🔧 Edge - Thermostat Replacement

On your Edge, the thermostat is part of a coolant outlet/thermostat housing that controls engine temperature. Replacing it typically means draining some coolant, removing the housing at the front (radiator side) of the 2.0L engine, and refilling/bleeding the cooling system.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• 🛑 Never open the coolant cap on a hot engine; wait until fully cool.
• 🧪 Coolant is toxic—use a drain pan and keep it away from kids/pets.
• 🧯 Support the vehicle with jack stands; never rely on a jack alone.
• 🧤 Wear gloves and safety glasses; coolant can irritate skin/eyes.
• 🔌 Battery disconnect is not required, but keep tools away from the electric fan area.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 2-gallon)
• Funnel
• Shop towels
• 8mm socket
• 10mm socket
• 1/4" ratchet
• 3" and 6" socket extensions
• Torque wrench (inch-pound)
• Hose clamp pliers
• Trim clip removal tool
• Flat-blade screwdriver

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Thermostat housing assembly (with seal/gasket) - Qty: 1
• Engine coolant (Motorcraft Yellow prediluted 50/50 or equivalent) - Qty: 1-2 gallons
• Lower radiator hose clamp - Qty: 1 (only if your clamp is damaged)

---

📋 Before You Begin

• Park on level ground, set the parking brake, and let the engine cool completely.
• Place wheel chocks behind the rear wheels.
• Set your drain pan under the radiator/engine area before loosening any hose.
• Hose clamp pliers are pliers that lock and hold spring clamps open.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the front and remove the lower splash shield

• Use a floor jack to lift the front of the Edge at the proper lift point.
• Set the vehicle securely on jack stands.
• Remove the lower splash shield fasteners using an 8mm socket and trim clip removal tool.

Step 2: Relieve pressure and drain coolant to a safe level

• Slowly loosen the coolant reservoir cap (degas bottle) by hand to release any residual pressure.
• Position a drain pan under the lower radiator hose/thermostat area.
• Drain coolant by loosening the radiator drain (if accessible) with a flat-blade screwdriver, or drain by disconnecting the lower radiator hose in Step 3.

Step 3: Disconnect the lower radiator hose from the thermostat housing

• Locate the thermostat housing at the front (radiator side) of the engine where the lower radiator hose connects.
• Use hose clamp pliers to open the spring clamp and slide it back on the hose.
• Carefully twist the hose to break it loose, then pull it off the housing (catch coolant in the drain pan).
• Twist first—pulling straight can tear the hose.

Step 4: Unplug the electrical connector (if equipped on your housing)

• If your thermostat housing has an electrical connector, press the tab and disconnect it by hand.
• If it’s stubborn, use a flat-blade screwdriver gently on the lock tab (don’t pry hard).

Step 5: Remove the thermostat housing

• Remove the thermostat housing bolts using a 10mm socket, 1/4" ratchet, and socket extensions.
• Pull the housing straight off and remove the old seal/gasket (use shop towels to catch remaining coolant).

Step 6: Clean the sealing surface and install the new housing

• Wipe the engine mating surface clean with shop towels. Do not gouge the surface.
• Install the new thermostat housing with the new seal/gasket in place.
• Start all bolts by hand, then tighten evenly using a 10mm socket.
• Final tighten using a torque wrench (inch-pound): Torque to 10 Nm (89 in-lbs).

Step 7: Reconnect the hose and connector

• Reinstall the lower radiator hose onto the housing.
• Use hose clamp pliers to position the spring clamp back in its original spot.
• Reconnect the electrical connector (if equipped) by hand until it clicks.

Step 8: Refill coolant and bleed air

• Lower the vehicle from the jack stands using the floor jack.
• Refill the degas bottle using a funnel with Motorcraft Yellow 50/50 coolant to the MAX line.
• If equipped with an air bleed screw near the upper coolant line, open it with an 8mm socket until coolant flows without bubbles, then close it. Torque to 2 Nm (18 in-lbs).
• Start the engine and let it idle with the heater set to HOT.
• As the engine warms up, top off coolant as the level drops. Install the cap once the level stabilizes.

Step 9: Reinstall the splash shield

• Reinstall the lower splash shield using the 8mm socket and trim clip removal tool.

---

✅ After Repair

• Bring the engine to full operating temperature and confirm the cabin heat is strong and steady.
• Check for leaks at the thermostat housing and lower radiator hose connection.
• After a full cool-down, recheck the degas bottle level and top off to MAX if needed.
• If the check engine light was on (overheat/thermostat code), clear codes with a scan tool and confirm they do not return.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$900 (parts + labor)

DIY Cost: $80-$220 (parts only)

You Save: $230-$820 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
