🔧 Sienna - Starter Motor Replacement

On your Sienna, the starter motor sits in the “valley” of the V6 under the upper intake manifold. Replacing it means removing the intake components to access the starter, then reinstalling everything with new gaskets to prevent vacuum leaks.

Difficulty Level: Advanced | Estimated Time: 4-6 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the battery before touching the starter power cable.
• ⚠️ Work on a cool engine; the intake and coolant passages can be hot.
• ⚠️ Keep bolts and tools out of intake ports; dropped items can damage the engine.
• ⚠️ Do not pry on plastic intake parts; they crack easily.
• ⚠️ Battery disconnect is required: remove negative terminal first.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 10mm combination wrench
• 3/8" drive ratchet
• 3/8" drive torque wrench (10–80 Nm range)
• 6" extension
• 12" extension
• Universal joint swivel (3/8")
• Flat-blade screwdriver
• Phillips screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Pick tool
• Magnetic pickup tool
• Shop light
• Fender cover
• Masking tape and marker
• Clean rags
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor - Qty: 1
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1
• Brake cleaner or throttle body cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and install a fender cover to protect paint.
• Label hoses and connectors with masking tape so they go back correctly.
• Disconnect the battery: use a 10mm socket to remove the negative terminal first, then isolate it so it can’t spring back.
• Have clean rags ready to plug intake openings once the manifold is off.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the wiper cowl area for access

• Use a trim clip removal tool and Phillips screwdriver to remove the plastic cowl top clips/screws.
• Use a 14mm socket to remove the wiper arm nuts, then lift the wiper arms off.
• Remove the cowl panels and, if equipped, the wiper motor/link assembly using a 10mm socket.
• Tip: Photograph the wiper arm positions.

Step 2: Remove the air intake duct and engine cover

• Pull off the engine cover by hand (it’s held by rubber grommets).
• Use a flat-blade screwdriver to loosen the intake hose clamps.
• Disconnect the air tube and any attached breather hoses using needle-nose pliers for spring clamps.
• Unplug the MAF connector (mass airflow sensor) by pressing the lock tab; use a pick tool gently if stuck.

Step 3: Remove the throttle body

• Unplug the throttle body connector.
• Remove the throttle body bolts using a 10mm socket.
• Remove the throttle body and discard the old gasket.
• Cover the opening with a clean rag to keep debris out.
• Torque to 10 Nm (89 in-lb) when reinstalling.
• Tip: Don’t force the connector lock tab.

Step 4: Remove the upper intake manifold (plenum)

• Disconnect vacuum/PCV/EVAP hoses from the manifold using needle-nose pliers as needed.
• Unplug any manifold-mounted connectors (label each one with masking tape).
• Remove the manifold fasteners using a 12mm socket, plus a 6" extension for the ones set deeper.
• Lift the manifold straight up and out. If it sticks, gently wiggle—do not pry hard with a screwdriver.
• Immediately plug the exposed intake ports with clean rags.
• Torque to 21 Nm (15 ft-lb) when reinstalling (tighten evenly in stages from the center outward).
• Tip: Count rags in and out—none left behind.

Step 5: Disconnect the starter electrical connections

• Locate the starter in the engine valley.
• Unplug the small starter solenoid connector by pressing the tab.
• Remove the rubber boot on the main power terminal.
• Use a 12mm socket (or 10mm combination wrench if tight) to remove the main cable nut and set the cable aside.
• Apply a thin smear of dielectric grease to the connector seal during reassembly.

Step 6: Remove the starter motor

• Remove the starter mounting bolts using a 14mm socket, 12" extension, and universal joint swivel (3/8") as needed.
• Lift the starter out carefully without dropping anything into the valley.
• Torque to 39 Nm (29 ft-lb) when reinstalling the starter bolts.
• Tip: A magnetic pickup helps with bolts.

Step 7: Install the new starter motor

• Set the new starter into place.
• Hand-start both mounting bolts to avoid cross-threading, then tighten with a 14mm socket.
• Torque to 39 Nm (29 ft-lb).
• Reconnect the main power cable and nut using a 12mm socket.
• Reconnect the solenoid connector until it clicks.

Step 8: Reinstall the intake manifold with new gaskets

• Remove all rags from the intake ports.
• Clean the mating surfaces using clean rags and brake cleaner or throttle body cleaner (spray on rag, not directly into ports).
• Install new upper intake manifold gaskets.
• Set the manifold in place and install the bolts by hand first.
• Tighten evenly with a 12mm socket.
• Torque to 21 Nm (15 ft-lb).
• Reconnect every hose and connector you labeled.

Step 9: Reinstall throttle body and intake ducting

• Install a new throttle body gasket.
• Install the throttle body bolts using a 10mm socket.
• Torque to 10 Nm (89 in-lb).
• Reconnect the throttle body connector.
• Reinstall the air intake tube and tighten clamps with a flat-blade screwdriver.
• Reconnect the MAF connector.

Step 10: Reinstall the cowl and wipers, then reconnect the battery

• Reinstall the wiper cowl panels and clips using a trim clip removal tool and Phillips screwdriver.
• Reinstall the wiper arms and nuts using a 14mm socket.
• Reconnect the battery negative terminal using a 10mm socket.
• Torque to 5 Nm (44 in-lb) on the battery clamp nut.

---

✅ After Repair

• Turn the key to ON (engine off) for 10 seconds, then OFF. Repeat once. This helps the throttle body re-initialize.
• Start the engine and listen for normal cranking and start-up.
• Check for a hissing sound (vacuum leak) around the intake manifold.
• If you have a check engine light, scan codes and recheck connectors you may have missed.
• Test drive briefly, then recheck for any loose clamps or smells.

---

💰 DIY vs Shop Cost

Shop Cost: $900-$1,400 (parts + labor)

DIY Cost: $220-$450 (parts only)

You Save: $680-$950 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 4-6 hours.

---
