🔧 Grand Cherokee - Thermostat Replacement

The thermostat controls coolant flow so your engine warms up correctly and stays at the right temperature. On your Grand Cherokee, the thermostat is mounted at the engine-side coolant outlet near the lower radiator hose area, and replacing it requires draining some coolant, removing the housing, installing a new thermostat, and bleeding air from the cooling system.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Only work on the cooling system when the engine is fully cold. Hot coolant can spray and cause severe burns.
• ⚠️ Coolant is toxic to people and animals. Catch it in a drain pan and wipe spills right away.
• ⚠️ Do not open the radiator cap or coolant pressure cap on a hot engine.
• ⚠️ Disconnecting the battery is not normally required for this repair, but keep tools away from the positive battery jump post.
• ⚠️ Use only coolant compatible with the Grand Cherokee’s OAT coolant system. Do not mix coolant types.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 8mm socket
• 10mm socket
• 13mm socket
• 3/8-inch drive ratchet
• 3/8-inch drive extension set
• Flat-head screwdriver
• Hose clamp pliers
• Plastic scraper
• Torque wrench rated 5-50 Nm
• Drain pan 2-gallon minimum
• Funnel
• Coolant hydrometer or refractometer
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine thermostat - Qty: 1
• Thermostat seal or O-ring - Qty: 1
• OAT engine coolant concentrate or premix - Qty: 1 gallon
• Distilled water - Qty: 1 gallon if using concentrate

---

📋 Before You Begin

• Park your Grand Cherokee on level ground and let the engine cool completely, ideally overnight.
• Set the parking brake and keep the transmission in Park.
• Open the hood and remove the engine cover by lifting it straight upward by hand.
• Set the cabin heater to full hot before the final bleed procedure. This helps coolant circulate through the heater core.
• Place a drain pan under the front of the engine before opening any coolant hose or drain point.
• A torque wrench is a tool that tightens bolts to an exact tightness, preventing stripped threads or leaks.
• Hose clamp pliers squeeze spring clamps evenly so hoses can be removed without damaging them.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve Cooling System Pressure

• Make sure the engine is cold to the touch.
• Put on safety glasses and nitrile gloves.
• Slowly loosen the coolant pressure cap by hand to release any leftover pressure.
• Reinstall the cap loosely after pressure is released to reduce splashing while you work.
• Cold engine only.

Step 2: Remove the Engine Cover and Intake Access Parts

• Lift the plastic engine cover upward by hand and set it aside.
• Use an 8mm socket or flat-head screwdriver to loosen the air intake tube clamps if the intake tube blocks access.
• Use a 10mm socket to remove any air box or resonator fasteners that block your hand path to the thermostat area.
• Move the intake tube aside gently. Do not pull hard on connected sensors or wiring.

Step 3: Drain Some Coolant

• Place the 2-gallon drain pan under the lower radiator hose and thermostat housing area.
• If using the radiator drain, open it carefully by hand or with a flat-head screwdriver, depending on access.
• If the drain is hard to access, use hose clamp pliers to slide the lower hose clamp back, then carefully loosen the hose enough to drain coolant into the pan.
• Drain about 1 gallon of coolant, or enough so coolant level is below the thermostat housing.
• Close the radiator drain by hand if opened.
• Go slow to avoid spills.

Step 4: Remove the Lower Radiator Hose from the Thermostat Housing

• Use hose clamp pliers to squeeze the spring clamp on the lower radiator hose at the thermostat housing.
• Slide the clamp several inches back on the hose.
• Twist the hose gently by hand to break it loose.
• If stuck, use a flat-head screwdriver carefully between the hose and housing lip. Do not gouge the aluminum surface.
• Pull the hose off and aim any remaining coolant into the drain pan.

Step 5: Remove the Thermostat Housing Bolts

• Use a 13mm socket, 3/8-inch drive ratchet, and extension to remove the thermostat housing bolts.
• Hold the housing with one hand while removing the last bolt so it does not drop.
• Remove the thermostat housing from the engine.
• Note the thermostat orientation before removal. The spring side faces into the engine.

Step 6: Remove the Old Thermostat and Seal

• Pull the old thermostat out by hand.
• Remove the old seal or O-ring by hand.
• Use a plastic scraper to clean the sealing surface on the housing and engine.
• Wipe the area clean with shop towels.
• Do not use a metal scraper. It can scratch the sealing surface and cause leaks.
• Clean surfaces seal best.

Step 7: Install the New Thermostat

• Install the new thermostat seal or O-ring onto the new thermostat if it is not already installed.
• Place the new engine thermostat into position with the spring side facing into the engine.
• Make sure the thermostat sits flat and centered in its recess.
• If the thermostat has a small jiggle valve or bleed hole, position it at the top.

Step 8: Reinstall the Thermostat Housing

• Place the thermostat housing squarely against the engine by hand.
• Start both bolts by hand to avoid cross-threading.
• Use a 13mm socket, 3/8-inch drive ratchet, and extension to snug the bolts evenly.
• Use a torque wrench rated 5-50 Nm to tighten the thermostat housing bolts to Torque to 28 Nm (21 ft-lbs).
• Do not overtighten. The housing can crack or warp.

Step 9: Reconnect the Lower Radiator Hose

• Push the lower radiator hose fully onto the thermostat housing by hand.
• Use hose clamp pliers to move the spring clamp back into its original position.
• Make sure the clamp sits behind the raised lip on the housing.
• Wipe the area dry with shop towels so leaks are easier to spot later.

Step 10: Reinstall Intake Parts

• Reposition the air intake tube by hand if removed.
• Use an 8mm socket or flat-head screwdriver to tighten the intake tube clamps until snug.
• Use a 10mm socket to reinstall any air box or resonator fasteners removed earlier.
• Push the engine cover back down by hand until it seats on its mounts.

Step 11: Refill the Cooling System

• Use a funnel to fill the coolant reservoir with the correct OAT engine coolant.
• If using concentrate, mix it 50/50 with distilled water before pouring.
• Fill to the COLD fill mark on the reservoir.
• Use a coolant hydrometer or refractometer to verify proper freeze protection if you mixed coolant yourself.
• Do not mix HOAT and OAT coolants. Mixing can cause sludge and cooling problems.

Step 12: Bleed Air from the Cooling System

• Leave the coolant pressure cap off.
• Start the engine and let it idle.
• Set the heater to full hot and low fan speed from the climate controls.
• Watch the coolant level in the reservoir and add coolant with the funnel as the level drops.
• Let the engine idle until the upper radiator hose gets warm and the thermostat opens.
• Look for steady heat from the vents. This helps confirm coolant circulation.
• Install the coolant pressure cap by hand once bubbles stop and the level stabilizes.
• Use shop towels to wipe any spilled coolant.

Step 13: Check for Leaks

• With the engine running, inspect the thermostat housing and lower radiator hose area using a flashlight if available.
• If coolant seeps from the housing, shut the engine off and let it cool before retightening or reseating parts.
• Do not put your hands near the fan, belts, or pulleys while the engine is running.

---

✅ After Repair

• Let the engine cool completely, then recheck coolant level at the reservoir. Top off to the COLD mark if needed.
• Take a short test drive while watching the temperature gauge. It should rise normally and stay near the normal range.
• After the test drive, park and check again for leaks around the thermostat housing and hose connection.
• Check coolant level again the next morning when cold. Small air pockets may purge overnight.
• Dispose of old coolant properly at a recycling center or repair facility. Do not pour it on the ground or into drains.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $205-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
