🔧 Side View Mirrors - Replacement

Your mirror assembly is replaced from inside the door. On your Silverado, the mirror is usually held by fasteners behind the interior sail trim and connected by one or more electrical plugs for power adjust, heat, turn signal, puddle lamp, and memory features if equipped.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before unplugging mirror connectors. This helps prevent module faults.
• Use care around the door trim and window glass. The edges can scratch easily.
• Support the mirror from outside while removing the last fastener so it does not fall.
• If your mirror has memory, heating, or turn signals, make sure every connector is fully seated during installation.
• Do not force the trim panel clips. Broken clips can cause rattles.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 7mm socket
• 10mm socket
• Ratchet
• Short extension
• Trim panel removal tool
• Pick tool
• Flat plastic pry tool
• Torque wrench
• Safety glasses
• Gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly - Qty: 1
• Mirror mounting nuts - Qty: 3
• Door trim panel clips - Qty: 1 set

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Lower the window glass before disconnecting the battery. This gives you more room to work.
• Turn the ignition off and remove the key fob from the vehicle.
• Disconnect the negative battery cable and wait at least 2 minutes before unplugging connectors.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the door sail trim

• Use a flat plastic pry tool to gently pop off the triangular sail trim at the front upper corner of the door panel.
• Set the trim aside carefully. Work slowly to avoid breaking clips.

Step 2: Remove the mirror fasteners

• Use a 10mm socket, ratchet, and short extension to remove the 3 mirror mounting nuts.
• Support the mirror from outside the door while removing the last nut.
• Torque on installation: 8 Nm (71 ft-lbs)

Step 3: Disconnect the mirror wiring

• Reach behind the opening and unplug the mirror connector(s) using your fingers or a pick tool only if a lock tab is tight.
• If the connector has a lock, release it before pulling the plug apart.

Step 4: Remove the old mirror

• Lift the mirror assembly away from the door.
• Inspect the mounting surface and clean off any dirt or old foam.

Step 5: Install the new mirror

• Position the new mirror on the door and route the wiring through the opening.
• Plug in all connectors until they click fully into place.
• Start the 3 mounting nuts by hand first, then snug them evenly with the 10mm socket.
• Torque to 8 Nm (71 ft-lbs)

Step 6: Reinstall the sail trim

• Align the trim and press it into place by hand.
• Make sure all clips are seated fully with no gaps.

Step 7: Reconnect power and test

• Reconnect the negative battery cable using a 10mm socket.
• Test mirror adjustment, heating, turn signal, puddle lamp, and folding function if equipped.
• Check that the mirror does not vibrate or move when touched.

---

✅ After Repair

• Verify both mirrors adjust correctly from the switch.
• Check the turn signal and heated mirror function if equipped.
• Drive over a short route and listen for wind noise around the mirror base.
• If the mirror has memory, cycle the memory presets to confirm proper operation.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$900 (parts + labor)

DIY Cost: $150-$500 (parts only)

You Save: $200-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-2 hours.

---
