🔧 Regal - Water Pump Replacement

Replacing the water pump stops coolant leaks and prevents overheating. On your Regal’s 2.0L turbo, the water pump is typically mounted on the front (passenger-side) of the engine and is driven by the serpentine belt.

Assumption: This procedure is for the common belt-driven (external) water pump. If your pump is behind the timing cover (no pulley on the pump), the job is much larger and requires timing component removal.

Difficulty Level: Intermediate | Estimated Time: 2.5-5.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant tank when hot; let the engine cool fully.
• ⚠️ Support the car with jack stands; never rely on a floor jack alone.
• ⚠️ Keep hands clear of the serpentine belt path; the tensioner is spring-loaded.
• ⚠️ Coolant is toxic—catch it in a drain pan and dispose of it properly.
• ⚠️ If you remove any engine mount fasteners, support the engine with a jack and block of wood first.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (10-quart minimum)
• Funnel with spill-free coolant fill adapter (specialty)
• Metric socket set 8mm-18mm
• 1/4" drive ratchet
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-100 Nm range)
• Extensions set (3" and 6")
• Serpentine belt tool 3/8" drive (specialty)
• Torx bit set (T20-T40)
• Trim clip remover
• Pry bar (12")
• Gasket scraper (plastic)
• Shop towels
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Water pump assembly - Qty: 1
• Water pump gasket / seal - Qty: 1
• Dex-Cool compatible coolant (50/50 premix) - Qty: 2-3 gallons
• Serpentine belt - Qty: 1 Optional but smart if worn/cracked
• Accessory drive belt tensioner - Qty: 1 Optional if weak/noisy

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool completely (upper radiator hose should feel cool).
• Raise the front-right corner with a floor jack and support with jack stands.
• Remove the front-right wheel using the correct lug socket.
• Remove the front-right splash shield/liner fasteners using a trim clip remover and Torx bits as needed.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Drain the coolant

• Place a drain pan (10-quart minimum) under the radiator drain area.
• Slowly loosen the coolant surge tank cap to release any leftover pressure.
• Open the radiator drain (if equipped) or remove the lower radiator hose clamp using an 8mm socket (style varies), then let coolant drain fully.

Step 2: Remove the serpentine belt

• Locate the belt routing sticker; take a photo for reference.
• Use a serpentine belt tool 3/8" drive (specialty) (a long handle used to rotate the tensioner safely) to rotate the tensioner and slip the belt off the water pump pulley.
• Remove the belt from the rest of the pulleys and set it aside.

Step 3: Remove the water pump pulley (if equipped)

• If your pump has a pulley, hold the pulley from turning and remove the pulley bolts using the appropriate metric socket (commonly 10mm).
• Set the pulley aside.

Step 4: Remove components blocking access (as needed)

• Remove any brackets, hoses, or shields in the way using a metric socket set 8mm-18mm and extensions.
• If a coolant hose is attached to the pump, release the clamp and remove the hose carefully. Use shop towels to catch spills.

Step 5: Unbolt and remove the water pump

• Remove the water pump mounting bolts using a ratchet and correct metric socket.
• Gently break the seal and pull the pump away from the engine. Use a pry bar (12") carefully only on sturdy casting points.
• Clean the mating surface with a plastic gasket scraper until smooth and dry. Do not gouge aluminum.

Step 6: Install the new water pump and gasket

• Install the new gasket/seal on the new pump (match orientation exactly).
• Position the pump and hand-start all bolts to avoid cross-threading.
• Tighten bolts evenly in a crisscross pattern using a torque wrench (a tool that tightens bolts to an exact setting).
• Torque to OEM specification for your engine’s water pump fasteners.

Step 7: Reinstall the pulley and belt

• Reinstall the water pump pulley and start bolts by hand.
• Tighten pulley bolts evenly using a torque wrench.
• Torque to OEM specification for the pulley fasteners.
• Route the belt according to your photo/sticker.
• Use the serpentine belt tool 3/8" drive (specialty) to rotate the tensioner and slip the belt fully onto the last pulley.
• Double-check the belt is seated in every pulley groove.

Step 8: Reinstall splash shield and wheel

• Reinstall the splash shield using the Torx bit set and trim clip remover as needed.
• Reinstall the wheel and snug the lug nuts in a star pattern.
• Lower the car and final-tighten lug nuts with a torque wrench.
• Torque to 140 Nm (103 ft-lbs) for the wheel lug nuts.

Step 9: Refill and bleed the cooling system

• Close the radiator drain (or reinstall the lower hose and clamp) using the correct socket.
• Fill the surge tank with Dex-Cool compatible coolant (50/50 premix) using a funnel with spill-free adapter (specialty).
• Start the engine and set HVAC to MAX HEAT with the fan on medium.
• Let it idle and watch coolant level; top off as the level drops. Keep the cap off until warm-up stabilizes.
• Once the radiator fan cycles and heat is steady, install the cap.

---

✅ After Repair

• Check for leaks around the water pump and hose connections with a flashlight.
• Test drive 10-15 minutes, then recheck coolant level after the engine cools.
• Verify the temperature gauge stays normal and the heater blows hot.
• Listen for belt squeal; if present, re-check belt routing and seating.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,200 (parts + labor)

DIY Cost: $120-$350 (parts only)

You Save: $530-$850 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
