🔧 Forte - Starter Motor Replacement

The starter motor is the electric motor that cranks your Forte’s engine when you turn the key/push the start button. Replacing it usually means working near the battery cables and the transmission bellhousing, so careful disconnect and secure lifting are key.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery cable first to prevent a short or sparks.
• ⚠️ Let the engine cool; you’ll work near hot components.
• ⚠️ Support the car with jack stands; never rely on a floor jack alone.
• ⚠️ Keep metal tools away from the starter’s main power stud; it’s direct battery power.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 1/4" drive ratchet
• 3/8" drive ratchet
• 3/8" drive torque wrench (10–100 Nm range)
• 10mm socket
• 12mm socket
• 14mm socket
• 6" extension
• 12" extension
• Flat trim tool
• Phillips screwdriver
• Pliers
• Work light

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor assembly - Qty: 1
• Air intake hose clamp (optional) - Qty: 1
• Battery terminal anti-corrosion washers (optional) - Qty: 1 set

---

📋 Before You Begin

• Park on a level surface, shift to Park, and set the parking brake.
• Open the hood and keep the key fob away from the car (prevents accidental wake-up).
• Have a small container ready for bolts/nuts so nothing gets lost.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect the battery

• Use a 10mm socket to loosen the negative (-) battery terminal and remove it from the battery post.
• Tuck the cable aside so it can’t spring back onto the terminal.
• Negative off first, on last.

Step 2: Remove the air intake ducting (for access)

• Use pliers to release any breather hose clamps on the intake tube.
• Use a Phillips screwdriver (or the appropriate clamp screw) to loosen the intake hose clamps.
• Remove the intake tube and, if needed, the upper air box using a 10mm socket.

Step 3: Raise and support the front of the car

• Place wheel chocks behind the rear tires.
• Lift the front with a floor jack (rated 2-ton minimum) and set it securely on jack stands (rated 2-ton minimum).
• Use a work light so you can clearly see the starter area.

Step 4: Remove the lower splash shield (if equipped)

• Use a flat trim tool to pop out the plastic clips.
• Use a 10mm socket for any small bolts holding the shield.

Step 5: Locate the starter and disconnect the wiring

• The starter sits at the engine/transmission bellhousing area.
• Remove the rubber boot covering the main starter power stud by hand.
• Use a 12mm socket to remove the main battery cable nut from the starter terminal. Torque to 9.8 Nm (87 in-lbs) during reassembly.
• Disconnect the small starter solenoid signal wire connector (pull the connector straight off). If it uses a nut style, use a 10mm socket. Torque to 4.9 Nm (43 in-lbs) during reassembly.
• Take a quick photo before unplugging.

Step 6: Remove the starter mounting bolts

• Support the starter with one hand while you remove bolts with a 14mm socket, 3/8" drive ratchet, and a 12" extension.
• Remove the upper and lower starter mounting bolts.
• Pull the starter straight out from the bellhousing.
• During reassembly: Torque the starter mounting bolts to 49 Nm (36 ft-lbs).

Step 7: Install the new starter

• Compare the new starter to the old one (same nose shape, same electrical studs/connectors).
• Position the starter into the bellhousing opening and start both mounting bolts by hand to prevent cross-threading.
• Tighten with a 14mm socket and then use a 3/8" drive torque wrench (10–100 Nm range): Torque to 49 Nm (36 ft-lbs).

Step 8: Reconnect starter wiring

• Install the main battery cable onto the starter power stud and tighten with a 12mm socket: Torque to 9.8 Nm (87 in-lbs).
• Reconnect the small solenoid wire connector (make sure it clicks/locks). If it uses a nut, tighten with a 10mm socket: Torque to 4.9 Nm (43 in-lbs).
• Reinstall the rubber boot over the main power stud.

Step 9: Reinstall splash shield and intake parts

• Reinstall the splash shield using the 10mm socket and flat trim tool for clips.
• Reinstall the intake tube/air box using a 10mm socket, Phillips screwdriver, and pliers for clamps.

Step 10: Lower the car and reconnect the battery

• Raise slightly with the floor jack, remove the jack stands, then lower the car.
• Reconnect the negative (-) battery terminal using a 10mm socket.

---

✅ After Repair

• Start the engine and listen: it should crank strongly with no grinding.
• Check that no warning lights appear and that all intake hoses are fully seated (no hissing/rough idle).
• Do a quick visual re-check for any loose wiring near the starter.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $150-$450 (parts only)

You Save: $300-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
