🔧 Cherokee - Thermostat Replacement

The thermostat controls engine temperature by opening and closing coolant flow to the radiator. If it sticks open you’ll run cool (poor heat, poor fuel economy), and if it sticks closed you can overheat. On your Cherokee, the thermostat is typically serviced as part of the thermostat housing/coolant outlet assembly.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap on a hot engine; wait until fully cool.
• ⚠️ Support the Cherokee with jack stands before working underneath.
• ⚠️ Coolant is toxic; keep it away from kids and pets and clean spills immediately.
• ⚠️ Keep hands/tools away from the radiator fan; it can turn on unexpectedly.
• Disconnecting the battery is not strictly required, but it’s safer if you’ll be near wiring and the cooling fan.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 2-gallon)
• Trim clip removal tool
• Flathead screwdriver
• 1/4" drive ratchet
• 3/8" drive ratchet
• Socket set (8mm, 10mm, 13mm)
• Torx bit set (T25, T30)
• Extensions (3" and 6")
• Hose clamp pliers
• Pick tool
• Torque wrench (in-lb or low-range Nm)
• Funnel
• Rags/shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Thermostat housing assembly (with thermostat) - Qty: 1
• Thermostat housing seal/O-ring - Qty: 1
• Engine coolant (Mopar OAT compatible) - Qty: 1-2 gallons
• Distilled water - Qty: 1-2 gallons
• Hose clamp(s) - Qty: 1-3

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Let the engine cool completely (upper radiator hose should feel cool).
• Set the HVAC to Heat (full hot) later during bleeding to help purge air.
• Hose clamp pliers pinch spring clamps safely. (They lock onto the clamp so it doesn’t snap your fingers.)

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the front and remove the lower shield (if equipped)

• Use a floor jack (rated 3-ton minimum) to lift the front and support with jack stands (rated 3-ton minimum).
• Use a trim clip removal tool and Torx T25/T30 bit (as equipped) to remove the lower engine splash shield fasteners.
• Set the shield and fasteners aside in a small tray.

Step 2: Relieve residual pressure and drain coolant

• Place a drain pan (at least 2-gallon) under the radiator drain area.
• Slowly loosen the coolant reservoir cap by hand to release any residual pressure, then remove it.
• Use a flathead screwdriver (if applicable) to open the radiator drain/petcock and drain coolant.
• If there is no easy drain access, use hose clamp pliers to remove the lower radiator hose clamp and carefully twist the hose off to drain. Use rags/shop towels for spills.

Step 3: Remove the air intake ducting for access

• Use an 8mm socket or flathead screwdriver to loosen the intake hose clamps.
• Unclip/remove the intake duct and move it out of the way.

Step 4: Locate the thermostat housing and disconnect hoses

• Find the thermostat housing/coolant outlet where the upper radiator hose connects to the engine.
• Use hose clamp pliers to compress the spring clamp and slide it back on the hose.
• Gently twist the hose to break it free, then pull it off. If stuck, use a pick tool carefully around the hose end (do not gouge plastic).
• Disconnect any small coolant hoses on the housing the same way.

Step 5: Unplug sensors (if equipped on the housing)

• Press the lock tab and unplug any electrical connectors on/near the thermostat housing using your fingers or a pick tool gently.
• Don’t pull on wires—pull on the connector.

Step 6: Remove the thermostat housing

• Place rags/shop towels under the housing to catch leftover coolant.
• Use a 10mm socket, 1/4" drive ratchet, and extension to remove the thermostat housing bolts.
• Lift the housing straight off. Remove the old seal/O-ring if it stayed on the engine.

Step 7: Clean the sealing surface

• Use rags/shop towels to wipe the engine sealing surface clean and dry.
• Do not use aggressive scraping on aluminum or plastic mating surfaces.

Step 8: Install the new thermostat housing and torque bolts

• Install the new seal/O-ring on the new housing (or in the groove) exactly as it came.
• Set the new housing in place and start all bolts by hand to avoid cross-threading.
• Use a torque wrench (in-lb or low-range Nm) and 10mm socket to tighten evenly.
• Torque to 12 Nm (106 in-lb)

Step 9: Reconnect hoses and electrical connectors

• Push hoses fully onto their fittings.
• Use hose clamp pliers to position clamps back in their original locations.
• Reconnect all electrical connectors until they click.

Step 10: Reinstall the intake and lower shield

• Reinstall the air intake ducting and tighten clamps using an 8mm socket or flathead screwdriver.
• Reinstall the splash shield using a Torx T25/T30 bit and trim clip removal tool as needed.
• Lower the Cherokee using the floor jack.

Step 11: Refill coolant and bleed air

• Mix coolant to a 50/50 ratio using engine coolant (Mopar OAT compatible) and distilled water unless your coolant comes pre-mixed.
• Use a funnel to slowly fill the coolant reservoir to the MAX line.
• Start the engine and let it idle. Set HVAC to Heat and low fan.
• Watch the temperature gauge and check for leaks around the housing and hose connections.
• As the thermostat opens, the coolant level may drop—add as needed.
• Shut the engine off, let it cool fully, then recheck and top off to MAX.

---

✅ After Repair

• Test drive 10–15 minutes and confirm normal temperature and good cabin heat.
• Park, let it cool, then recheck coolant level and inspect for seepage at the thermostat housing.
• Check for a coolant smell or wet spots over the next 2–3 drives.
• Dispose of old coolant properly (local recycling/parts store collection).

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $390-$670 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
