Assumption: Your Acadia has standard power mirrors (no memory). If your mirror has heat/turn-signal/BSM, the removal is the same—just match the connector and options on the replacement mirror.

🔧 Acadia - Side View Mirror Replacement

You’ll remove the inside door trim panel, unplug the mirror wiring, and swap the mirror assembly. The mirror is held on by a few nuts behind the small interior corner cover, so the job is mostly careful trim removal.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours (first side)

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground with the ignition OFF and the key away from the vehicle.
• ⚠️ Disconnect the negative battery cable before unplugging door wiring to reduce the chance of accidental shorts and to avoid setting warning lights.
• ⚠️ Support the mirror with one hand while removing the last nut so it doesn’t fall and chip paint.
• ⚠️ Use a plastic trim tool—metal screwdrivers can crack panels and mar paint.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Trim removal tool set (plastic)
• Small flat trim pick
• 7mm socket
• 10mm socket
• 1/4" ratchet
• 3" extension (1/4" drive)
• Torque wrench (inch-pound)
• Painters tape
• Magnetic parts tray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly (left/driver) - Qty: 1
• Side view mirror assembly (right/passenger) - Qty: 1
• Door trim panel retainer clips - Qty: 6-12
• Butyl tape (vapor barrier adhesive) - Qty: 1

---

📋 Before You Begin

• Park on a flat surface, shift to Park, and set the parking brake.
• Lower the window on the side you’re working on (it makes panel handling easier).
• Disconnect the negative battery cable using a 10mm socket and wait 2 minutes.
• Sail panel = the small triangular interior trim at the top front corner of the door by the mirror.
• Trim clips = plastic fasteners that “pop” the panel to the door; they can break, so having spares helps.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Protect the paint and get access ready

• Apply painters tape along the door edge near the mirror area to help prevent accidental scratches.
• Place a magnetic parts tray nearby for screws and nuts.

Step 2: Remove the interior sail panel

• Use a trim removal tool set (plastic) to gently pry the sail panel straight outward (it’s held by clips).
• If there’s a small tweeter speaker in the panel, unplug it using a small flat trim pick to release the connector tab.

Step 3: Remove the door pull/handle trim and screws

• Use a trim removal tool set (plastic) to pop off the small trim covers in/near the interior handle and the pull pocket (if equipped).
• Remove the exposed screws using a 7mm socket, 1/4" ratchet, and 3" extension.

Step 4: Lift off the window switch panel and unplug it

• Use a trim removal tool set (plastic) to pry up the window switch panel.
• Unplug the switch connector(s) using a small flat trim pick to lift the locking tab, then pull the connector straight out.

Step 5: Remove the door trim panel

• Starting at the bottom edge, use a trim removal tool set (plastic) to pop the door panel clips free.
• Once clips are released, lift the whole panel upward to unhook it from the window ledge.
• Disconnect any remaining electrical connectors using the small flat trim pick for the lock tabs.
• If your Acadia has a mechanical door-handle cable, unhook it carefully (rotate the cable housing out, then lift the cable end out of the lever). Take a photo first.

Step 6: Peel back the vapor barrier (only as needed)

• Carefully peel back the plastic water shield near the mirror area using a trim removal tool set (plastic).
• If the butyl adhesive is messy or won’t reseal, plan to use butyl tape during reassembly.

Step 7: Unplug the mirror connector

• Locate the mirror wiring connector near the front upper area of the door.
• Release the locking tab with a small flat trim pick and unplug the connector.

Step 8: Remove the mirror mounting nuts

• Support the mirror with one hand from the outside.
• Remove the mirror mounting nuts using a 10mm socket, 1/4" ratchet, and 3" extension.

Step 9: Remove the mirror assembly

• Feed the mirror wiring through the door opening and remove the mirror from the outside.
• Clean the mounting surface (dirt here can cause wind noise or leaks).

Step 10: Install the new mirror

• Feed the new mirror harness through the opening and set the mirror onto the door.
• Hand-start all mounting nuts to avoid cross-threading.
• Tighten the nuts evenly using a 10mm socket.
• Final tighten with a torque wrench (inch-pound): Torque to 9 N·m (80 in-lb).

Step 11: Reconnect wiring and reseal the vapor barrier

• Plug in the mirror connector until it clicks.
• Press the vapor barrier back into place firmly; add butyl tape where it won’t stick.

Step 12: Reinstall the door panel and trim

• Reconnect all electrical connectors (and the door-handle cable if equipped).
• Hang the panel on the window ledge, then press around the edges to snap clips in place.
• Reinstall screws using the 7mm socket, 1/4" ratchet, and 3" extension.
• Reinstall the window switch panel (press in until it snaps) and the sail panel (press to clip in).

Step 13: Reconnect the battery

• Reconnect the negative battery cable using a 10mm socket.

---

✅ After Repair

• Turn the ignition ON and test mirror up/down/left/right adjustment.
• If equipped, test mirror heat, turn signal, puddle lamp, and power fold.
• Verify window switch, door lock, and door handle all work normally.
• Take a short drive and listen for wind noise; re-check the mirror seating if needed.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$650 (parts + labor, per side depending on options/paint)

DIY Cost: $90-$400 (parts only, per side depending on options/paint)

You Save: $160-$250+ by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
