🔧 Starter Motor - Replacement

Assumption: This guide covers the starter motor on your Accord V6. On this engine, the starter is mounted low on the engine/transmission area and access is tight, so the intake ducting and related upper components may need to come off first. A failed starter can cause a no-crank condition, clicking, or intermittent starting.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before starting. The starter cable is always hot and can arc badly.
• Use care around the intake manifold area and electrical connectors. Do not force brittle clips.
• Keep metal tools away from the starter battery cable until the battery is disconnected.
• If you raise the vehicle, support it with jack stands on level ground.
• Do not allow the starter to hang by the wiring.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves
• 10mm socket
• 12mm socket
• 14mm socket
• 3/8-inch ratchet
• Extensions
• Universal joint adapter
• Torque wrench
• Flat-blade trim tool
• Battery terminal wrench
• Pickup magnet

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor - Qty: 1
• Starter mounting bolts - Qty: 2
• Intake tube clamp - Qty: 1
• Battery terminal clamp cleaner - Qty: 1

---

📋 Before You Begin

• Make sure the ignition is off and the key/fob is away from the vehicle.
• Disconnect the negative battery cable first, then the positive if needed.
• If the car is in a tight driveway, open the hood fully and give yourself room at the front and top of the engine bay.
• Take a photo of each connector before unplugging it.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect battery power

• Use a 10mm socket or battery terminal wrench to remove the negative battery cable.
• Move the cable aside so it cannot touch the terminal.
• Torque to factory specification when reinstalling the battery terminal.

Step 2: Remove upper intake ducting

• Use a flat-blade trim tool to loosen any clips on the air inlet duct.
• Use a 10mm socket to remove the duct or airbox fasteners if equipped.
• Lift the intake tube out of the way for access.
• Label every hose before removal.

Step 3: Gain access to the starter area

• Depending on access, remove any nearby brackets, covers, or air cleaner parts using a 10mm socket and 12mm socket.
• If needed for lower access, raise the front of the vehicle with a floor jack and support it on jack stands.
• Remove the lower splash shield fasteners with a 10mm socket.

Step 4: Disconnect starter wiring

• Use a 10mm socket to remove the battery cable nut from the starter terminal.
• Remove the small control-wire connector by pressing the lock tab and pulling it straight off.
• Keep the cable from touching metal parts.

Step 5: Remove the starter

• Use a 14mm socket, extensions, and a universal joint adapter to remove the starter mounting bolts.
• Support the starter with one hand while removing the last bolt.
• Lower the starter out carefully. It may need to rotate slightly to clear the housing.

Step 6: Compare the new starter

• Match the mounting ears, electrical terminals, and depth of the old and new starters.
• Check that any heat shield or spacer transfers over if your replacement requires it.

Step 7: Install the new starter

• Position the new starter in place and start the mounting bolts by hand.
• Use the 14mm socket and torque wrench to tighten the bolts evenly.
• Torque to factory specification.
• Reconnect the small control-wire connector first, then install the battery cable nut with a 10mm socket.
• Torque to factory specification.

Step 8: Reassemble removed parts

• Reinstall any brackets, splash shields, intake ducting, and airbox parts with a 10mm socket and 12mm socket.
• Make sure all hose clamps and connectors are fully seated.

Step 9: Restore battery power and test

• Reconnect the negative battery cable with a 10mm socket.
• Start the engine and confirm normal cranking.
• Listen for smooth engagement and check for warning lights.

---

✅ After Repair

• Verify the engine starts consistently several times in a row.
• Check that no loose parts rattle near the intake or starter area.
• If the battery was weak, have it load-tested.
• If the no-crank condition remains, check battery voltage, main fuse, and starter relay.

---

💰 DIY vs Shop Cost

Shop Cost: $550-$1,050 (parts + labor)

DIY Cost: $150-$400 (parts only)

You Save: $400-$650 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
