• Reinstall intake ducting/airbox using a 8mm socket and Torx T25/T30 bit.
• Reinstall the lower splash shield using a Torx T25/T30 bit and clips.
• Lower the GLA off the jack stands using the floor jack.

Step 11: Refill and bleed the cooling system

• If using a cooling system vacuum fill tool (specialty), pull vacuum and refill—this is the easiest way to avoid air pockets (trapped air that causes overheating).
• If filling normally: use a funnel and add the correct MB-spec coolant mixture into the expansion tank slowly.
• Start the engine and set cabin heat to maximum temperature and low fan speed.
• Let the engine idle and warm up while watching the coolant level; add as needed.
• Once warm, carefully check for leaks around the pump and hoses using a flashlight (keep hands away from moving belt).

---

✅ After Repair

• Recheck coolant level after the first full heat cycle and again the next morning when cold; top off as needed.
• Inspect for leaks under the GLA after a short test drive.
• Watch the temperature gauge for any overheating symptoms.
• If you disconnected the battery, reset clock/radio settings as needed.
• Dispose of old coolant properly (most auto parts stores accept waste fluids).

---

💰 DIY vs Shop Cost

Shop Cost: $900-$1,600 (parts + labor)

DIY Cost: $180-$450 (parts only)

You Save: $720-$1,150 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
