🔧 Optima - Thermostat Replacement

The thermostat controls coolant flow so your engine warms up quickly and then stays at the correct temperature. If it sticks open you may get low heat and poor fuel economy; if it sticks closed you can overheat.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Only work on a fully cold engine; hot coolant can cause severe burns.
• ⚠️ Support your Optima with jack stands before going underneath.
• ⚠️ Keep coolant off belts/alternator and clean spills immediately (coolant is toxic).
• ⚠️ Do not open the radiator cap when hot; pressure can spray coolant.
• ⚠️ Battery disconnect is not required, but keep tools away from the cooling fan (it can turn on unexpectedly).

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Drain pan (at least 10-quart)
• Funnel
• Shop rags
• Trim clip removal tool
• Phillips screwdriver
• 10mm socket
• 12mm socket
• 3/8" ratchet
• 3/8" torque wrench (10–80 Nm range)
• 3/8" extension set
• Hose clamp pliers
• Plastic gasket scraper

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Thermostat assembly (with seal/O-ring) - Qty: 1
• Long-life coolant (phosphate OAT type, 50/50 premix) - Qty: 1-2 gallons
• Distilled water - Qty: 1 gallon
• Lower radiator hose clamp (optional) - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool completely (ideally overnight).
• Set the cabin HVAC to HOT later during bleeding to help purge air.
• Tip: Take a photo of hose routing first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the front and remove the splash shield

• Use a floor jack to lift the front jacking point, then support with jack stands.
• Remove the engine under cover/splash shield using a trim clip removal tool and Phillips screwdriver.

Step 2: Drain the coolant

• Place a drain pan under the radiator.
• Slowly loosen the radiator cap to the first stop (pressure check). Remove it fully only if there is no hiss.
• Drain coolant from the radiator drain (if equipped) into the pan. If your drain is hard to access, you can drain by removing the lower radiator hose in Step 3.

Step 3: Access the thermostat housing

• Locate the thermostat housing at the end of the lower radiator hose on the engine side.
• Use hose clamp pliers to compress the hose clamp and slide it back on the hose.
• Twist and pull the hose off the housing (catch remaining coolant with the drain pan and shop rags).
• Tip: Twist the hose to break it loose.

Step 4: Remove the thermostat housing

• Remove the housing mounting bolts using a 10mm socket (some fasteners may be 12mm socket depending on housing version).
• Pull the housing straight off and remove the thermostat/seal.
• Use a plastic gasket scraper to clean the mating surface (no deep scraping).

Step 5: Install the new thermostat assembly

• Install the new thermostat and seal/O-ring exactly as the old one came out.
• Reinstall the housing and hand-start bolts to avoid cross-threading.
• Tighten housing bolts evenly with a 3/8" ratchet, then final-tighten with a 3/8" torque wrench: Torque to 10–12 Nm (7–9 ft-lbs).
• Tip: Tighten in a crisscross pattern.

Step 6: Reinstall the lower radiator hose

• Push the hose fully onto the housing.
• Reposition the clamp in the original location using hose clamp pliers.
• Wipe everything dry with shop rags so leaks are easy to spot later.

Step 7: Refill coolant

• Use a funnel to refill with 50/50 long-life coolant (or correct mix using distilled water if using concentrate).
• Fill the coolant reservoir to the correct level line.

Step 8: Bleed air and verify operation

• Start the engine and let it idle with the radiator cap off.
• Set heat to HOT and fan to medium.
• As the engine warms up, add coolant as the level drops. Watch for steady small bubbles to stop.
• When the upper radiator hose gets hot and you feel coolant flow (thermostat opened), install the radiator cap.
• Let the engine reach normal temperature and confirm the cooling fan cycles.

Step 9: Reinstall splash shield and lower the car

• Reinstall the under cover using the trim clip removal tool and Phillips screwdriver.
• Lower the vehicle using the floor jack and remove jack stands.

---

✅ After Repair

• Check for leaks around the thermostat housing and lower radiator hose with the engine running.
• Road-test for 10–15 minutes, then recheck the coolant level after it cools down and top off as needed.
• Verify the temperature gauge stays normal and cabin heat works well.
• Dispose of old coolant properly (never pour it on the ground).

---
