🔧 Altima - Thermostat Replacement

The thermostat controls coolant flow to help your engine warm up quickly and then stay at the correct temperature. On your Altima, it sits in the water inlet housing where the lower radiator hose connects to the engine, so you’ll drain some coolant, swap the thermostat (and seal), then bleed air out of the cooling system.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the cooling system hot; severe burns risk.
• ⚠️ Support the car with jack stands; never rely on a jack.
• ⚠️ Coolant is toxic—keep away from kids/pets; clean spills.
• ⚠️ Work gently around radiator fins; they bend easily.
• 🔋 Battery disconnect is not required, but keep tools away from the battery terminals.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 2-gallon)
• 10mm socket
• 3/8" drive ratchet
• 3/8" drive extension set
• Torque wrench (inch-pound)
• Hose clamp pliers
• Flat-blade screwdriver
• Trim clip removal tool
• Funnel
• Spill-free coolant funnel kit (specialty)
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine thermostat - Qty: 1
• Thermostat seal / O-ring - Qty: 1
• Engine coolant (Nissan Long Life Antifreeze/Coolant or equivalent blue, premixed 50/50) - Qty: 2-3 gallons
• Lower radiator hose clamp - Qty: 1 (optional if yours is weak)

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool completely (overnight is best).
• Raise the front of the car with a floor jack and set it on jack stands.
• Set your HVAC to heat later during bleeding (this helps purge air).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield (under cover)

• Use a floor jack (rated 2-ton minimum) and jack stands (rated 2-ton minimum) to safely support the front of the car.
• Use a trim clip removal tool and 10mm socket with a 3/8" drive ratchet to remove the clips/bolts holding the under cover.

Step 2: Drain coolant from the radiator

• Place a drain pan (at least 2-gallon) under the radiator drain cock area.
• Open the radiator drain cock using a flat-blade screwdriver (turn slowly) and let coolant drain.
• Once flow slows, close the drain cock with the flat-blade screwdriver (snug only—do not over-tighten).

Step 3: Locate the thermostat housing (water inlet)

• Follow the lower radiator hose to where it connects to the engine—this connection is the thermostat/water inlet housing area.
• Wipe the area with shop towels so dirt can’t fall inside when opened.

Step 4: Remove the lower radiator hose from the thermostat housing

• Use hose clamp pliers to compress the clamp and slide it back on the hose.
• Twist the hose gently to break it free (do not pry hard on the housing), then pull it off.
• Expect more coolant to drain—keep the drain pan (at least 2-gallon) underneath.

Step 5: Remove the thermostat housing

• Use a 10mm socket, 3/8" drive ratchet, and 3/8" drive extension set to remove the housing bolts.
• Carefully separate the housing and remove the thermostat.
• Note the thermostat orientation before removal (install the new one the same way).

Step 6: Clean the sealing surfaces

• Use shop towels to clean the mating surfaces on the housing and engine.
• Do not gouge the aluminum surfaces. Clean and flat is the goal.

Step 7: Install the new thermostat and seal

• Install the new thermostat seal / O-ring onto the thermostat or housing as designed.
• Set the new engine thermostat into position (same orientation as removed).
• Reinstall the housing and start all bolts by hand to avoid cross-threading.
• Use a torque wrench (inch-pound) with a 10mm socket to tighten the housing bolts evenly: Torque to 10 N·m (89 in-lbs).

Step 8: Reinstall the lower radiator hose

• Push the hose fully onto the housing neck.
• Use hose clamp pliers to move the clamp back to its original position.
• If the clamp feels weak or doesn’t clamp evenly, replace it.

Step 9: Reinstall the under cover

• Use the trim clip removal tool to align clips and a 10mm socket with a 3/8" drive ratchet to reinstall bolts.
• Lower the car safely from the jack stands (rated 2-ton minimum) using the floor jack (rated 2-ton minimum).

Step 10: Refill and bleed the cooling system

• Refill with engine coolant (Nissan Long Life Antifreeze/Coolant or equivalent blue, premixed 50/50) using a funnel.
• Install a spill-free coolant funnel kit (specialty) (it’s a funnel with adapters that seals to the radiator fill neck to help push air out without spilling).
• Start the engine and set HVAC to full heat.
• Let the engine idle until it reaches operating temperature; watch for bubbles in the funnel as air purges.
• Once the radiator fan cycles on/off and bubbles stop, shut the engine off and let it cool.
• Top off the radiator and overflow reservoir to the correct level using the funnel.

---

✅ After Repair

• Check carefully for leaks around the thermostat housing and lower radiator hose while idling.
• Road test 10-15 minutes and confirm the temperature gauge stays normal and cabin heat is strong.
• Let the engine cool completely, then recheck coolant level and top off if needed.
• If you get overheating, no cabin heat, or gurgling sounds, there’s likely trapped air—repeat the bleed step.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $60-$150 (parts only)

You Save: $200-$500 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3 hours.

---
