🔧 RX350 - Starter Motor Replacement

On your RX350, the starter motor sits under the intake manifold (the large plastic “upper plenum” on top of the engine). Replacing it means removing the air intake parts and the intake manifold to reach the starter, then reinstalling everything with new gaskets to prevent vacuum leaks.

Difficulty Level: Advanced | Estimated Time: 4-6 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the battery before touching the starter wiring (prevents shorts and fire).
• ⚠️ Work only on a cold engine (intake and coolant lines can burn you).
• ⚠️ Keep bolts and tools out of the intake ports (stuff ports with clean rags).
• ⚠️ If you pinch or remove any coolant hoses at the throttle body, expect some coolant loss and clean spills immediately.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Fender cover
• 10mm socket
• 12mm socket
• 14mm socket
• 1/4" drive ratchet
• 3/8" drive ratchet
• 6" extension (3/8")
• 12" extension (3/8")
• Torque wrench (5-80 Nm range)
• Flat-blade screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Hose pinch-off pliers (specialty)
• Magnetic pickup tool
• Telescoping inspection mirror
• Shop towels
• Masking tape and marker

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor - Qty: 1
• Intake manifold gasket set (upper plenum gaskets) - Qty: 1
• Throttle body gasket - Qty: 1
• Coolant (Toyota/Lexus compatible, pre-mixed) - Qty: 1-2 quarts

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the hood and install a fender cover to protect paint.
• Use masking tape and marker to label any hoses/connectors you unplug (makes reassembly easy).
• Disconnect the battery: use a 10mm socket to remove the negative terminal and isolate it so it can’t spring back.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the engine cover and air intake tube

• Pull upward to remove the plastic engine cover (it’s held by rubber grommets).
• Unplug the air flow sensor connector (press the tab; don’t yank wires).
• Use a flat-blade screwdriver to loosen the hose clamps on the intake tube.
• Use needle-nose pliers to release any small hose clamps and disconnect breather hoses.
• Remove the intake tube/air box pieces as needed to clear access to the throttle body.

Step 2: Remove the throttle body

• Unplug the throttle body electrical connector.
• If your RX350 has coolant hoses running to the throttle body, use hose pinch-off pliers to gently clamp the hoses, then remove clamps with needle-nose pliers and pull hoses off. Have towels ready for drips.
• Use a 10mm socket to remove the throttle body mounting bolts.
• Remove the throttle body and discard the old gasket.
• On reassembly later: Torque to 10 Nm (89 in-lb)

Step 3: Disconnect intake manifold hoses, connectors, and brackets

• Use your inspection mirror to look for hidden connectors and hose connections along the intake manifold.
• Unplug visible sensors/connectors (label with masking tape).
• Disconnect the PCV/vacuum hoses using needle-nose pliers where spring clamps are used.
• Remove any wiring brackets attached to the intake using a 10mm socket.

Step 4: Remove the intake manifold (upper plenum)

• Use a 12mm socket with a 3/8" ratchet and extensions to remove the intake manifold bolts/nuts.
• Lift the intake manifold up and out carefully, checking for any hose/connector you missed before forcing it.
• Immediately stuff clean shop towels into the exposed intake ports. Do not drop anything inside.
• Remove and discard the old intake manifold gaskets.
• On reassembly later: Torque to 21 Nm (15 ft-lb)

Step 5: Access and disconnect the starter wiring

• The starter is now visible in the “V” of the engine.
• Remove the starter B+ terminal cover (if equipped) by hand.
• Use a 12mm socket to remove the main power cable nut from the starter (set the cable aside so it can’t touch metal).
• Unplug the small starter signal connector by pressing the lock tab.

Step 6: Remove the starter motor

• Use a 14mm socket with a 3/8" ratchet and extensions to remove the starter mounting bolts.
• Lift the starter out carefully; use a magnetic pickup tool if a bolt starts to fall.
• On installation later: Torque to 39 Nm (29 ft-lb)

Step 7: Install the new starter motor

• Position the new starter and hand-thread the mounting bolts first (prevents cross-threading).
• Use a torque wrench and 14mm socket: Torque to 39 Nm (29 ft-lb)
• Reconnect the signal connector until it clicks.
• Reconnect the main power cable and tighten with a 12mm socket (snug plus a little; do not overtighten).
• Reinstall the terminal cover.

Step 8: Reinstall intake manifold with new gaskets

• Remove the shop towels from the intake ports.
• Install new intake manifold gaskets (make sure they sit flat and fully seated).
• Set the intake manifold in place and hand-start all bolts/nuts.
• Use a torque wrench and 12mm socket: Torque to 21 Nm (15 ft-lb)
• Reconnect all hoses, connectors, and wiring brackets using a 10mm socket where applicable.

Step 9: Reinstall the throttle body and air intake

• Install a new throttle body gasket.
• Reinstall throttle body bolts using a 10mm socket, then use a torque wrench: Torque to 10 Nm (89 in-lb)
• Reconnect coolant hoses (if equipped) and remove the hose pinch-off pliers.
• Reconnect the throttle body connector.
• Reinstall the intake tube/air box and tighten clamps with a flat-blade screwdriver.
• Reconnect the air flow sensor connector.
• Reinstall the engine cover.

Step 10: Reconnect the battery

• Reconnect the negative battery terminal using a 10mm socket.

---

✅ After Repair

• Start the engine and confirm it cranks strongly and starts normally.
• Let it idle 2-3 minutes and listen for hissing (a hissing sound can mean a vacuum leak at the intake or a loose hose clamp).
• If you removed any throttle-body coolant hoses, top off coolant as needed and check for leaks once the engine warms up.
• If the check engine light comes on, re-check every connector and hose you touched; scan codes if you have a basic OBD2 scanner.

---
