🔧 Escape - Radiator Hose Replacement

Replacing a radiator hose stops coolant leaks and prevents overheating. On your Escape, the most common hoses are the upper radiator hose (top of radiator to engine) and lower radiator hose (bottom of radiator to engine).

Assumption: You want the steps for either the upper or lower hose (instructions cover both).

Difficulty Level: Beginner | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap on a hot engine; hot coolant can spray and burn you.
• ⚠️ Support the Escape with jack stands if you lift it; never rely on a floor jack.
• ⚠️ Keep coolant off belts and electrical connectors; wipe spills immediately.
• ⚠️ Wear gloves and eye protection; coolant is toxic and slippery.
• 🔋 Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (10-quart minimum)
• Funnel
• Shop towels
• Slip-joint pliers
• Hose clamp pliers
• Pick tool (small) (specialty)
• Flathead screwdriver
• 7mm nut driver
• 8mm nut driver
• 10mm socket
• 1/4" ratchet
• 6" extension (1/4" drive)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Radiator hose clamps - Qty: 2
• Engine coolant (orange or yellow, per underhood label) - Qty: 1-2 gallons
• Distilled water - Qty: 1-2 gallons (only if using концентрат coolant)

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool fully (ideally 2+ hours) before opening the cooling system.
• Locate the coolant reservoir (degas bottle) and confirm the coolant type by the underhood label.
• If doing the lower hose, plan to raise the front and support it on jack stands.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Depressurize the cooling system (cold engine only)

• Slowly loosen the coolant reservoir cap by hand until any hiss stops, then remove it completely.
• If it hisses hard, wait longer.

Step 2: Gain access to the hose you’re replacing

• Upper hose: From above, remove any intake ducting that blocks access using a 7mm nut driver or 8mm nut driver (clamp style varies).
• Lower hose: Lift the front with a floor jack, set it on jack stands, then remove the lower splash shield fasteners using a 10mm socket, 1/4" ratchet, and extension (if equipped).
• Lay bolts in a cup so you don’t lose them.

Step 3: Drain coolant to below hose level

• Place a drain pan under the radiator drain area.
• Open the radiator drain (if accessible) by hand or with a flathead screwdriver (style varies) and drain about 1–2 gallons, or until the radiator level is below the hose you’re removing.
• If there is no easy drain access, you can drain by loosening the lower hose carefully in Step 5 and catching the flow in the drain pan.

Step 4: Release the hose clamps

• If you have spring clamps (squeezing-type clamps): use hose clamp pliers (they lock onto the clamp so your hands are free).
• If you have worm-gear clamps (screw-type clamps): loosen with a 7mm nut driver or 8mm nut driver.
• Slide the clamp(s) back on the hose, away from the fitting.

Step 5: Remove the radiator hose

• Twist the hose by hand to break it free. Then pull it off.
• If it’s stuck, use a pick tool to gently lift the hose edge to let air in, then twist again. (A pick tool is a small hooked tool that helps separate stuck rubber without tearing fittings.)
• Catch any remaining coolant with the drain pan and wipe spills with shop towels.
• Don’t pry hard on plastic fittings.

Step 6: Prep the fittings and compare parts

• Wipe the radiator neck and engine-side fitting clean with shop towels.
• Compare the old hose to the new hose (length, bends, end shapes) before installing.
• Install new clamps onto the new hose if you’re replacing them.

Step 7: Install the new hose and position clamps

• Push the hose fully onto each fitting until it seats against the stop/bead.
• Move the clamp into position behind the raised bead on the fitting.
• If using worm-gear clamps, tighten with a 7mm nut driver or 8mm nut driver: Torque to 3-4 Nm (27-35 in-lbs).
• If using spring clamps, compress and release them with hose clamp pliers (no torque spec).

Step 8: Reinstall anything you removed

• Reinstall the splash shield using a 10mm socket, ratchet, and extension (if removed).
• Reinstall intake ducting and tighten clamps with a 7mm nut driver or 8mm nut driver.
• Remove jack stands and lower the Escape using the floor jack (if raised).

Step 9: Refill coolant

• Use a funnel and refill the coolant reservoir to the MAX line with the correct coolant mixture.
• If using concentrate coolant, mix with distilled water to make a 50/50 blend.

Step 10: Bleed air and check for leaks

• Start the engine and set HVAC to MAX HEAT with the fan on medium.
• Let it idle until the temperature gauge reaches normal and you feel steady heat from the vents.
• With the engine idling, carefully watch the hose connections for leaks and recheck coolant level in the reservoir.
• Shut the engine off, let it cool, then top off to the MAX line again if needed.
• Air bubbles = level drops after cool-down.

---

✅ After Repair

• Check for leaks after the first short drive (5–10 minutes) and again the next morning (cold engine).
• Make sure the temperature gauge stays normal and the cabin heat works well.
• Verify the coolant level is at the MAX line when cold.
• Dispose of old coolant properly; do not pour it on the ground.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$500 (parts + labor)

DIY Cost: $40-$140 (parts only)

You Save: $110-$460 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
