🔧 Timing Belt - Not Applicable

Your Sienna does not use a timing belt. It uses a timing chain, which is internal to the engine and is not a routine maintenance item like a belt.

Difficulty Level: Advanced | Estimated Time: N/A

---

⚠️ Safety & Precautions

• Timing chain service requires major engine disassembly.
• Do not attempt internal engine work without factory service data.
• Battery disconnect is recommended before any engine teardown.
• If you hear chain rattle, inspect immediately to avoid engine damage.

---

🔧 Required Tools

You'll need the following tools for this repair:

• OBD-II scan tool
• Metric socket set
• Torque wrench
• Breaker bar
• Engine support bar
• Drain pan
• Floor jack (rated 3-ton minimum)
• Jack stands
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Timing chain kit - Qty: 1
• Timing cover gasket set - Qty: 1
• Front crankshaft seal - Qty: 1
• Engine oil - Qty: 1 service fill
• Engine oil filter - Qty: 1
• Coolant - Qty: 1 drain-and-refill

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Disconnect the negative battery cable before starting.
• Allow the engine to cool completely.
• This is a major repair best handled with factory procedures.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm the concern

• Use an OBD-II scan tool to check for cam/crank correlation codes.
• Listen for chain rattle on cold start.

Step 2: Do not replace a belt

• Your engine has a timing chain, not a timing belt.
• Chain service is major engine work.

Step 3: If chain repair is needed

• Use the metric socket set and torque wrench to disassemble the front of the engine per factory procedure.
• Replace the chain, guides, tensioner, seals, and gaskets as a complete set.
• Torque to factory specification for every fastener in sequence.

---

✅ After Repair

• Refill engine oil and coolant.
• Clear all fault codes with the scan tool.
• Start the engine and verify no leaks or unusual noise.
• Recheck fluid levels after the road test.

---

💰 DIY vs Shop Cost

Shop Cost: $1,800-$4,500 (parts + labor)

DIY Cost: $400-$1,200 (parts only)

You Save: $1,400-$3,300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 10-16 hours.

---
