🔧 Patriot - Thermostat Replacement

The thermostat regulates engine temperature by controlling coolant flow to the radiator. If it sticks closed you can overheat; if it sticks open you may get slow warm-up and poor heater output. This job involves draining some coolant, removing the thermostat housing, and refilling/bleeding the cooling system.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

Assumption: 2.0L uses a thermostat inside a bolt-on housing at the engine end of the upper radiator hose.

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap on a hot engine; let it cool fully.
• ⚠️ Coolant is toxic—wear gloves and clean spills immediately.
• ⚠️ Support the vehicle with jack stands if you raise it; never rely on a jack.
• ⚠️ Keep coolant off belts and electrical connectors.
• 🔋 Battery disconnect is not required, but keep tools away from the battery terminals.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Drain pan (at least 10-quart)
• Funnel
• Spill-free coolant funnel kit (specialty)
• 3/8" drive ratchet
• 3/8" drive extension set
• 10mm socket
• 8mm socket
• Flat-blade screwdriver
• Hose clamp pliers (specialty)
• Torque wrench (in-lb or low-range ft-lb)
• Plastic scraper
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine thermostat - Qty: 1
• Thermostat housing gasket or O-ring - Qty: 1
• Engine coolant - Qty: 1-2 gallons
• Distilled water - Qty: 1-2 gallons

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool completely (upper radiator hose should feel cool).
• Set the HVAC temperature to full HOT during bleeding later so coolant flows through the heater core.
• Place a drain pan under the radiator area before loosening any hoses.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve pressure and access the cooling system

• Put on safety glasses and nitrile gloves.
• Slowly loosen the coolant reservoir cap by hand (only when cold) to relieve any residual pressure.
• If needed for access, raise the front with a floor jack (rated 2-ton minimum) and support with jack stands (rated 2-ton minimum).

Step 2: Drain enough coolant to get below the thermostat level

• Position a drain pan (at least 10-quart) under the radiator drain area.
• Open the radiator drain (if equipped) using a flat-blade screwdriver, or loosen the lower radiator hose clamp using hose clamp pliers (specialty) and carefully crack the hose loose to drain.
• Drain about 1–2 gallons—enough so coolant level is below the thermostat housing.

Step 3: Locate the thermostat housing

• Follow the upper radiator hose by hand from the radiator to the engine; the hose connects to the thermostat housing.
• Place shop rags under the housing to catch spills.

Step 4: Remove the upper radiator hose from the thermostat housing

• Use hose clamp pliers (specialty) to compress the spring clamp, then slide it back on the hose.
• Twist the hose gently to break it free, then pull it off.
• If stuck, twist—don’t pry hard.

Step 5: Remove the thermostat housing

• Remove any nearby intake ducting if it blocks access using an 8mm socket and flat-blade screwdriver.
• Remove the thermostat housing bolts using a 10mm socket with a 3/8" drive ratchet and 3/8" drive extension.
• Lift the housing off carefully; more coolant will spill into the drain pan.

Step 6: Replace the thermostat and seal

• Remove the old thermostat and the old gasket/O-ring by hand.
• Clean the mating surfaces using a plastic scraper and shop rags. (Mating surface = the flat sealing surfaces where the housing meets the engine.)
• Install the new thermostat in the same orientation as the old one.
• Install the new gasket/O-ring (do not reuse the old seal).

Step 7: Reinstall the thermostat housing

• Set the housing into place by hand and start all bolts by hand to avoid cross-threading.
• Tighten bolts evenly using a 10mm socket.
• Final tighten with a torque wrench (in-lb or low-range ft-lb): Torque to 12 Nm (106 in-lb).

Step 8: Reinstall the hose and any removed ducting

• Reinstall the upper radiator hose and reposition the clamp using hose clamp pliers (specialty).
• Reinstall any intake ducting using an 8mm socket and flat-blade screwdriver.

Step 9: Refill and bleed the cooling system

• Close the radiator drain (if opened) using a flat-blade screwdriver.
• Mix coolant with distilled water as required (many coolants are 50/50 premix—read the jug). Use a funnel to refill the reservoir.
• Install a spill-free coolant funnel kit (specialty) on the reservoir neck and fill to the proper level.
• Start the engine and let it idle. Set heat to HOT and fan to LOW.
• As the engine warms up, watch for air bubbles in the funnel and add coolant as the level drops.
• If your Patriot has a coolant bleeder screw near the thermostat/hose area, crack it open slightly using an 8mm socket until a steady stream of coolant flows (no bubbles), then snug it closed.
• When the radiator fan cycles on/off and heat blows hot, shut the engine off and let it cool.
• Top off the reservoir to the correct line using a funnel.

---

✅ After Repair

• Start the engine and verify the temperature gauge rises to normal and stays steady.
• Check for leaks at the thermostat housing and hose connection with a bright light.
• Road test 10–15 minutes, then recheck coolant level after a full cool-down and top off if needed.
• If you get overheating, no heat, or gurgling sounds, air is still trapped—repeat the bleed process.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $45-$140 (parts only)

You Save: $205-$605 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
