🔧 Camry - Radiator Hose Replacement

Replacing a radiator hose stops coolant leaks and prevents overheating. You’ll remove the old hose, install the new one with fresh clamps (if needed), then refill and bleed the cooling system.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

Assumption: You want the upper and/or lower radiator hose; steps cover both.

---

⚠️ Safety & Precautions

• ⚠️ Never open the radiator cap on a hot engine; coolant can spray and burn.
• ⚠️ Hybrid caution: avoid any orange high-voltage cables/components; you don’t need to touch them for this job.
• ⚠️ Support the car with jack stands on a level surface; never rely on a floor jack alone.
• ⚠️ Keep coolant off painted surfaces and away from pets; it’s toxic.
• ⚠️ Battery disconnect is not required for hose replacement, but keep the car OFF until you’re ready to bleed the system.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 10-quart)
• 10mm socket
• 3/8" drive ratchet
• 6" socket extension
• Flathead screwdriver
• Hose clamp pliers
• Pick tool
• Utility knife
• Funnel
• Spill-free funnel kit (specialty)
• Shop rags
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Hose clamps - Qty: 2-4
• Toyota Super Long Life Coolant (pink, premixed 50/50) - Qty: 1-2 gallons

---

📋 Before You Begin

• Park on level ground, set parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool fully (best: sit overnight).
• Remove the plastic engine cover if equipped (pull up by hand).
• If you’re doing the lower hose, raise the front with a floor jack and support with jack stands.
• Set your drain pan under the radiator drain area before you open anything.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve pressure safely

• Use your hand to slowly loosen the radiator cap (or reservoir cap if that’s the only accessible cap) only when the engine is cold.
• If you hear pressure release, stop and wait until it fully vents, then remove the cap.

Step 2: Drain enough coolant to drop the level below the hose

• Place a drain pan (at least 10-quart) under the radiator.
• Open the radiator drain cock (petcock) carefully by hand or with a flathead screwdriver if needed.
• Drain until the coolant level is below the hose you’re replacing, then close the drain cock snugly. Hand-snug only; don’t overtighten.

Step 3: Gain access (upper hose vs lower hose)

• Upper hose: Use a flashlight to locate the hose from the radiator top outlet to the engine outlet.
• Lower hose: Remove the front lower splash shield/under cover using a 10mm socket, ratchet, and 6" extension.

Step 4: Remove the hose clamps

• Use hose clamp pliers to compress the spring clamp and slide it back onto the hose.
• If you have a worm-gear clamp instead, loosen it with a flathead screwdriver.
• Tip: Take a quick photo before moving clamps.

Step 5: Break the hose free (don’t break the radiator neck)

• Twist the hose gently by hand to break the seal.
• If it’s stuck, slide a pick tool between the hose and the fitting to let air in. (A pick tool is a small hooked tool used to separate stuck rubber without prying hard.)
• Pull the hose off.
• If the hose is rock-hard and won’t budge, use a utility knife to carefully slit the hose lengthwise near the end and peel it off. Do not cut into the plastic/aluminum neck.

Step 6: Inspect and prep the fittings

• Wipe the radiator and engine hose fittings with shop rags.
• Make sure the sealing surfaces are smooth and not cracked (especially the radiator neck).

Step 7: Install the new hose

• Slide the new hose clamps onto the new hose before installing it.
• Push the hose fully onto each fitting until it seats against the stop/bead.
• Position the clamp behind the raised bead on the fitting, then release with hose clamp pliers (or tighten with a flathead screwdriver).
• Tip: Match the original hose angle to prevent rubbing.

Step 8: Reinstall shields/covers and refill coolant

• If removed, reinstall the splash shield using a 10mm socket, ratchet, and extension.
• Fill the radiator (or reservoir, depending on fill point) using a funnel with Toyota Super Long Life Coolant (pink, premixed 50/50).

Step 9: Bleed air from the system (important on a hybrid)

• Install a spill-free funnel kit (specialty) at the radiator fill neck (or the correct fill point) and keep coolant level in the funnel.
• Put the car into Maintenance Mode so the engine will run more steadily:
  • Press POWER twice (no brake) to IG-ON.
  • Fully press/release accelerator 2 times.
  • Shift to N, fully press/release accelerator 2 times.
  • Shift to P, fully press/release accelerator 2 times.
  • Press POWER with brake to go READY; Maintenance/Inspection mode should indicate.
• Set HVAC to HI heat and fan on low/medium to help air purge.
• Let it run and watch for bubbles; add coolant as the level drops.
• When bubbles stop and you have steady heat, shut the car OFF and let it cool, then top off again.

Step 10: Final top-off

• Remove the spill-free funnel and install the cap.
• Fill the coolant reservoir to the FULL line using a funnel.
• Clean any spilled coolant with shop rags.

---

✅ After Repair

• Start the car (READY) and check carefully for leaks at both ends of the replaced hose.
• After your first short drive, recheck the reservoir level when fully cool and top off as needed.
• Watch the temperature gauge; if it rises abnormally, stop and re-check for trapped air or leaks.
• Dispose of old coolant properly (sealed container; take to a recycling/parts store).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $50-$180 (parts only)

You Save: $200-$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
