🔧 LaCrosse - Thermostat Replacement

On your LaCrosse, the thermostat controls engine temperature by opening to let coolant flow to the radiator. If it sticks open you can get low temperature and poor heat; if it sticks closed you can overheat. This job involves draining some coolant, swapping the thermostat/housing, then refilling and bleeding air from the cooling system.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap on a hot engine; scalding coolant can spray out.
• ⚠️ Support the car with jack stands if you lift it; never rely on a jack alone.
• ⚠️ Keep coolant off belts and electrical connectors, and clean spills immediately (coolant is toxic to pets).
• ⚠️ Battery disconnect is not required for this repair, but keep tools away from the battery terminals.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 10-quart)
• Funnel
• Metric socket set with ratchet
• 10mm socket
• 8mm socket
• 6-inch extension
• Torque wrench (inch-pound)
• Flathead screwdriver
• Hose clamp pliers
• Trim clip remover
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Thermostat assembly with housing and seal - Qty: 1
• Engine coolant (Dex-Cool 50/50 premix) - Qty: 2-3 gallons
• Hose clamp - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool fully (ideally overnight) before opening the cooling system.
• Set the heater to MAX HEAT during the final bleed step so coolant flows through the heater core.
• Assumption: thermostat is in the upper/front engine water outlet.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve pressure safely

• Slowly loosen the coolant surge tank cap by hand only (do not use tools).
• If you hear hissing, tighten it back and wait longer for the engine to cool.

Step 2: Raise the front (optional but helpful)

• Use a floor jack to lift the front at the proper jacking point.
• Set the car onto jack stands and gently shake the car to confirm it’s stable.

Step 3: Drain enough coolant to get below the thermostat

• Place a drain pan under the radiator drain area.
• Remove the lower splash shield fasteners using a trim clip remover and 8mm socket as needed.
• Open the radiator drain cock using a flathead screwdriver and drain 1-2 gallons (enough so the level drops below the upper hoses).
• Close the drain cock firmly by hand with the flathead screwdriver (snug, do not over-tighten).

Step 4: Remove the intake ducting for access

• Loosen the intake hose clamps using an 8mm socket or flathead screwdriver.
• Lift the intake duct/air snorkel out and set it aside.
• Tip: Take a quick photo before unplugging anything.

Step 5: Locate the thermostat housing/water outlet

• Follow the upper radiator hose to the engine; it connects near the thermostat housing.
• Wipe the area with shop rags so dirt doesn’t fall into the opening.

Step 6: Remove the hose from the thermostat housing

• Use hose clamp pliers to compress the spring clamp and slide it back on the hose.
• Twist the hose gently to break it loose, then pull it off.
• Tip: Don’t pry hard on plastic fittings.

Step 7: Remove the thermostat housing bolts

• Remove the housing bolts using a 10mm socket, ratchet, and 6-inch extension.
• Lift the thermostat housing off carefully; some coolant will spill, so keep the drain pan underneath.

Step 8: Clean the sealing surface

• Use shop rags to wipe the engine mating surface clean.
• Do not scrape aggressively; you don’t want to gouge aluminum or crack plastic.

Step 9: Install the new thermostat assembly

• Position the new thermostat/housing and make sure the seal sits flat and is not pinched.
• Start all bolts by hand first (this prevents cross-threading).
• Tighten bolts evenly using a 10mm socket.
• Final tighten using an inch-pound torque wrench (a torque wrench measures bolt tightness accurately): Torque to 10 Nm (89 in-lbs).

Step 10: Reinstall the hose and intake ducting

• Slide the hose fully onto the fitting, then reposition the clamp using hose clamp pliers.
• Reinstall the intake ducting and tighten clamps using an 8mm socket or flathead screwdriver.

Step 11: Refill coolant

• Use a funnel and fill the surge tank with Dex-Cool 50/50 premix to the COLD line.
• Leave the cap off for the initial air purge.

Step 12: Bleed air and verify operation

• Start the engine and let it idle.
• Set HVAC to heat: high temp, low fan at first.
• Watch the coolant level and add as needed with the funnel.
• When the engine warms up, the upper hose should get hot (thermostat opening).
• Once bubbles stop and the level stabilizes, install the surge tank cap by hand.
• Let it reach normal operating temperature, then shut it off and let it cool completely.
• Recheck level and top off to the COLD line.

---

✅ After Repair

• Test drive 10-15 minutes while watching the temperature gauge for normal operation.
• After the test drive and full cool-down, recheck coolant level and inspect for leaks around the thermostat housing and hose connection.
• If you spilled coolant, rinse the area with water and dispose of old coolant properly.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $60-$140 (parts only)

You Save: $210-$590 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
