🔧 Q3 - Side View Mirror Replacement

This job replaces a damaged side mirror on your Q3. You’ll remove the inside door trim, unplug the mirror wiring, unbolt the mirror, and install the new one.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours (one side)

Assumption: You’re replacing the full mirror assembly (not just the glass); glass-only steps are included too.

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground with ignition OFF and key away from the vehicle.
• ⚠️ If your door has an airbag (common on many vehicles), avoid turning ignition ON while connectors are unplugged to prevent an airbag/SRS warning light.
• ⚠️ Support the mirror with one hand while removing the last bolt so it doesn’t fall and chip paint.
• ⚠️ If you disconnect the battery, keep the tailgate closed and windows down first.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Plastic trim removal tool set
• Pick tool
• Torx T20 screwdriver
• Torx T25 screwdriver
• Torx T30 bit socket
• 1/4" drive ratchet
• 3/8" drive ratchet
• 3" extension
• 10mm socket
• Torque wrench (2–25 Nm range)
• Small flat-blade screwdriver
• Painter’s tape
• Magnetic parts tray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly (LH driver or RH passenger, painted cap as needed) - Qty: 1
• Door panel clips - Qty: 5-10
• Mirror glass (optional, if replacing glass only) - Qty: 1
• Mirror cap cover (optional, if damaged) - Qty: 1

---

📋 Before You Begin

• Park on a flat surface, shift to Park, and set the parking brake.
• Use painter’s tape to protect the paint around the mirror base and door edge.
• If you choose to disconnect the battery: use a 10mm socket to remove the negative terminal and isolate it so it can’t spring back.
• Trim tool = plastic pry tool to avoid scratches.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the inner mirror “sail” trim

• Open the door fully for access.
• Use a plastic trim removal tool to pry off the small triangular trim at the front top corner of the door (inside), near the mirror.
• If there’s a small connector (tweeter speaker) attached, release it with a pick tool and unplug it.

Step 2: Remove the door panel fasteners

• Use a pick tool or small flat-blade screwdriver to carefully pop off covers in the door pull/handle area.
• Remove screws using a Torx T20 screwdriver and/or Torx T25 screwdriver (locations vary by door panel).
• Put screws in a magnetic parts tray.

Step 3: Release the door panel clips

• Start at the bottom edge of the door panel.
• Use a plastic trim removal tool to pop the clips free around the perimeter.
• Pop, don’t yank—clips break easily.

Step 4: Lift the door panel off and disconnect wiring

• Lift the whole panel straight upward to unhook it from the window channel.
• Support the panel close to the door and unplug connectors (window switch, courtesy light, etc.).
• If equipped, unhook the inner door handle cable carefully (note its routing for reassembly).

Step 5: Unplug the mirror connector

• Locate the mirror wiring connector near the front upper area of the door.
• Release the lock tab using a pick tool, then unplug the connector.

Step 6: Remove the mirror mounting bolts

• Hold the mirror on the outside with one hand.
• Use a Torx T30 bit socket with a ratchet and extension to remove the mirror mounting bolts (commonly 3 bolts).
• Remove the mirror from the outside and feed the wiring through the opening.
• Torque to 8 Nm (6 ft-lbs) on installation (common Audi mirror fastener torque; verify with service data for your exact mirror hardware).

Step 7: Install the new mirror assembly

• Feed the mirror wiring through the door opening.
• Position the mirror squarely on the door.
• Start all bolts by hand first to prevent cross-threading.
• Tighten with a Torx T30 bit socket, then finish with a torque wrench: Torque to 8 Nm (6 ft-lbs).

Step 8: Reconnect mirror wiring and quick-test

• Plug the mirror connector back in until it clicks.
• If the battery was disconnected, reconnect it using a 10mm socket.
• Turn ignition ON and test mirror adjustment, heating (if equipped), and turn signal in the mirror (if equipped).
• Turn ignition OFF before reassembly if you still have connectors unplugged elsewhere.

Step 9: Reinstall the door panel

• Reconnect all door panel electrical connectors and the door handle cable.
• Hang the panel on the top lip (window channel) first, then press downward to seat it.
• Press around the edges to snap all clips back in.
• Reinstall screws using a Torx T20 screwdriver / Torx T25 screwdriver.
• Reinstall the sail trim using your hands (press until it clips in).

Step 10 (Optional): Mirror glass-only replacement (if that’s what you meant)

• Tilt the mirror glass fully inward using the mirror switch so you can access the outside edge.
• Use a plastic trim removal tool to gently pry the mirror glass off the motor plate (it snaps on).
• Disconnect heater wires from the back of the glass using a pick tool.
• Reconnect heater wires, align the glass to the motor plate, and press evenly until it snaps in.
• Press near the center, not the edges.

---

✅ After Repair

• Confirm the mirror sits flush and doesn’t wobble.
• Test: mirror adjust in all directions, mirror heat (if equipped), power fold (if equipped), and mirror turn signal (if equipped).
• Check the door panel: window switch works, door opens from inside and outside, and there are no rattles.
• If an SRS/airbag light comes on, it typically requires a scan tool to clear after the fault is fixed.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$900 (parts + labor, depending on options like heat/blind-spot/power-fold)

DIY Cost: $150-$650 (parts only)

You Save: $200-$450 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
