🔧 Starter Motor - Replacement

The starter on your Sienna is mounted low on the engine and access is tight. On this V6, you’ll need to remove the intake ducting and upper intake manifold to reach it cleanly. This is a moderate DIY job with careful bolt handling and a few electrical connections.

Difficulty Level: Intermediate | Estimated Time: 3-5 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before starting. The starter cable is always hot.
• Wait at least 90 seconds after battery disconnect before unplugging any engine sensors.
• Do not let tools bridge the starter power terminal to ground.
• Work on a cool engine. The intake and exhaust area can stay hot for a long time.
• Keep track of intake seals and gaskets. Air leaks can cause rough running after reassembly.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 3/8-inch ratchet
• 3/8-inch extension set
• Torque wrench
• Flat-blade screwdriver
• Pliers
• Trim clip removal tool
• Gasket scraper
• Shop towels
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor - Qty: 1
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Shift into Park and remove the key/fob from the vehicle.
• Disconnect the negative battery cable with a 10mm socket.
• Wait for the engine to cool fully before opening the intake area.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect the battery

• Use a 10mm socket to loosen the negative battery terminal.
• Move the cable aside so it cannot touch the post.
• Prevent accidental cranking.

Step 2: Remove the intake ducting

• Use a flat-blade screwdriver or pliers to loosen the air intake clamps.
• Remove the intake tube and any resonator pieces blocking access to the top of the engine.
• Unplug any air intake sensors you need to move aside.

Step 3: Remove the throttle body

• Use a 10mm socket to remove the throttle body fasteners.
• Disconnect the electrical connector from the throttle body.
• Set the throttle body aside without stressing the coolant hoses.
• Torque on install: Tighten throttle body bolts to 10 Nm (89 in-lbs).

Step 4: Remove the upper intake manifold

• Use a 10mm socket and 3/8-inch extension to remove the upper intake manifold bolts.
• Disconnect the vacuum hoses and electrical connectors attached to the manifold.
• Lift the manifold straight up and out.
• Remove the old intake gaskets and clean the sealing surfaces with a gasket scraper.
• Torque on install: Tighten upper intake manifold bolts to 21 Nm (16 ft-lbs).

Step 5: Remove the starter electrical connections

• Locate the starter on the transaxle side of the engine.
• Use a 12mm socket to remove the battery cable nut from the starter terminal.
• Remove the smaller signal wire connector carefully by hand.
• Do not twist the wire terminals.

Step 6: Remove the starter motor

• Use a 14mm socket and 3/8-inch extension to remove the starter mounting bolts.
• Support the starter with one hand as you remove the last bolt.
• Lower the starter out of the engine bay.
• Torque on install: Tighten starter mounting bolts to 39 Nm (29 ft-lbs).

Step 7: Install the new starter

• Position the new starter in place by hand.
• Start both mounting bolts by hand first.
• Use a 14mm socket to tighten the bolts evenly.
• Reconnect the starter signal wire and main battery cable with a 12mm socket.
• Torque on install: Tighten starter electrical terminal nut to 9 Nm (80 in-lbs).

Step 8: Reinstall the intake manifold and throttle body

• Install new intake gaskets before putting the manifold back on.
• Use a 10mm socket to reinstall the upper intake manifold.
• Reconnect all hoses and electrical connectors.
• Reinstall the throttle body with its new gasket.
• Torque on install: Upper intake manifold bolts to 21 Nm (16 ft-lbs); throttle body bolts to 10 Nm (89 in-lbs).

Step 9: Reinstall the intake ducting and reconnect the battery

• Put the intake tube and airbox parts back in place.
• Tighten the clamps with a flat-blade screwdriver or pliers.
• Reconnect the negative battery cable with a 10mm socket.

Step 10: Test the repair

• Turn the key to START and verify the engine cranks normally.
• Check for vacuum leaks, warning lights, or loose intake connections.
• Listen for abnormal starter noise.

---

✅ After Repair

• Confirm the engine starts quickly and consistently.
• Inspect the intake manifold area for any hissing or air leaks.
• Recheck the battery terminal tightness after the first test start.
• If the Check Engine light appears, scan for intake-related codes.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,100 (parts + labor)

DIY Cost: $180-$400 (parts only)

You Save: $470-$700 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
