🔧 Impreza - Starter Motor Replacement

Your starter motor spins the engine so it can start. When it fails, you may get a single click, slow cranking, or no crank at all. On your Impreza, the starter sits on top of the transmission bellhousing area, so most of the job is working carefully in a tight space.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• Disconnect the battery negative terminal first to prevent an electrical short.
• Do not let your wrench touch the starter’s main power stud and any metal at the same time.
• Work on a cool engine; the exhaust and engine parts can burn you.
• Keep keys out of the car while working so nobody tries to start it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• 10mm socket
• 12mm socket
• 14mm socket
• 3/8" ratchet
• 3/8" extension set
• Torque wrench (3/8" drive)
• Flat-blade screwdriver
• Pliers
• Trim clip removal tool
• Small wire brush
• Shop rags
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor - Qty: 1
• Starter terminal nut/cap kit - Qty: 1
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and keep your tools away from the battery until you disconnect it.
• Have your radio presets saved if you care about them.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect the battery

• Use a 10mm socket to loosen the negative (–) battery terminal clamp.
• Remove the negative cable and tuck it aside so it cannot spring back.

Step 2: Remove the air intake pieces for access

• Use a flat-blade screwdriver to loosen the intake hose clamp(s).
• Use a trim clip removal tool to pop any plastic clips holding the ducting/snorkel.
• Use a 10mm socket and/or 12mm socket to remove the air box/duct fasteners as needed.
• Lift the intake duct/air box out enough to clearly see the starter area. Take a quick photo first.

Step 3: Unplug the starter small connector (signal wire)

• Find the small electrical connector on the starter solenoid.
• Press the lock tab and pull it off by hand; use pliers gently only if needed.

Step 4: Remove the starter main power cable

• Pull off the rubber protective cap from the starter main power stud.
• Use a 10mm socket to remove the nut holding the main cable to the stud.
• Move the cable aside and cover the end with a shop rag so it cannot touch metal.
• Torque note for install: main terminal nut Torque to 9.8 Nm (7.2 ft-lbs).

Step 5: Unbolt and remove the starter motor

• Use a 14mm socket, 3/8" ratchet, and a 3/8" extension to remove the two starter mounting bolts.
• Support the starter with one hand as the last bolt comes out.
• Lift the starter out of the engine bay carefully.
• Torque note for install: starter mounting bolts Torque to 44 Nm (32 ft-lbs).

Step 6: Prep the cables and mounting surface

• Use a small wire brush to clean corrosion from the main cable ring terminal.
• Wipe the starter mounting surface clean with shop rags so the starter sits flat.
• Apply a thin film of dielectric grease to electrical connections to help prevent corrosion (do not pack the connector full).

Step 7: Install the new starter

• Place the starter into position by hand.
• Start both mounting bolts by hand to avoid cross-threading.
• Use a 14mm socket to snug the bolts, then use a torque wrench (3/8" drive) to finish: Torque to 44 Nm (32 ft-lbs).

Step 8: Reconnect the wiring

• Install the main power cable onto the stud and hand-start the nut.
• Use a 10mm socket and then a torque wrench (3/8" drive) (if your torque wrench supports low torque) to finish: Torque to 9.8 Nm (7.2 ft-lbs).
• Reinstall the rubber protective cap over the stud.
• Plug the small connector back in until it clicks.

Step 9: Reinstall the air intake pieces

• Reinstall the intake duct/air box using the 10mm socket / 12mm socket as removed.
• Tighten hose clamps using the flat-blade screwdriver.
• Confirm all clips are fully seated.

Step 10: Reconnect the battery and test

• Reconnect the negative (–) battery terminal using the 10mm socket.
• Start the engine and listen for strong, normal cranking.
• If you get only a click, recheck the main cable nut and the small connector.

---

✅ After Repair

• Make sure there are no tools left in the engine bay.
• Verify the intake hose clamps are tight (a loose clamp can cause rough idle).
• Check that the battery terminal is tight and doesn’t rotate by hand.
• Test 3-5 key starts over the next day to confirm consistency.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $160-$420 (parts only)

You Save: $290-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
