🔧 Fusion - Thermostat Replacement

The thermostat controls engine temperature by opening and closing coolant flow to the radiator. If it sticks open you may get slow warm-up/poor heat; if it sticks closed you can overheat. On your Fusion’s 2.5L, the thermostat sits in a housing where a radiator hose meets the engine.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant reservoir cap on a hot engine; hot coolant can spray and burn you.
• ⚠️ The cooling fan can turn on by itself; keep hands/tools clear and disconnect the battery negative terminal.
• ⚠️ Support the car with jack stands on solid ground; never rely on a jack alone.
• ⚠️ Collect coolant in a drain pan and dispose of it properly; it’s toxic to people and pets.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 2-gallon)
• Funnel
• Shop towels
• 7mm nut driver
• 8mm socket
• 10mm socket
• 1/4" ratchet
• 3" extension (1/4" drive)
• Torque wrench (in-lb or small Nm range)
• Hose clamp pliers
• Trim clip removal tool
• Flathead screwdriver
• Plastic scraper

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Thermostat (with housing seal/O-ring) - Qty: 1
• Engine coolant (Ford-spec, prediluted 50/50) - Qty: 1-2 gallons
• Hose clamp (replacement, if original is weak or damaged) - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool completely (ideally 2+ hours).
• Disconnect the battery negative terminal using a 10mm socket to prevent the cooling fan from turning on unexpectedly.
• Assumption: Thermostat is in the hose-to-engine housing; bolt torques listed are typical for this setup—use service information if you have it.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve pressure safely

• Put on safety glasses and nitrile gloves.
• Slowly loosen the coolant reservoir cap only when the engine is fully cool, then remove it.

Step 2: Raise the front of the car (if needed for access)

• Lift the front with a floor jack (rated 3-ton minimum).
• Set it onto jack stands (rated 3-ton minimum) at the proper support points.

Step 3: Drain enough coolant

• Place a drain pan (at least 2-gallon) under the radiator drain area.
• If equipped with a drain cock, open it using a flathead screwdriver and drain until the level is below the thermostat area.
• If there’s no easy drain access, you can drain by loosening the lower hose clamp later—keep the drain pan positioned and be ready for flow.

Step 4: Remove the air intake ducting for access

• Loosen intake hose clamps with a 7mm nut driver.
• Remove any clips using a trim clip removal tool.
• Lift the ducting out and set it aside.

Step 5: Locate the thermostat housing

• Follow the large radiator hose to where it meets the engine; that connection point is the thermostat housing area.
• Clean around the housing with shop towels so dirt doesn’t fall inside.

Step 6: Remove the radiator hose from the housing

• Slide the clamp back using hose clamp pliers.
• Twist the hose to break it free, then pull it off.
• Direct coolant into the drain pan.
• Tip: Twisting first prevents tearing the hose.

Step 7: Unbolt and remove the thermostat housing

• Remove the housing bolts using an 8mm socket or 10mm socket (varies by fastener).
• Use a 3" extension (1/4" drive) if bolts are recessed.
• Pull the housing straight off and note the seal/O-ring position.

Step 8: Clean the mating surfaces

• Use a plastic scraper to remove old seal material or stuck debris.
• Wipe the surface clean with shop towels.
• Do not gouge the aluminum surface.

Step 9: Install the new thermostat and seal

• Fit the new seal/O-ring onto the thermostat/housing (same orientation as the old one).
• Reinstall the housing onto the engine by hand-aligning it first.
• Start all bolts by hand to avoid cross-threading.
• Tighten bolts evenly using an 8mm socket or 10mm socket.
• Torque to 10 Nm (89 in-lbs) using a torque wrench (in-lb or small Nm range).

Step 10: Reinstall the radiator hose

• Push the hose fully onto the housing.
• Reposition the clamp with hose clamp pliers in the same spot it was originally.

Step 11: Reinstall the air intake ducting

• Reinstall ducting and clips using a trim clip removal tool (as needed).
• Tighten hose clamps with a 7mm nut driver.

Step 12: Refill and bleed (remove trapped air)

• Lower the vehicle if it was raised.
• Refill the coolant reservoir slowly using a funnel with the correct prediluted 50/50 coolant.
• Reconnect the battery negative terminal using a 10mm socket.
• Start the engine and set the heater to HOT and the fan to LOW.
• Let it idle and watch the coolant level; top off as it drops. Use shop towels to catch small spills.
• Once the engine reaches operating temp and you get steady heat, shut it off and let it cool completely, then recheck and top off again.

---

✅ After Repair

• Check carefully for leaks around the thermostat housing and hose connection with the engine idling.
• Verify the temperature gauge behaves normally and the heater blows hot air.
• After your first short drive, let the engine cool and recheck the coolant level again.
• If the check engine light comes on, have the codes scanned (cooling system codes can set if air is trapped).

---

💰 DIY vs Shop Cost

Shop Cost: $350-$700 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $170-$640 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3 hours.

---
