🔧 Kona - Starter Motor Replacement

Replacing the starter on your Kona means disconnecting the battery, gaining access to the starter (usually from underneath and the intake side), and swapping the electrical connections and mounting bolts. The key is safe lifting and reinstalling everything with the correct factory torque so you don’t damage threads or cause starting/charging issues.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery cable before touching the starter wiring.
• ⚠️ Support your Kona with jack stands; never work under a vehicle held only by a jack.
• ⚠️ Let the engine/exhaust cool first; the starter sits near hot parts.
• ⚠️ Keep the key fob away from the vehicle while working to prevent accidental powering of systems.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Wheel chocks
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• 10mm socket
• 12mm socket
• 14mm socket
• 3/8" drive ratchet
• 3/8" drive torque wrench (10–100 Nm range)
• 6" socket extension
• 12" socket extension
• Universal joint adapter
• Flat trim tool
• Needle-nose pliers
• Paint marker

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor - Qty: 1
• Starter electrical terminal nut(s) - Qty: 1
• Intake clamp(s) or clip(s) as needed - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels using wheel chocks.
• Open the hood and plan to disconnect the battery using a 10mm socket.
• Quick check: confirm you have the factory torque specs for the starter mounting bolts and electrical nuts (service manual). I need these to give you exact Torque to XX Nm (YY ft-lbs) values without guessing.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm access path and torque specs

• On your Kona, the starter is mounted to the transmission bell housing. Access is commonly from underneath after removing the lower splash shield.
• Please answer these 2 quick questions so I can give you the exact, trim-accurate procedure and torque values:
  • Can you upload a clear photo from underneath showing the starter and its mounting bolts?
  • Do you have the starter torque specs from the Hyundai service manual (or can you upload a screenshot/photo of that page)?

Step 2: Disconnect the battery

• Use a 10mm socket to loosen the negative battery terminal and remove it from the battery post.
• Move the cable aside so it can’t spring back to the post. Keep it from touching metal.

Step 3: Raise and support the vehicle

• Use a floor jack (rated 3-ton minimum) to lift the front of the vehicle at the proper front jack point.
• Set the vehicle down on jack stands (rated 3-ton minimum) placed at the proper support points.

Step 4: Remove the lower splash shield

• Use a flat trim tool to pop out plastic clips (a trim tool is a flat pry tool that removes clips without breaking them).
• Use a 10mm socket to remove any splash shield bolts.
• Set all clips/bolts aside in a tray so nothing gets lost.

Step 5: Locate the starter and label the wiring

• Find the starter (cylindrical motor with a smaller solenoid attached) near where the engine meets the transmission.
• Use a paint marker to mark which cable goes where before removing anything.

Step 6: Disconnect the starter electrical connections

• Remove the small control connector by releasing its tab using needle-nose pliers (only if needed) and pulling straight off.
• Remove the main power cable nut using the correct socket (commonly 12mm socket, sometimes 14mm socket).
• Torque on reinstall: Torque to XX Nm (YY ft-lbs) (I’ll fill in the exact value once you provide the manual spec/photo).

Step 7: Remove the starter mounting bolts

• Support the starter with one hand.
• Use a 14mm socket, 3/8" drive ratchet, 6" socket extension, and universal joint adapter as needed to remove the starter mounting bolts.
• Torque on reinstall: Torque to XX Nm (YY ft-lbs) (I’ll provide the exact spec once confirmed).

Step 8: Remove the starter

• Wiggle the starter free from the bell housing and lower it out carefully.
• Compare the old and new starter side-by-side: same mounting ears, same electrical stud locations, same connector.

Step 9: Install the new starter

• Position the new starter and hand-thread the mounting bolts first (prevents cross-threading).
• Tighten the mounting bolts using a 14mm socket and finish with a 3/8" drive torque wrench (10–100 Nm range).
• Torque to XX Nm (YY ft-lbs) once we confirm the factory spec.

Step 10: Reconnect the starter wiring

• Install the main power cable onto the stud and tighten the nut using a 12mm socket or 14mm socket (whichever fits your starter).
• Reconnect the small control connector until it clicks.
• Torque to XX Nm (YY ft-lbs) for the main terminal nut once we confirm the factory spec.

Step 11: Reinstall the splash shield and lower the vehicle

• Reinstall the splash shield using a 10mm socket and the flat trim tool for the clips.
• Raise slightly with the floor jack (rated 3-ton minimum), remove jack stands (rated 3-ton minimum), then lower the vehicle.

Step 12: Reconnect the battery and test

• Reconnect the negative battery terminal using a 10mm socket.
• Start the vehicle. Listen for a strong, clean crank (no grinding).

---

✅ After Repair

• Start the engine 3–5 times to confirm consistent cranking.
• Check that no warning lights appear after the start.
• Look underneath for any loose wiring near the starter and verify the splash shield is secure.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$900 (parts + labor)

DIY Cost: $180-$450 (parts only)

You Save: $270-$450 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
