🔧 4Runner - Starter Motor Replacement

On your 4Runner, the starter sits in the “V” of the engine under the intake manifold, so replacing it requires removing the air intake parts and the upper intake manifold to access the starter.

Plan to work slowly, label connectors/hoses, and replace the intake/throttle body gaskets so you don’t create a vacuum leak.

Difficulty Level: Advanced | Estimated Time: 3-5 hours

---

⚠️ Safety & Precautions

• 🧯 Disconnect the battery: Remove the negative (-) cable first to prevent a short (the starter cable is always “hot”).
• 🔥 Work on a cool engine; the intake area gets very hot.
• 🧤 Keep dirt out of the engine: Cover the intake ports with clean rags once the manifold is off.
• 💧 Coolant caution: The throttle body may have small coolant hoses—expect minor coolant loss and clean spills immediately.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 3/8" drive ratchet
• 6" extension (3/8")
• 12" extension (3/8")
• Universal joint adapter (3/8")
• Torque wrench (in-lb, 30-250 in-lb)
• Torque wrench (ft-lb, 10-80 ft-lb)
• Flathead screwdriver
• Needle-nose pliers
• Hose clamp pliers
• Trim clip removal tool
• Pick tool
• Magnetic pickup tool
• Painter’s tape and marker
• Shop rags
• Drain pan
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor assembly - Qty: 1
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Coolant (Toyota-compatible, premix) - Qty: 1-2 quarts

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to Park, and set the parking brake.
• 🧠 Label everything: Use painter’s tape and marker on each hose/connector so it goes back to the same spot.
• 🔋 Disconnect battery: Use a 10mm socket to remove the negative (-) terminal and isolate it so it can’t spring back.
• 🧼 Cleanliness matters: Blow/brush loose dirt off the intake area so it doesn’t fall into the engine.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover and air intake ducting

• Remove the plastic engine cover (if equipped) by lifting it off its mounting points.
• Use a flathead screwdriver to loosen the intake hose clamps.
• Unplug the intake air sensor(s) by pressing the lock tab, then pull straight off. Don’t yank on wires.
• Remove the intake tube/air ducting and set it aside.

Step 2: Remove the throttle body connections

• Unplug the throttle body electrical connector.
• If your throttle body has coolant hoses, place a drain pan underneath and use hose clamp pliers to slide the clamps back, then carefully twist/pull hoses off. (A little coolant loss is normal.)
• Use a 10mm socket to remove the throttle body mounting bolts.
• Remove the throttle body and discard the old gasket.
• Torque for install later: Throttle body bolts to 10 Nm (89 in-lbs)

Step 3: Remove the upper intake manifold

• Disconnect vacuum hoses and electrical connectors attached to the upper intake manifold. Use needle-nose pliers for spring clamps.
• Remove any brackets/lines attached to the manifold using a 10mm socket or 12mm socket as equipped.
• Use a 12mm socket with a 6" extension to remove the intake manifold bolts/nuts.
• Lift the manifold straight up and out. If it feels stuck, gently rock it—do not pry on sealing surfaces.
• Immediately cover the intake ports with clean shop rags so nothing can fall in.
• Remove and discard the old intake manifold gaskets.
• Torque for install later: Upper intake manifold bolts/nuts to 21 Nm (15 ft-lbs)

Step 4: Access the starter and disconnect its wiring

• Locate the starter in the engine “V”.
• Remove the starter solenoid trigger wire connector by pressing the tab and pulling off.
• Use a 12mm socket to remove the nut for the main starter power cable, then move the cable aside.
• Keep the nut somewhere safe. A magnetic pickup tool helps if it drops.

Step 5: Remove the starter motor

• Use a 14mm socket with a 12" extension and universal joint adapter to remove the starter mounting bolts.
• Lift the starter out carefully without snagging wiring harnesses.
• Torque for install: Starter mounting bolts to 39 Nm (29 ft-lbs)

Step 6: Install the new starter motor

• Set the new starter in place and hand-start both mounting bolts to avoid cross-threading.
• Use a torque wrench (ft-lb) to tighten: Torque to 39 Nm (29 ft-lbs).
• Reconnect the main power cable and tighten the nut using a 12mm socket (snug, then a little more—do not overtighten the stud).
• Reconnect the small trigger wire connector until it clicks.

Step 7: Reinstall the upper intake manifold with new gaskets

• Remove the rags from the intake ports.
• Install new intake manifold gaskets in their grooves.
• Lower the manifold straight down into place.
• Hand-start all bolts/nuts, then tighten evenly in a crisscross pattern using a 12mm socket.
• Use a torque wrench (ft-lb): Torque to 21 Nm (15 ft-lbs).
• Reconnect all hoses/connectors and any brackets you removed using the same 10mm/12mm sockets.

Step 8: Reinstall the throttle body with a new gasket

• Place the new throttle body gasket.
• Install the throttle body and hand-start bolts.
• Use a torque wrench (in-lb): Torque to 10 Nm (89 in-lbs).
• Reconnect coolant hoses (if equipped) using hose clamp pliers and reinstall clamps in their original positions.
• Reconnect the throttle body electrical connector.

Step 9: Reinstall the air intake ducting and reconnect the battery

• Reinstall the intake tube and tighten clamps using a flathead screwdriver.
• Reconnect intake air sensor connector(s).
• Reconnect the battery negative (-) terminal using a 10mm socket.

---

✅ After Repair

• 🔍 Coolant check: If you removed coolant hoses, top off the coolant and check for leaks with the engine running.
• 🚗 First start: Turn the key to ON for 5 seconds, then start. The first crank may be slightly longer than normal.
• 🎧 Listen for issues: No grinding noises, no clicking, and the engine should crank strongly.
• 🧪 Idle relearn: Let it idle 5-10 minutes with all accessories off. Helps stabilize idle.
• ✅ Recheck: After a short test drive, recheck for vacuum leaks (hissing) and coolant seepage.

---

💰 DIY vs Shop Cost

Shop Cost: $700-$1,300 (parts + labor)

DIY Cost: $220-$450 (parts only)

You Save: $480-$850 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
