🔧 Escape - Starter Motor Replacement

The starter motor spins the engine to get it running. On your Escape, it’s mounted low on the engine/transmission area, so you’ll be working from underneath and handling a heavy electrical cable.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

Assumption: 2.5L starter is accessed from underneath with a lower splash shield.

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the battery negative cable first to prevent a short (the starter cable is always “hot”).
• ⚠️ Support the Escape with jack stands; never rely only on a floor jack.
• ⚠️ Let the exhaust cool before working near it.
• ⚠️ Keep tools off the starter power stud to avoid arcing.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Wheel chocks
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• 8mm socket
• 10mm socket
• 13mm socket
• 1/4" ratchet
• 3/8" ratchet
• 3/8" torque wrench (10–80 ft-lbs range)
• 6" extension (3/8" drive)
• 12" extension (3/8" drive)
• Universal joint adapter (3/8" drive)
• Flat trim clip tool
• Flathead screwdriver
• Needle-nose pliers
• Flashlight
• Battery terminal puller (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor - Qty: 1
• Starter electrical terminal nut kit - Qty: 1
• Lower engine splash shield fastener/clips kit - Qty: 1
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Open the hood and keep the key fob away from the vehicle while you work.
• Disconnect the battery: use a 10mm socket to remove the negative terminal (the “-” cable) and tuck it aside so it cannot spring back.
• Jack up the front and set the Escape on jack stands at the proper lift points.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield

• Use a flat trim clip tool and flathead screwdriver to remove plastic push-clips.
• Use an 8mm socket or 10mm socket (varies by fastener) with a 1/4" ratchet to remove shield screws/bolts.
• Set the shield and fasteners aside in a small pile so nothing gets lost.

Step 2: Locate the starter and identify the two connections

• Use a flashlight to find the starter at the engine/transmission joint.
• You’ll see:
• The large battery cable on a stud (thick wire).
• The smaller control connector (a plug).
• The big cable is why the battery must be disconnected.

Step 3: Disconnect the starter wiring

• Remove the protective boot from the large cable using needle-nose pliers if needed.
• Use a 13mm socket with a 3/8" ratchet to remove the nut from the starter power stud, then lift the cable off.
• Disconnect the small plug by pressing the lock tab and pulling straight off (use a flathead screwdriver gently if the tab is stubborn).
• Apply a tiny amount of dielectric grease to the small connector seal (not on the metal pin surfaces).

Step 4: Remove the starter mounting bolts

• Support the starter with one hand while loosening bolts (it can be heavier than it looks).
• Use a 13mm socket with a 3/8" ratchet, plus a 6" extension and universal joint adapter if needed, to remove the starter mounting bolts.
• Carefully lower the starter out of the vehicle.

Step 5: Install the new starter

• Position the new starter in place by hand and start the mounting bolts by hand first to avoid cross-threading.
• Tighten with a 13mm socket and 3/8" ratchet.
• Final-tighten with a 3/8" torque wrench: Torque to 35 Nm (26 ft-lbs) for starter mounting bolts.
• Hand-starting bolts prevents expensive thread damage.

Step 6: Reconnect the starter wiring

• Install the small control plug until it clicks (push straight on).
• Install the large cable onto the starter stud.
• Install a new nut (recommended) and tighten using a 13mm socket.
• Final-tighten with a 3/8" torque wrench: Torque to 10 Nm (89 in-lbs) for the power cable nut.
• Reinstall the rubber boot over the stud so it fully covers the connection.

Step 7: Reinstall the splash shield

• Reposition the shield and start all fasteners by hand.
• Tighten screws/bolts using an 8mm socket or 10mm socket with a 1/4" ratchet until snug.
• Reinstall push-clips using the trim clip tool.

Step 8: Reconnect the battery and lower the vehicle

• Lower the Escape from the jack stands using the floor jack.
• Reconnect the battery negative terminal using a 10mm socket.
• Snug the terminal so it cannot rotate by hand.

---

✅ After Repair

• Start the engine and listen: it should crank strong and smooth (no clicking, no grinding).
• Check underneath for any dangling wires and confirm the rubber boot is covering the power stud.
• If the Escape does not crank, recheck the small control connector and battery terminal tightness first.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $120-$320 (parts only)

You Save: $330-$530 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
