🔧 Grand Cherokee WK - Thermostat Replacement

You're going to remove the old thermostat housing, install a new thermostat with seal, then refill and bleed the cooling system on your Grand Cherokee WK. This fixes issues like running too cold, overheating, or thermostat-related trouble codes.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• 🛑 Never open the cooling system when the engine is hot; hot coolant can spray and cause serious burns.
• 🛑 Allow the engine to cool completely (at least 1–2 hours) before starting.
• 🛑 Wear safety glasses and gloves to protect from coolant and sharp edges.
• 🛑 Keep coolant away from children and pets; it is toxic but sweet-tasting.
• 🛑 Support the Jeep securely on jack stands if you raise the front; never rely on a jack alone.
• ⚙️ Disconnect the negative battery cable if you might bump the starter wiring or any rotating parts; not strictly required but safer for beginners.
• ⚙️ Work in a well-ventilated area and avoid breathing coolant mist.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🧰 Metric socket set (8mm–15mm sockets)
• 🧰 1/4" drive ratchet
• 🧰 3/8" drive ratchet
• 🧰 3" and 6" socket extensions (1/4" and 3/8" drive)
• 🧰 Torque wrench (inch-lb and ft-lb, 5–80 ft-lb range)
• 🧰 Flathead screwdriver (medium size)
• 🧰 Phillips screwdriver (medium size)
• 🧰 Hose clamp pliers (specialty)
• 🧰 Needle-nose pliers
• 🧰 Trim clip removal tool (specialty)
• 🧰 Plastic drain pan (at least 10-liter capacity)
• 🧰 Funnel with long neck
• 🧰 Coolant spill-proof funnel kit (specialty)
• 🧰 Floor jack (rated 3-ton minimum)
• 🧰 Jack stands (rated 3-ton minimum, Qty: 2)
• 🧰 Shop rags or paper towels
• 🧰 Plastic scraper or nylon gasket scraper
• 🧰 Flashlight or work light
• 🧰 Safety glasses
• 🧰 Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Engine thermostat with housing and seal (3.6L) - Qty: 1
• 🔩 Upper radiator hose O-ring or seal (if separate) - Qty: 1
• 🔩 Mopar OAT coolant (purple, concentrate or premix) - Qty: 2–3 gallons equivalent (enough for drain and refill)
• 🔩 Distilled water - Qty: 2–3 gallons (only if using concentrate)
• 🔩 Thermostat housing bolts (optional, replacement) - Qty: 3 (if kit does not include)
• 🔩 Radiator drain plug O-ring (optional, if worn) - Qty: 1
• 🔩 Shop towels/absorbent pads - Qty: 1 pack
• 🔩 Dielectric grease (for any disconnected sensor connectors) - Qty: small tube

---

📋 Before You Begin

• 🧭 Park the Grand Cherokee WK on a level surface, set the parking brake, shift to Park, and switch off the engine.
• 🧊 Let the engine cool fully so the upper radiator hose feels cold to the touch.
• 🔌 If desired for safety, disconnect the negative battery terminal using a 10mm socket.
• 🧺 Place a large drain pan under the front of the Jeep where the radiator drain is located (bottom passenger side).
• 📦 Plan where you will store used coolant; use a clean container for recycling.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the front (if needed)

• Use the floor jack (3-ton) to lift the front of the Jeep at the front jacking point or crossmember (check your owner’s manual illustration).
• Place jack stands (3-ton) under the proper frame points and slowly lower the Jeep onto them.
• Give the Jeep a gentle shake to confirm stability.

Step 2: Remove engine cover and locate the thermostat

• Open the hood and prop it securely.
• Pull up on the plastic engine cover; it is held by rubber grommets. If needed, use both hands and a gentle rocking motion.
• On the 3.6L V6, follow the lower radiator hose from the radiator toward the engine; the hose connects to the thermostat housing on the front of the engine (lower front area).

Step 3: Drain coolant from the radiator

• Slide the plastic drain pan under the passenger side bottom of the radiator.
• Use a flathead screwdriver (if applicable) to carefully loosen the radiator drain plug (petcock) and open it. Some versions turn by hand.
• Remove the coolant reservoir cap by hand to let air in so coolant drains faster.
• Let coolant drain until it slows to a drip.
• Do not force the plastic drain; it can break.

Step 4: Remove lower radiator hose from thermostat housing

• Place rags under the thermostat area to catch any remaining coolant.
• Use hose clamp pliers to squeeze the spring clamp on the lower radiator hose where it connects to the thermostat housing, then slide the clamp back along the hose.
• Gently twist the hose by hand to break it loose, then pull it off the thermostat housing. If stuck, use a flathead screwdriver carefully at the edge, but do not gouge the plastic.
• Let any extra coolant drain into the pan.

Step 5: Disconnect any sensors or brackets (if equipped)

• Some thermostat housings have a coolant temperature sensor nearby or a wiring bracket.
• If present, use needle-nose pliers or a trim clip removal tool to release any plastic clips from the housing.
• Unplug electrical connectors by pressing the tab with your thumb; avoid pulling on the wires. If you unplug a sensor, note its position for reassembly.

Step 6: Remove thermostat housing bolts

• Use a 10mm socket with a 1/4" drive ratchet and appropriate extension to remove the three thermostat housing bolts (number can vary; usually three).
• Loosen all bolts a little first, then remove them fully to prevent binding.
• Keep track of bolt length and location, laying them out in the same pattern you removed them.

Step 7: Remove the thermostat housing and thermostat

• Gently pull the thermostat housing away from the engine by hand.
• If it is stuck, tap lightly around the housing with the heel of your hand or use a plastic scraper at the edge. Do not pry with metal tools on aluminum.
• Remove the old thermostat assembly and seal. Note its orientation (how it sits and faces).

Step 8: Clean the sealing surface

• Use a plastic scraper and shop rags to carefully clean the mating surface on the engine of old gasket material or residue.
• Do not scratch the aluminum; keep debris from falling into the engine opening. You can stuff a clean rag loosely in the opening while scraping, then remove it when done.
• Wipe the surface with a clean rag until it is smooth and dry.

Step 9: Prepare the new thermostat and housing

• Install the new seal or O-ring onto the new thermostat housing if it is separate; ensure it sits evenly in its groove.
• Position the new thermostat in the housing in the same orientation as the old one (spring side toward engine for this style, as supplied).
• Compare old and new parts carefully; they must match.

Step 10: Install the new thermostat housing

• Place the new thermostat housing against the engine, aligning bolt holes carefully.
• Start all thermostat housing bolts by hand to avoid cross-threading.
• Use the 10mm socket and 1/4" drive ratchet to snug the bolts evenly in a crisscross pattern.
• Use a torque wrench with the 10mm socket to tighten the thermostat housing bolts to 12 Nm (106 in-lbs). Do not over-tighten; the housing is plastic.

Step 11: Reconnect hoses and sensors

• Slide the lower radiator hose back onto the thermostat housing fully until it seats against the stop.
• Use hose clamp pliers to move the spring clamp back into its original position over the hose and fitting.
• Reconnect any electrical connectors you removed by hand until they click into place.
• Reattach any wire or hose clips using the trim clip removal tool or by pressing them back into their holes.

Step 12: Close the radiator drain

• Use the flathead screwdriver or your fingers (depending on design) to close the radiator drain plug firmly by hand. Do not over-tighten; it is plastic.
• Wipe any coolant from around the drain area with shop rags.

Step 13: Refill the cooling system

• Make sure the heater controls inside the Jeep are set to full hot (ignition on is enough later; this just opens the heater core circuit).
• If you have concentrate coolant, mix it with distilled water in a clean container to make a 50/50 mix before pouring.
• Install a coolant spill-proof funnel into the radiator or coolant reservoir cap opening (this kit helps burp air).
• Slowly pour the coolant mix into the funnel until the radiator/reservoir is full and the level stabilizes.
• Squeeze the upper and lower radiator hoses gently by hand to help push out air bubbles while topping up.

Step 14: Bleed air from the system (burping)

• With the funnel still installed and some coolant in it, start the engine.
• Let the engine idle, and turn the cabin heater to maximum heat and fan speed using the dashboard controls.
• Watch the coolant level in the funnel. As the thermostat opens, the level may drop and small bubbles will rise.
• Use a flashlight to keep an eye on leaks around the thermostat housing and hose connections.
• Add coolant as needed to keep the level above the outlet; do not let it run dry.
• Let the engine reach normal operating temperature; the upper radiator hose should feel hot and firm.
• Run the engine for about 10–15 minutes, occasionally raising engine speed slightly (1500–2000 rpm) to move coolant.

Step 15: Final coolant level set and cleanup

• Turn off the engine and let it sit for a few minutes to settle.
• Remove the funnel and top off the coolant reservoir to the “FULL COLD” mark using coolant directly from the bottle or funnel.
• Install the reservoir cap by hand and tighten until snug.
• Wipe up any spilled coolant with shop rags.
• Pour the used coolant from the drain pan into sealed containers for recycling.

Step 16: Reinstall engine cover and lower the vehicle

• Press the engine cover back into place by hand, aligning the grommets with their mounting posts.
• If the Jeep is on jack stands, use the floor jack to raise it slightly, remove the jack stands, then lower it gently to the ground.

Step 17: Next-morning level check

• After the engine has completely cooled (next morning is best), check the coolant level in the reservoir.
• If the level has dropped, top off to the “FULL COLD” mark again using a 50/50 coolant mix.

---

✅ After Repair

• 🚗 Start the engine and let it warm to normal temperature while watching the temperature gauge; it should rise steadily and then stay near the middle.
• 🚗 Verify the cabin heater blows hot air and there are no gurgling sounds from behind the dashboard.
• 🔍 Inspect around the thermostat housing, hose connections, and radiator drain for leaks with a flashlight.
• 🧪 If you have a scan tool, clear any thermostat or coolant temperature-related codes and verify they do not return.
• 🛣️ Take a short drive, watch the temperature gauge, then recheck for leaks back in the driveway.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$550 (parts + labor)

DIY Cost: $80-$160 (parts + coolant)

You Save: $190-$470 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
