🔧 1500 - Side View Mirror Replacement

Replacing a side view mirror on your 1500 means removing the small interior trim panel at the front of the window (the “sail panel”), unplugging the mirror wiring (if equipped), and unbolting the mirror from the door. A careful install matters so the mirror sits flat, doesn’t whistle in the wind, and doesn’t leak water.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours (per side)

---

⚠️ Safety & Precautions

• ⚠️ If your door has a side airbag, do not probe yellow connectors or wiring.
• ⚠️ Support the mirror with one hand while removing the last fastener so it doesn’t fall and chip paint.
• ⚠️ Disconnect the negative battery cable before unplugging door wiring to prevent shorts.
• ⚠️ Use plastic trim tools to avoid cracking interior panels.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" drive ratchet
• 6" socket extension
• Torque wrench (in-lb)
• Trim removal tool (plastic)
• Small flat-blade screwdriver
• Pick tool
• Flashlight
• Painter’s tape
• Fender cover
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly (LH driver or RH passenger, correct options) - Qty: 1
• Mirror-to-door foam gasket/seal - Qty: 1
• Interior trim panel retainers/clips (assorted) - Qty: 1 set

---

📋 Before You Begin

• Park on level ground, shift to Park, and turn the ignition off.
• Lower the window glass on the side you’re working on.
• Use 10mm socket to disconnect the negative battery cable and isolate it so it can’t spring back.
• Apply painter’s tape along the door edge under the mirror to protect the paint.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the interior “sail panel”

• Use a trim removal tool (plastic) to pry off the small triangular trim cover at the front upper corner of the door (inside, by the mirror).
• If there’s a small cap hiding a screw, use a small flat-blade screwdriver to lift the cap, then remove any retainer carefully with a pick tool.
• Pull straight out to avoid breaking clips.

Step 2: Disconnect the mirror wiring (if equipped)

• Look behind the sail panel with a flashlight for the mirror electrical connector.
• Use a pick tool to gently lift the lock tab (if present), then unplug the connector by hand.
• If your mirror is manual (no connector), skip this step.

Step 3: Remove the mirror mounting fasteners

• Support the mirror on the outside with one hand.
• Use a 10mm socket, 1/4" drive ratchet, and 6" socket extension to remove the three mirror mounting nuts/bolts inside the door.
• Keep the fasteners in a small pile so they don’t drop into the door.

Step 4: Remove the mirror from the door

• Carefully pull the mirror away from the door.
• If it’s a power mirror, feed the wiring and connector through the hole as you remove it.
• Remove the old foam gasket/seal if it stayed stuck to the door.

Step 5: Prep the mounting surface

• Wipe the door mounting surface clean by hand (no scraping tools).
• Install the new mirror-to-door foam gasket/seal onto the mirror (or door) in the same orientation as the original.
• A flat seal prevents wind noise and leaks.

Step 6: Install the new mirror

• Hold the mirror in place and feed the wiring through the door opening (if equipped).
• Hand-start all fasteners to avoid cross-threading.
• Use a 10mm socket and 1/4" drive ratchet to snug them evenly.
• Use a torque wrench (in-lb) and tighten evenly: Torque to 9 Nm (80 in-lb).

Step 7: Reconnect wiring and reinstall the sail panel

• Plug the mirror connector back in until it clicks (if equipped).
• Align the sail panel clips and press it straight into place by hand.
• If you removed any clip caps, reinstall them by hand (use a small flat-blade screwdriver only if needed).

Step 8: Reconnect the battery

• Use a 10mm socket to reconnect the negative battery cable.

---

✅ After Repair

• Check mirror fit: confirm it sits flush and the gasket is not pinched.
• Power mirror test (if equipped): ignition on, verify left/right selection and up/down movement.
• If your mirror has heat or turn signal (if equipped), verify operation.
• Road test: listen for wind noise around the mirror at 30-50 mph.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$650 (parts + labor)

DIY Cost: $80-$400 (parts only)

You Save: $170-$250 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
