🔧 Radiator Hose - Replacement

On your Fusion, the radiator hoses carry coolant between the engine and the radiator. Replacing a leaking, swollen, or cracked hose is important to prevent overheating and engine damage.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant reservoir cap on a hot engine; hot coolant can spray and burn you.
• ⚠️ Support the car with jack stands if you lift it; never rely on a floor jack alone.
• ⚠️ Coolant is toxic to people and pets; catch all drained coolant and dispose of it properly.
• ⚠️ Keep fingers clear of the radiator fan; it can turn on unexpectedly.
• Disconnecting the battery is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 2-gallon)
• Funnel
• Hose clamp pliers (specialty)
• Channel-lock pliers
• Pick tool
• Flathead screwdriver
• 8mm socket
• 10mm socket
• 1/4" ratchet
• 6" extension
• Trim clip removal tool
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Radiator hose clamp set - Qty: 1
• Engine coolant (Motorcraft Orange-compatible) - Qty: 1-2 gallons
• Distilled water - Qty: 1-2 gallons

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool completely (ideally 2+ hours).
• Set the HVAC temperature to full hot for the refill/bleed step later (this helps coolant flow through the heater core).
• Have your drain pan ready under the radiator area before loosening anything.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve pressure (engine cold)

• Put on safety glasses and nitrile gloves.
• Slowly loosen the coolant reservoir cap by hand to release any leftover pressure, then remove it.

Step 2: Raise the front (if doing the lower hose)

• Lift the front with a floor jack (rated 3-ton minimum) at the correct front jacking point.
• Set the car onto jack stands (rated 3-ton minimum).
• Keep wheel chocks in place.

Step 3: Drain enough coolant to get the hose off

• Place a drain pan (at least 2-gallon) under the lower radiator area.
• If accessible, open the radiator drain (petcock) using a flathead screwdriver and drain until the level is below the hose you’re replacing.
• If the drain isn’t accessible, you can carefully loosen the lower hose clamp instead (coolant will rush out), using hose clamp pliers (specialty).
• Drain only what you need to reduce mess.

Step 4: Remove components blocking access (as needed)

• For upper hose access, remove the air intake duct/clips if they block your hands using a 8mm socket, 10mm socket, 1/4" ratchet, and trim clip removal tool.
• Use a flashlight to identify both ends of the hose and the clamp types.

Step 5: Release the hose clamps

• If your clamps are spring clamps, squeeze and slide them back using hose clamp pliers (specialty).
• If your clamps are worm-gear clamps, loosen them with an 8mm socket (or flathead screwdriver) until the hose can move.
• Slide each clamp a few inches away from the hose end.

Step 6: Break the hose loose (don’t pry the radiator neck)

• Twist the hose by hand to break the seal. If it’s stuck, gently work around the edge with a pick tool.
• Pull the hose off while keeping the opening aimed into the drain pan (at least 2-gallon).
• Twist first; pulling straight can tear fittings.

Step 7: Compare parts and prep the fittings

• Match the new hose to the old one (same bends and diameter) under a flashlight.
• Inspect the radiator and engine hose necks for cracks, heavy corrosion, or leftover rubber.
• Clean the sealing surfaces with a shop towel (use the pick tool only gently if needed).

Step 8: Install the new hose and position clamps

• Slide the clamps onto the new hose before installation.
• Push the hose fully onto the radiator neck and the engine neck until it bottoms out.
• Reposition the clamps to sit behind the raised “bead” on each neck using hose clamp pliers (specialty) or an 8mm socket (depending on clamp type).
• If using worm-gear clamps, tighten with an 8mm socket until snug (do not crush the plastic radiator neck).

Step 9: Reinstall any removed intake covers/ducts

• Reinstall brackets, ducts, and clips using a 10mm socket, 8mm socket, 1/4" ratchet, and trim clip removal tool.

Step 10: Refill coolant

• Mix coolant with distilled water to a 50/50 blend unless you purchased pre-mix.
• Fill the reservoir slowly using a funnel until it reaches the proper level line.
• Install the reservoir cap hand-tight.

Step 11: Bleed air and verify the repair

• Start the engine and let it idle while watching temperature.
• Set heat to max and fan to medium.
• As it warms up, check both hose connections for seepage using a flashlight.
• Shut the engine off, let it cool, then recheck the reservoir level and top off with 50/50 coolant using a funnel.

---

✅ After Repair

• Test drive 10-15 minutes, then recheck for leaks with a flashlight.
• After the engine fully cools, recheck coolant level and top off as needed.
• Watch the temperature gauge for the next few trips; any overheating means stop and recheck for trapped air or leaks.
• Dispose of old coolant properly (many parts stores accept it).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $40-$140 (parts only)

You Save: $110-$510 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
