🔧 Cherokee - Thermostat Replacement

The thermostat controls coolant flow to help your engine warm up quickly and stay at the correct temperature. If it sticks open or closed, you can get slow warm-up, poor heat, overheating, or a check engine light. On your Cherokee, the thermostat is part of a thermostat housing assembly, so you’ll typically replace the whole housing.

Difficulty Level: Intermediate | Estimated Time: 1.5–3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap on a hot engine; pressurized coolant can cause burns.
• ⚠️ Support the vehicle with jack stands if you raise it—never rely on a floor jack alone.
• ⚠️ Keep coolant off belts and pulleys; wipe spills immediately.
• ⚠️ Coolant is toxic—catch it in a drain pan and dispose of it properly.
• Battery disconnect is not required for this job, but keep the key away from the vehicle while working.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 3-gallon)
• Funnel
• Spill-free coolant funnel kit (specialty)
• Trim clip removal tool
• Flathead screwdriver
• 8mm socket
• 10mm socket
• 13mm socket
• 1/4" drive ratchet
• 3/8" drive ratchet
• 3" extension
• Torque wrench (inch-pound)
• Hose clamp pliers (specialty)
• Pick tool
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Thermostat housing assembly (includes thermostat and seal) - Qty: 1
• Engine coolant (OAT type, Mopar-compatible) - Qty: 2–3 gallons (mix as directed)
• Upper radiator hose clamp - Qty: 1 (optional)
• Upper radiator hose - Qty: 1 (optional, if swollen/cracked)

---

📋 Before You Begin

• Park on level ground, set the parking brake, and let the engine cool fully (ideally overnight).
• Place a drain pan under the front of the engine/radiator area.
• Remove the coolant reservoir cap only when the engine is cold to release any leftover pressure.
• Take a quick photo of hose routing first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Make the vehicle safe and accessible

• Use wheel chocks behind the rear wheels.
• If you need more room underneath, lift the front with a floor jack (rated 3-ton minimum) and support it with jack stands (rated 3-ton minimum).

Step 2: Drain enough coolant for a clean thermostat swap

• Place the drain pan (at least 3-gallon) under the radiator area.
• Remove the lower splash shield if it blocks access using a trim clip removal tool and 8mm socket.
• Slowly open the coolant reservoir cap (engine cold) by hand.
• Drain coolant from the radiator drain (petcock) if accessible; use a flathead screwdriver if the style requires it.
• If the drain isn’t accessible, you can drain by loosening the lower radiator hose clamp using hose clamp pliers (specialty) and carefully slipping the hose enough to drain into the pan.
• Drain 1–2 gallons to reduce spilling.

Step 3: Remove the engine cover and air inlet duct

• Pull up to remove the engine cover by hand (it’s held by rubber grommets).
• Loosen the intake duct clamps using an 8mm socket or flathead screwdriver (depends on clamp style).
• Remove any fasteners holding the inlet duct with a 10mm socket, then lift the duct out.

Step 4: Locate the thermostat housing

• The thermostat housing sits at the front/top area of the engine where a large radiator hose connects.
• Wipe the area with shop towels so dirt doesn’t fall into the cooling system.

Step 5: Remove the radiator hose from the thermostat housing

• Use hose clamp pliers (specialty) to compress the hose clamp and slide it back on the hose.
• Twist the hose gently to break it loose. If it’s stuck, carefully work the edge with a pick tool (don’t gouge the plastic housing).
• Pull the hose off and aim any remaining coolant into the drain pan.

Step 6: Unbolt and remove the thermostat housing

• Unplug any connector(s) in your way using your fingers and a gentle assist from a pick tool if the lock tab is tight.
• Remove the thermostat housing mounting bolts using a 10mm socket with a 1/4" drive ratchet and 3" extension.
• Lift the housing out. Keep it upright to avoid spilling coolant.

Step 7: Clean the sealing surface

• Use shop towels to wipe the engine mating surface clean.
• Do not scrape aggressively—this is usually an aluminum surface and the housing is plastic.
• Make sure the old seal/gasket is fully removed (it should come off with the housing if it’s part of the assembly).

Step 8: Install the new thermostat housing assembly

• Confirm the new housing seal is seated properly before installation.
• Position the new thermostat housing and start all bolts by hand to prevent cross-threading.
• Tighten the bolts evenly using a 10mm socket.
• Final tighten with a torque wrench (inch-pound): Torque to 12 Nm (106 in-lbs).
• Snug + torque only—plastic cracks easily.

Step 9: Reinstall the radiator hose and clamps

• Push the hose fully onto the housing until it bottoms out.
• Use hose clamp pliers (specialty) to slide the clamp back into its original position.
• If the clamp feels weak or distorted, replace it.

Step 10: Reinstall the air inlet duct and engine cover

• Reinstall the inlet duct and fasteners using a 10mm socket.
• Tighten the hose clamps using an 8mm socket or flathead screwdriver.
• Press the engine cover back into the grommets by hand.

Step 11: Refill and bleed the cooling system

• Close the radiator drain (if used) by hand, then snug carefully (do not overtighten).
• Refill coolant at the reservoir using a funnel. Use the correct engine coolant (OAT type, Mopar-compatible) mixture as directed on the bottle.
• Install the spill-free coolant funnel kit (specialty) at the reservoir to reduce mess and help burp air (remove trapped air).
• Start the engine and set the cabin heat to MAX heat (this helps coolant circulate through the heater core).
• Let the engine idle until it reaches operating temperature and the radiator fan cycles on at least once.
• Top off as the level drops, then shut the engine off and let it cool completely.
• Recheck level when cold and fill to the “COLD” mark.

---

✅ After Repair

• Check for leaks around the thermostat housing and hose connection with the engine idling.
• Verify cabin heat works and the temperature gauge stays stable during a 10–15 minute drive.
• After the next full cool-down, recheck coolant level and top off to the correct mark.
• If you had a check engine light for coolant temperature, it may clear after a few drive cycles; otherwise it may need a scan tool reset.

---

💰 DIY vs Shop Cost

Shop Cost: $350–$650 (parts + labor)

DIY Cost: $70–$220 (parts only)

You Save: $280–$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5–2.5 hours.

---
