🔧 Escape - Radiator Hose Replacement

Replacing a radiator hose stops coolant leaks and prevents overheating. The job is mostly about safely draining a little coolant, swapping the hose, and refilling/bleeding the cooling system so you don’t trap air.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Only work on a stone-cold engine; hot coolant can cause severe burns.
• ⚠️ Never remove the radiator cap when hot; pressure can spray coolant.
• ⚠️ Support the Escape with jack stands if you go underneath; never rely on a jack alone.
• ⚠️ Keep coolant off belts and electrical connectors; wipe spills immediately.
• ⚠️ Dispose of used coolant properly; it’s toxic to people and pets.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Drain pan (at least 2-gallon)
• Funnel
• Hose clamp pliers (specialty)
• Slip-joint pliers
• Flathead screwdriver
• Pick tool (specialty)
• Utility knife
• Shop rags
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 8mm socket
• Ratchet

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Hose clamps - Qty: 2-4
• Engine coolant (Motorcraft Premium Gold equivalent) - Qty: 1-2 gallons
• Distilled water - Qty: 1-2 gallons

---

📋 Before You Begin

• 🧊 Let the Escape sit until the radiator hoses are completely cool to the touch.
• 🅿️ Park on level ground, set the parking brake, and chock the rear wheels.
• 🧽 Place a drain pan under the radiator area before loosening anything.
• 📝 Quick question so I can tailor the steps: are you replacing the upper hose (top/front, easier) or the lower hose (bottom, usually requires going underneath)?

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove pressure safely

• Use safety glasses and nitrile gloves.
• With the engine cold, slowly loosen the radiator cap by hand to the first stop to release any leftover pressure, then remove it fully.

Step 2: Drain enough coolant to get below the hose level

• Position the drain pan under the radiator.
• If you can access the radiator drain, open it carefully by hand or with a flathead screwdriver (varies by radiator) and drain 1-2 quarts.
• If the drain isn’t accessible, you can drain by loosening the hose clamp at the radiator end in Step 4 and letting coolant run into the pan. Go slow to control the spill.

Step 3: (Lower hose only) Lift and support the front safely

• Place wheel chocks behind the rear wheels.
• Lift the front with a floor jack (rated 3-ton minimum).
• Set the Escape onto jack stands (rated 3-ton minimum) at solid frame points.

Step 4: Loosen the hose clamps

• For factory spring clamps, use hose clamp pliers (specialty) to squeeze the clamp ears, then slide the clamp back on the hose.
• For worm-gear clamps, loosen with a flathead screwdriver.
• Move both end clamps back far enough that they’re no longer clamping the hose to the fittings.

Step 5: Break the hose loose (don’t break the radiator neck)

• Twist the hose by hand to break the seal.
• If it’s stuck, slide a pick tool (specialty) under the hose edge to let air in, then twist again.
• Do not pry hard against the radiator’s plastic neck—cracking it means radiator replacement.

Step 6: Remove the hose

• Pull the hose off the first end, then the second end, guiding it into the drain pan to catch remaining coolant.
• Use shop rags to wipe coolant off nearby parts.

Step 7: Prep the fittings and compare parts

• Inspect the radiator and engine fittings for corrosion or cracks; wipe clean with shop rags.
• Compare the new hose to the old hose (length, bends, end diameters).
• Slide the clamps onto the new hose before installing it.

Step 8: Install the new hose and position clamps

• Push the hose fully onto each fitting until it bottoms out.
• Position each clamp behind the raised “bead” on the fitting (the little ridge that helps prevent leaks).
• Tighten worm clamps with a flathead screwdriver until snug; do not crush the hose.
• Release spring clamps using hose clamp pliers (specialty) so they sit squarely in the same clamp track as before.

Step 9: (Lower hose only, if equipped) Reinstall any splash shield you removed

• If you removed a lower shield, reinstall it using an 8mm socket and ratchet.

Step 10: Refill coolant and bleed air

• Mix engine coolant (Motorcraft Premium Gold equivalent) with distilled water to a 50/50 mix unless you’re using premix.
• Use a funnel to slowly fill the radiator, then fill the coolant reservoir to the “FULL COLD” line.
• Start the engine and set HVAC to heat with the fan on medium.
• Let it idle and watch the coolant level; add as it drops. When the thermostat opens, the upper hose will get hot and coolant may drop again.
• Once bubbles stop and the level stabilizes, install the radiator cap by hand.

Step 11: Check for leaks

• With the engine idling, inspect both hose ends with a flashlight (use safety glasses).
• Shut the engine off and check again after 5 minutes for seepage.

---

✅ After Repair

• 🧪 After a full cool-down, recheck the reservoir level and top off to “FULL COLD” as needed.
• 🔎 Look for dried coolant residue at the clamps over the next 2-3 drives (a sign you need to re-seat/tighten a clamp).
• 🌡️ Watch the temperature gauge on your test drive; pull over if it rises abnormally.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$500 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $130-$460 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-2 hours.

---
