🔧 Crosstrek - Radiator Hose Replacement

You’ll replace a leaking, swollen, or cracked radiator hose so your engine can circulate coolant safely. On your Crosstrek there are typically two main radiator hoses: the upper hose (radiator to engine) and the lower hose (radiator to engine/water pump area).

Assumption: You’re replacing either the upper or lower main radiator hose (steps note both).

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the radiator cap on a hot engine; hot coolant can spray and burn you.
• ⚠️ Support the vehicle with jack stands; never rely on a floor jack alone.
• ⚠️ Coolant is toxic—keep it away from kids/pets and clean spills immediately.
• ⚠️ Use only the correct coolant type; mixing types can cause corrosion or sludge.
• 🔋 Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Drain pan (at least 2-gallon)
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 10mm socket
• 12mm socket
• 3/8" drive ratchet
• 3/8" drive extension (6")
• Phillips screwdriver #2
• Hose clamp pliers
• Channel-lock pliers
• Pick tool
• Trim clip removal tool
• Funnel
• Spill-free coolant funnel kit (specialty)
• Shop rags
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Radiator hose clamps - Qty: 2-4
• Coolant (Subaru Super Coolant compatible, pre-mixed) - Qty: 1-2 gallons

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool completely (best: sit overnight).
• Set the HVAC to HEAT and fan LOW later during bleeding (this helps move coolant through the heater core).
• If you’re doing the lower hose, plan to raise the front for better access.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Safely raise the front (recommended for lower hose)

• Place wheel chocks.
• Use a floor jack (rated 3-ton minimum) to lift the front and set the vehicle on jack stands (rated 3-ton minimum).

Step 2: Remove the lower splash shield (if equipped)

• Use a trim clip removal tool for plastic clips.
• Use a 12mm socket and 3/8" ratchet for any bolts.
• Use a Phillips screwdriver #2 for any screws.

Step 3: Relieve cooling system pressure (engine cold)

• Place shop rags around the radiator cap area.
• Slowly loosen the radiator cap by hand to the first stop to release any leftover pressure, then remove it fully.

Step 4: Drain enough coolant to get the hose off cleanly

• Position a drain pan (at least 2-gallon) under the radiator.
• Open the radiator drain (petcock) by hand if accessible; use channel-lock pliers only if needed and be gentle (plastic can break).
• Drain until coolant level is below the hose you’re replacing, then close the drain snugly by hand.
• Save clean coolant only if uncontaminated.

Step 5: Identify the hose you’re replacing

• Upper hose: runs from the top of the radiator to the engine at the thermostat housing area.
• Lower hose: runs from the bottom of the radiator down to the engine/water pump area (harder to access).
• Use a flashlight to confirm both ends and clamp types.

Step 6: Remove the hose clamps

• If you have spring clamps, use hose clamp pliers (they lock onto the clamp and make it much easier).
• Squeeze the clamp and slide it back several inches away from the hose end.
• If clamps were replaced with screw-type clamps, loosen using a Phillips screwdriver #2 or a 10mm socket (whichever fits).

Step 7: Break the hose loose and remove it

• Twist the hose at the end by hand. If it’s stuck, use channel-lock pliers gently to rotate the hose (don’t crush the radiator neck).
• If it’s still stuck, carefully slip a pick tool between the hose and the fitting to break the seal, then twist again.
• Pull the hose off and aim it into the drain pan to catch remaining coolant.

Step 8: Prep the fittings (very important)

• Use a shop rag to wipe the radiator neck and engine-side fitting clean.
• Make sure there is no old rubber stuck to the fitting.
• Inspect the radiator neck for cracks and the fitting for heavy corrosion.

Step 9: Install the new hose and position the clamps

• Slide the clamps onto the new hose first (use hose clamp pliers if spring clamps).
• Push the hose fully onto each fitting until it bottoms out.
• Position each clamp behind the raised bead on the fitting (this bead prevents blow-off).
• If using screw-type clamps, tighten using a 10mm socket or Phillips screwdriver #2 until snug—do not over-tighten (you can cut the hose).

Step 10: Reinstall the splash shield

• Reinstall clips with a trim clip removal tool (to align) and press in by hand.
• Reinstall bolts using a 12mm socket and 3/8" ratchet.

Step 11: Refill coolant

• Place a funnel or spill-free coolant funnel kit (specialty) in the radiator fill neck. (A spill-free funnel is a tall funnel that seals at the neck and lets air burp out while the engine runs.)
• Slowly add Subaru Super Coolant compatible, pre-mixed until full.
• Fill the overflow reservoir to the FULL line.

Step 12: Bleed air from the system

• Start the engine and let it idle.
• Set HVAC to HOT using the controls; keep fan on low.
• Watch the coolant level in the funnel/neck and add as needed (use the spill-free coolant funnel kit (specialty) or funnel).
• As the engine warms up, carefully squeeze the upper radiator hose by hand (gloves on) to help push trapped air out.
• Continue until you get steady cabin heat and you no longer see frequent air bubbles.
• When the radiator fans cycle on/off, it’s a good sign the system reached operating temperature.

Step 13: Cap it and check for leaks

• Turn the engine off and let it cool for 10–15 minutes.
• Top off the radiator one final time using a funnel.
• Install the radiator cap fully by hand until it clicks/stops.
• Start the engine again and inspect both ends of the hose with a flashlight for seepage.

---

✅ After Repair

• With the engine at operating temp, confirm the temperature gauge stays normal and you have strong cabin heat.
• After the first drive and a full cool-down, recheck the overflow reservoir and top off to the FULL line (use a funnel).
• Inspect for dried coolant residue around clamps over the next 2–3 days.
• Dispose of old coolant properly (most parts stores accept used coolant).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $40-$140 (parts only)

You Save: $210-$410 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
