🔧 Forester - Thermostat Replacement

Your Forester’s thermostat controls coolant flow to keep engine temperature stable. If it sticks closed you’ll overheat; if it sticks open you may get low heat and poor fuel economy. This job involves draining coolant, swapping the thermostat at the water pump housing, then refilling and bleeding air.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the radiator cap on a hot engine; scalding coolant risk.
• ⚠️ Support the vehicle with jack stands if you lift it; never rely on a jack.
• ⚠️ Keep coolant away from pets and kids; it’s toxic and attractive-tasting.
• ⚠️ Use only the correct coolant type for your Forester; mixing types can cause sludge/corrosion.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Wheel chocks
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 2-ton minimum) x2
• Drain pan (at least 2-gallon)
• Funnel (spill-free coolant funnel preferred)
• Shop rags
• 10mm socket
• 3/8" ratchet
• 3" extension
• Torque wrench (5–30 Nm range)
• Slip-joint pliers
• Flathead screwdriver
• Trim clip removal tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine thermostat - Qty: 1
• Thermostat gasket / seal - Qty: 1
• Coolant (Subaru Super Coolant equivalent, pre-mixed 50/50) - Qty: 2 gallons
• Lower radiator hose clamp - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool completely (best: sit overnight).
• Set the climate controls to HOT (this helps coolant flow through the heater core during bleeding).
• If you raise the front, lift with a floor jack and support with jack stands at the proper front support points.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve any residual pressure (cold engine only)

• Slowly loosen the radiator cap by hand using a shop rag for grip.
• If you hear pressure, stop and wait until it fully releases, then remove the cap.

Step 2: Drain the coolant

• Position a drain pan (at least 2-gallon) under the lower radiator area.
• Open the radiator drain (if accessible) by hand; if a splash shield is in the way, remove the clips with a trim clip removal tool.
• If your drain uses a small screw-style plug, turn carefully with a flathead screwdriver (do not force it).
• Tip: Save coolant only if it’s clean and fresh.

Step 3: Make room to access the thermostat housing

• Remove any intake snorkel/ducting that blocks access using a flathead screwdriver (for hose clamps) and a 10mm socket (for bolts, if equipped).
• Locate the thermostat housing at the end of the lower radiator hose on the front/lower part of the engine (water pump inlet).
• Thermostat housing = the metal neck the hose connects to.

Step 4: Remove the lower radiator hose from the thermostat housing

• Squeeze and slide the spring clamp back using slip-joint pliers, or loosen a worm clamp with a flathead screwdriver.
• Twist the hose to break it loose, then pull it off the housing.
• Catch remaining coolant in the drain pan.

Step 5: Remove the thermostat housing

• Remove the thermostat housing bolts using a 10mm socket, 3/8" ratchet, and 3" extension.
• Gently separate the housing and remove the thermostat.
• Clean both mating surfaces with a shop rag (no deep scratching).

Step 6: Install the new thermostat and seal

• Install the new thermostat gasket / seal onto the new thermostat (as supplied).
• Install the thermostat into the engine side in the same orientation as removed.
• If the thermostat has a small “jiggle valve” air bleeder, position it at the top (12 o’clock).
• Reinstall the housing and start bolts by hand to avoid cross-threading.
• Tighten with a torque wrench (5–30 Nm range): Torque to 10 Nm (7.4 ft-lbs).

Step 7: Reconnect the lower radiator hose

• Push the hose fully onto the thermostat housing neck.
• Reposition the clamp using slip-joint pliers (or tighten with a flathead screwdriver if worm clamp).
• If the clamp is weak or damaged, replace it with the new lower radiator hose clamp.

Step 8: Refill coolant and bleed air

• Install a funnel at the radiator fill neck and fill with coolant (pre-mixed 50/50) until full.
• Fill the overflow tank to the FULL line.
• Start the engine and let it idle; keep the heater set to HOT.
• As the engine warms up, watch the coolant level in the funnel and add as needed.
• When the thermostat opens, you should see coolant begin to flow and the level may drop—top off again.
• Once bubbles mostly stop and heat blows hot, install the radiator cap.
• Tip: Don’t rev a cold engine to “bleed faster”.

Step 9: Reinstall any removed ducting and shields

• Reinstall the intake snorkel/ducting using a 10mm socket and flathead screwdriver as needed.
• Reinstall any lower splash shield clips using the trim clip removal tool.

---

✅ After Repair

• With the engine fully warm, confirm the temperature gauge stays normal and cabin heat is steady.
• Check for leaks around the thermostat housing and lower radiator hose.
• Let the engine cool completely, then recheck the radiator level and overflow tank; top off as needed.
• Over the next 1–2 drives, keep an eye on coolant level and any coolant smell.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $60-$150 (parts only)

You Save: $200-$500 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
