🔧 Pathfinder - Radiator Hose Replacement

Replacing a radiator hose means draining some coolant, removing the old hose, and installing a new one with good clamps so the cooling system can hold pressure. A cracked or soft hose can leak or burst and cause overheating, so it’s important to fix it right away.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the radiator cap on a hot engine; hot coolant can spray and burn you.
• ⚠️ Support the vehicle with jack stands before going underneath.
• ⚠️ Keep coolant away from kids/pets; it’s poisonous and tastes sweet.
• ⚠️ Use gloves and safety glasses; coolant is an irritant.
• 🔋 Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 10-quart)
• Funnel
• Pliers
• Hose clamp pliers (specialty)
• Pick tool
• Utility knife
• Flathead screwdriver
• 10mm socket
• Ratchet
• Torque wrench (5-60 Nm range)
• Trim clip remover
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Hose clamps - Qty: 2-4
• Nissan Long Life Antifreeze/Coolant (blue) premix - Qty: 1-2 gallons
• Distilled water - Qty: 1 gallon

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool fully (at least 2-3 hours).
• Set the HVAC temperature to full hot during bleeding later; this helps move coolant through the heater core.
• Take a photo of hose routing first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield (if equipped)

• Raise the front of your Pathfinder using a floor jack (rated 3-ton minimum) and support it with jack stands (rated 3-ton minimum).
• Use a trim clip remover and 10mm socket with a ratchet to remove the clips/bolts holding the lower splash shield.

Step 2: Relieve pressure safely

• Place shop towels around the radiator cap area.
• Slowly open the radiator cap only when the engine is completely cool.

Step 3: Drain enough coolant

• Place a drain pan (at least 10-quart) under the radiator drain.
• Open the drain using a flathead screwdriver (if slotted) and drain until the coolant level is below the hose you’re replacing.
• If your drain uses hand-turn only, use pliers gently only if needed (don’t crush it).

Step 4: Remove the upper radiator hose (radiator to engine)

• Use hose clamp pliers (specialty) or pliers to compress the spring clamp and slide it back on the hose.
• Twist the hose to break it loose. If it’s stuck, carefully work around the edge with a pick tool. (A pick tool is a small hook tool used to gently separate stuck rubber.)
• Pull the hose off the radiator neck, then off the engine neck.
• If it will not come off, use a utility knife to slit the hose lengthwise near the end and peel it off. Cut the hose, not the plastic neck.

Step 5: Remove the lower radiator hose (radiator to engine)

• Reposition the drain pan (at least 10-quart) under the lower hose area; more coolant will spill.
• Use hose clamp pliers (specialty) to move both clamps back.
• Twist and remove the hose from each end. Use the pick tool if needed.

Step 6: Prep the fittings and install the new hose(s)

• Wipe the radiator and engine hose necks clean using shop towels.
• Slide the new hose clamps onto the new hose before installing it.
• Push the hose fully onto each neck until it bottoms out (you should feel it “seat”).
• Position spring clamps behind the raised bead on the neck using hose clamp pliers (specialty). (That bead prevents the hose from blowing off.)
• If using worm-gear clamps, tighten with a flathead screwdriver until snug; do not crush the radiator neck.

Step 7: Reinstall the splash shield

• Reinstall the lower splash shield using a 10mm socket and ratchet, plus a trim clip remover for clips.
• If you have a torque spec available for your fasteners, use a torque wrench (5-60 Nm range); otherwise tighten snug (do not strip plastic).

Step 8: Refill coolant

• Close the radiator drain snugly.
• Use a funnel to refill with Nissan Long Life Antifreeze/Coolant (blue) premix.
• If you used concentrate, mix with distilled water to a 50/50 blend before filling.

Step 9: Bleed air from the cooling system

• Start the engine and let it idle with the radiator cap off.
• Set the heater to maximum heat and fan on medium.
• As the engine warms up, watch coolant level and add as needed using a funnel.
• Once the thermostat opens (upper hose gets hot), you may see bubbles; keep topping up until bubbles reduce.
• Install the radiator cap once the level stabilizes.
• Let it reach normal temperature and check for leaks at both ends of each hose using safety glasses.

Step 10: Top off the reservoir

• With the engine off and cooling down, fill the overflow reservoir to the “MAX” line using a funnel.
• After your first drive and full cool-down, recheck the reservoir and top off if needed.

---

✅ After Repair

• Check carefully for leaks at every clamp with the engine hot and running.
• Make sure the heater blows hot air; weak heat can mean air is still trapped.
• Watch the temperature gauge on the first 2-3 drives; pull over if it rises above normal.
• Dispose of old coolant properly (sealed container; take to a recycling center/auto parts store).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $50-$160 (parts only)

You Save: $200-$390 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
