Assumption: Your Focus has power mirrors (common). If yours is manual, skip the electrical-connector steps.

🔧 Focus - Side View Mirror Replacement

Replacing a side view mirror means removing the small interior trim at the front top corner of the door, unplugging the mirror (if powered), and unbolting the mirror from the door. Then you install the new mirror, tighten the nuts evenly, and verify the mirror adjustment works.

Difficulty Level: Beginner | Estimated Time: 0.5-1.5 hours (per side)

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground with the ignition OFF and key removed.
• ⚠️ If your mirror is powered/heated, disconnect the battery negative cable to prevent accidental shorting.
• ⚠️ Wear safety glasses—door trim clips can pop loose suddenly.
• ⚠️ Support the mirror from the outside when removing the last nut so it doesn’t drop and chip paint.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" drive ratchet
• 6" socket extension
• Torx T20 screwdriver
• Trim removal tool set
• Small flathead screwdriver
• Needle-nose pliers
• Torque wrench (inch-pound or low-range Nm)
• Painter’s tape
• Shop rags
• Safety glasses
• Work gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly (left or right, paint-to-match or textured) - Qty: 1
• Door trim panel clips - Qty: 4-10 (nice to have spares)
• Mirror mounting nuts (if not included with mirror) - Qty: 3

---

📋 Before You Begin

• Park your Focus on a flat surface and open the window on the side you’re working on.
• Apply painter’s tape around the mirror base on the outside to protect paint.
• If equipped with power/heated mirrors: use 10mm socket to disconnect the battery negative cable and isolate it so it can’t spring back.
• Lay a shop rag on the door sill to protect interior plastics while you work.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the interior mirror “sail” trim cover

• At the top front corner of the door (inside), use a trim removal tool set to pry the small triangular trim panel outward.
• If there’s a small retaining clip, use needle-nose pliers to help release it without breaking it.
• Pry close to the clips, not the edge.

Step 2: Decide if you need to loosen/remove the door panel

• On many Focus doors, the mirror connector sits behind the sail trim and is accessible now.
• If you cannot reach the connector or mirror studs, you may need to loosen/remove the door trim panel:
• Use a Torx T20 screwdriver to remove visible door-pull/handle screws (locations vary).
• Use a trim removal tool set to pop the door panel clips free around the perimeter.
• Lift the panel upward to unhook it from the window ledge, then support it.
• Use a small flathead screwdriver to release electrical connectors (lock tabs), if equipped.
• Don’t yank—connectors have locking tabs.

Step 3: Unplug the mirror (power/heated mirrors)

• Find the mirror electrical connector near the mirror mounting area.
• Press the lock tab and disconnect it by hand; if stuck, use a small flathead screwdriver gently to lift the tab.
• Trim note: If your mirror is manual, there will be no connector—skip this step.

Step 4: Remove the mirror mounting nuts

• Support the mirror with one hand from the outside.
• Use a 10mm socket, 6" socket extension, and 1/4" drive ratchet to remove the mirror mounting nuts (typically 3).
• Place the nuts in a tray or pocket so they don’t fall into the door.

Step 5: Remove the mirror from the door

• Carefully pull the mirror straight away from the door.
• Feed the wiring grommet/connector through the hole (if equipped) by hand.
• Use a shop rag to wipe the mounting surface clean.

Step 6: Install the new mirror

• Guide the mirror wiring through the door opening first (if equipped), then seat the mirror onto the mounting area.
• Start all mounting nuts by hand to avoid cross-threading.
• Use a 10mm socket and 1/4" drive ratchet to snug them evenly.
• Use a torque wrench (inch-pound or low-range Nm) to finish tightening: Torque to 9 Nm (80 in-lbs).
• Tighten evenly so the mirror sits flat.

Step 7: Reconnect wiring and reassemble trim

• Reconnect the mirror connector until it clicks (if equipped).
• If you removed the door panel, reconnect all connectors, hang the panel on the window ledge, then press clips back in by hand.
• Reinstall screws using a Torx T20 screwdriver.
• Reinstall the sail trim by lining up clips and pressing it into place.

Step 8: Reconnect the battery (if disconnected)

• Use a 10mm socket to reconnect the battery negative cable and tighten it snug.

---

✅ After Repair

• Turn ignition ON and test mirror adjustment (left/right, up/down) if equipped.
• If heated mirror is equipped, verify heat works after a few minutes (may depend on rear defrost button).
• Close the door and check mirror stability—no wobble at the base.
• Remove the painter’s tape and clean fingerprints from the glass and paint.

---

💰 DIY vs Shop Cost

Shop Cost: $200-$550 (parts + labor)

DIY Cost: $60-$350 (parts only)

You Save: $140-$200+ by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
