🔧 Equinox - Thermostat Replacement

Your Equinox’s thermostat controls engine operating temperature by opening to let coolant flow to the radiator. When it sticks closed (overheats) or open (runs cold), replacing the thermostat housing assembly restores proper temperature control.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap on a hot engine; hot coolant can spray and burn.
• ⚠️ Support the vehicle with jack stands before working underneath.
• ⚠️ Coolant is toxic—keep it off skin/paint and away from pets/kids; clean spills immediately.
• ⚠️ Let the engine cool fully (at least 2–3 hours) before draining coolant.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Wheel chocks
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Drain pan (at least 2-gallon)
• Funnel
• Shop towels
• 1/4" drive ratchet
• 3" extension (1/4" drive)
• 6" extension (1/4" drive)
• 7mm socket
• 8mm socket
• 10mm socket
• Torque wrench (inch-pound)
• Hose clamp pliers
• Pick tool
• Plastic scraper

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Thermostat housing assembly (with seal/O-ring) - Qty: 1
• Dex-Cool coolant (50/50 premix) - Qty: 2-3 gallons
• Hose clamp (worm-gear or constant-tension, correct size) - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Allow the engine to cool completely. Remove the surge tank cap only when cool.
• Set the HVAC temperature to HOT for the refill/bleed step later (helps air purge from the heater core).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the front and prep for draining

• Place wheel chocks, then lift the front with a floor jack (rated 3-ton minimum).
• Support the vehicle on jack stands (rated 3-ton minimum).
• Position a drain pan (at least 2-gallon) under the radiator drain area.

Step 2: Drain the coolant

• Slowly loosen/remove the surge tank cap to release any remaining pressure (engine must be cool).
• Open the radiator drain (petcock) and drain into the drain pan (at least 2-gallon).
• Tip: Keep the drain pan centered—coolant spreads fast.

Step 3: Remove the intake ducting for access

• Remove the engine cover (if equipped) by pulling upward firmly at the corners.
• Loosen the intake tube clamps using an 8mm socket.
• Remove any air snorkel/duct fasteners using a 7mm socket as needed, then lift the ducting out.

Step 4: Locate the thermostat housing

• Find the thermostat housing at the engine-side connection of the lower radiator hose.
• Clean the area with shop towels so dirt doesn’t fall into the opening.

Step 5: Disconnect the lower radiator hose

• Use hose clamp pliers to compress the constant-tension clamp and slide it back on the hose.
• Twist the hose gently to break it loose; use a pick tool carefully if it’s stuck (don’t gouge the plastic housing).
• Pull the hose off and aim it into the drain pan (at least 2-gallon) for any remaining coolant.

Step 6: Remove the thermostat housing assembly

• Remove the thermostat housing mounting bolts using a 10mm socket with a 1/4" drive ratchet and extensions.
• Pull the housing straight off. More coolant will spill—keep the drain pan underneath.
• Remove the old seal/O-ring (if it stayed behind) using a pick tool.

Step 7: Clean the sealing surface

• Use a plastic scraper and shop towels to clean the mating surface.
• Do not use metal scrapers; they can gouge aluminum/plastic and cause leaks.

Step 8: Install the new thermostat housing

• Make sure the new seal/O-ring is properly seated on the new housing.
• Position the housing and start all bolts by hand to prevent cross-threading.
• Tighten bolts evenly using a 10mm socket, then final-tighten with a torque wrench (inch-pound): Torque to 10 Nm (89 in-lb).

Step 9: Reconnect the lower radiator hose

• Push the hose fully onto the housing.
• Reposition the clamp using hose clamp pliers so it sits in the original clamp “track” on the hose.
• If the clamp is weak or distorted, replace it with the correct-size new clamp.

Step 10: Reinstall the intake ducting

• Reinstall the intake ducting/snorkel and tighten fasteners using a 7mm socket as needed.
• Reinstall the intake tube and tighten clamps using an 8mm socket.
• Reinstall the engine cover (press down until it seats).

Step 11: Refill and bleed the cooling system

• Close the radiator drain (petcock).
• Fill the surge tank using a funnel with Dex-Cool coolant (50/50 premix) to the COLD line.
• Start the engine and let it idle with the cap off. Set the heater to HOT and blower on low.
• As the level drops, add coolant with the funnel to keep it near the COLD line.
• Watch for a steady stream/flow returning to the surge tank and for warm air from the vents (signs air is purging).
• Once it stabilizes, install the cap, then let the engine reach normal operating temperature.
• Shut it off, let it cool fully, then recheck and top off to the COLD line.

---

✅ After Repair

• Check for leaks around the thermostat housing and lower radiator hose with the engine running.
• Verify the temperature gauge reads normal and the heater blows hot.
• After the next full cool-down (or next morning), recheck coolant level and top off if needed.
• If you had overheating before, confirm the radiator fan cycles on/off normally.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $170-$590 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
