🔧 Timing Chain - Replacement

Your RAV4 does not use a timing belt. It uses a timing chain, which is a major internal engine repair and is much more involved than a belt service. This job requires front-engine disassembly, careful timing alignment, and seal replacement to prevent engine damage.

Difficulty Level: Advanced | Estimated Time: 10-14 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before starting.
• Support the vehicle securely on jack stands; do not rely on a jack alone.
• The engine must be cool before draining coolant or removing covers.
• Timing work must be done with the engine at top dead center; incorrect timing can cause severe engine damage.
• Use a harmonic balancer puller (specialty) only if required by the crank pulley design.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 17mm socket
• 19mm socket
• Ratchet
• Breaker bar
• Torque wrench
• Harmonic balancer puller (specialty)
• Engine support bar or jack with wood block
• Jack stands
• Floor jack
• Drain pan
• Scraper
• Gasket sealant applicator
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Timing chain kit - Qty: 1
• Timing chain tensioner - Qty: 1
• Timing chain guides - Qty: 1 set
• Front engine cover gasket/seal kit - Qty: 1
• Crankshaft seal - Qty: 1
• Camshaft seals - Qty: 2
• Water pump gasket - Qty: 1
• Engine coolant - Qty: 1-2 gallons
• RTV sealant - Qty: 1 tube

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Let the engine cool fully.
• Disconnect the negative battery cable with a 10mm socket.
• Raise the front of the vehicle and secure it on jack stands.
• Drain the engine coolant into a drain pan.
• Keep parts organized by side and order.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove upper engine access parts

• Use a 10mm socket and ratchet to remove the engine cover, air intake ducting, and any brackets blocking access.
• Label connectors and clamps as you remove them.

Step 2: Remove accessory drive components

• Use a 14mm socket and breaker bar to relieve belt tension and remove the serpentine belt.
• Remove the accessory brackets and any splash shields with the correct 10mm and 12mm sockets.

Step 3: Support the engine and remove mounts

• Support the engine with an engine support bar or a floor jack and wood block.
• Use a 14mm socket and 17mm socket to remove the engine mount bolts as needed.

Step 4: Remove crank pulley and front cover

• Use a 19mm socket and breaker bar to remove the crankshaft pulley bolt.
• If the pulley is stuck, use a harmonic balancer puller (specialty).
• Remove front timing cover bolts with 10mm and 12mm sockets.
• Torque on reassembly: crankshaft pulley bolt to 157 Nm (116 ft-lbs).

Step 5: Set engine timing at top dead center

• Rotate the crankshaft by hand with a 19mm socket until cylinder 1 is at top dead center.
• Align the timing marks on the crankshaft and camshaft sprockets exactly.
• Do not force the crankshaft.

Step 6: Remove timing chain components

• Use a 10mm socket to remove the timing chain tensioner.
• Remove the timing chain guides with a 10mm socket.
• Lift off the timing chain and sprockets in the correct order.

Step 7: Install new chain and guides

• Install the new timing chain kit, matching all colored timing links to the sprocket marks.
• Install new guides and the new tensioner with a 10mm socket.
• Torque to 9 Nm (80 in-lbs) unless your kit instructions specify otherwise.

Step 8: Reinstall front cover and seals

• Clean all sealing surfaces with a scraper and apply RTV sealant where specified.
• Install new crankshaft and camshaft seals.
• Reinstall the front cover with a 10mm socket and tighten bolts evenly.
• Torque to 10 Nm (89 in-lbs) for small cover bolts unless otherwise specified.

Step 9: Reassemble accessories

• Reinstall the crank pulley, engine mounts, belts, brackets, and intake parts using the correct sockets.
• Reinstall all fasteners to factory torque specs.

Step 10: Refill fluids and verify timing

• Refill the cooling system with the correct engine coolant.
• Reconnect the battery.
• Rotate the engine by hand two full turns with a 19mm socket and recheck timing marks.

---

✅ After Repair

• Start the engine and listen for abnormal rattles or ticking.
• Check for coolant, oil, or RTV leaks.
• Verify smooth idle and normal engine operation.
• Recheck coolant level after warm-up and again after a short drive.

---

💰 DIY vs Shop Cost

Shop Cost: $1,800-$3,200 (parts + labor)

DIY Cost: $250-$700 (parts only)

You Save: $1,100-$2,500 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 10-14 hours.

---
